CD74HCT137M96 datasheet, PDF - EEWORLD Datasheet

CD74HCT137M96: DescriptionIC,DECODER/DEMUX,3-TO-8-LINE,HCT-CMOS,SOP,16PIN,PLASTIC; Categorylogic logic; File Size545KB，8 Pages; ManufacturerIntersil ( Renesas ); Websitehttp://www.intersil.com/cda/home/

Download Datasheet Parametric View All

CD74HCT137M96 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	CD74HCT137M96	-	-	View	Buy Now

IC,DECODER/DEMUX,3-TO-8-LINE,HCT-CMOS,SOP,16PIN,PLASTIC

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Objectid	100700114
package instruction	SOP, SOP16,.25
Reach Compliance Code	not_compliant
ECCN code	EAR99
JESD-30 code	R-PDSO-G16
JESD-609 code	e0
Load capacitance (CL)	50 pF
Logic integrated circuit type	OTHER DECODER/DRIVER
MaximumI(ol)	0.004 A
Number of functions	1
Number of terminals	16
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP16,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
method of packing	TR
Prop。Delay @ Nom-Sup	57 ns
Certification status	Not Qualified
Nominal supply voltage (Vsup)	5 V
surface mount	YES
technology	CMOS
Temperature level	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
