Quick-Disconnect Plug Connector • #23 Contacts
Crimp Rear Release • Ordering Information
Quick Disconnect
These plugs snap securely into
receptacle housings and release with
a simple pull.
Two Keying Styles
A single master key provides fast
mating in low-light situations, or specify
three keys for more polarizing options.
Two Shell Styles
Integral platform for direct shield
attachment using the
Band-Master
ATS termination system, or an
accessory thread for attaching a
strain relief.
TM
Series 804 Plug Connector
with Banding Platform
HoW to oRDER
804-026
series
-06
shell style
Plug
M
sample part Number
6-7
p
Contact style
Connector supplied
with contacts
Pin
Socket
3
A
shell Key
position
omit
for Single
Master Key
Pos. A
(Normal)
Pos. B
Pos. C
Pos. D
Pos. E
Pos. F
shell Material / Finish
Aluminum / Black Anodize
(Non-Conductive)
RoHS Compliant
Aluminum / Electroless
Nickel
RoHS Compliant
Aluminum / Olive Drab
Cadmium over Electroless
Nickel Finish
shell size- Insert
Arrangement
1
4
2
3
-06
C
p
s
804-026
Plug with
Banding
Platform
M
6 - 4
1
6
5
7
A
2
4
NF
6 - 7
3
7
10
9
8
2
1
4
Pin with 30 AWG
Crimp Barrel
Socket with 30 AWG
Crimp Barrel
Connector supplied
without contacts
Pin Connector,
Less Contacts
Socket Connector,
Less Contacts
9
G
b
C
D
E
F
Plug with
Accessory
Thread
804-027
Aluminum / Zinc-Nickel
over Electroless Nickel
Aluminum / Zinc-Nickel
Black over Electroless
Nickel
Stainless Steel / Passivate
Stainless Steel / Olive Drab
Chromate over Cadmium
Stainless Steel / Zinc
Cobalt Alloy / Black
Chromate
ZN
H
ZNu
7 - 10
7
12
16
19
17
13
3
1
4
8
A
b
Z1
Zb
ZC
9 - 19
6 3
11
15
18
23
25
1
8
14
20
5
10
17
22
7
13
19
2 4
12
24
16
21
10-26
26
Connectors with contacts
are supplied with signal and/
or power crimp contacts.
These contacts are not
installed.
Coaxial contacts and non-
standard signal contacts are
ordered separately.
Dimensions in Inches (millimeters) are subject to change without notice.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
37
E-Mail: sales@glenair.com
High Speed
Mighty Mouse
804-026 and 804-027
Series 804 Push-Pull High Speed Mighty Mouse
804-026 and 804-027
Series 804 Push-Pull High Speed Mighty Mouse
Quick-Disconnect Plug Connector • #23 Contacts
Crimp Rear Release • Dimensions
.950 (24.13) Max
.561 (14.25)
.060 (1.52)
High Speed
Mighty Mouse
Key
Ø
A
.990 (25.15)
Straight
Ridges
.561 (14.25)
.060 (1.52)
ØB
ØC ØD
ØC
ØD
Integral Band Platform
804-026-06
E Thread
Accessory Thread
804-027-06
DIMENsIoNs
shell
size
6
7
9
10
Ø A Max.
In.
mm.
.495
.575
.670
.745
12.57
14.61
17.02
18.92
Ø b
In.
mm.
.286
.390
.500
.564
7.26
9.91
12.70
14.33
Ø C
In.
mm.
.282
.351
.454
.529
7.16
8.92
11.53
13.44
Ø D
In.
mm.
.313
.383
.486
.563
7.95
9.73
12.34
14.30
E threads
.3125-32 UNEF-2A
.4375-28 UNEF-2A
.5625-24 UNEF-2A
.6250-24 UNEF-2A
sERIEs 804 pLuG KEY posItIoNs
A°
A
B
C
D
E
F
150°
75°
95°
140°
75°
95°
b°
210°
210°
230°
275°
275°
210°
B° A°
Dimensions in Inches (millimeters) are subject to change without notice.
© 2013 Glenair, Inc.
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
38
E-Mail: sales@glenair.com
