DUAL-IN-LINE SOCKETS
Clinch Pin
Open Frame
•
Special lock-down feature
prevents floating of socket
during soldering.
•
Open insulator with
ladder construction.
•
Sockets are XY stackable.
•
Socket pins feature closed
end construction eliminat-
ing any solder wicking
problems.
Series 101
Total number
of pins
Quantity
per tube
Ordering Information
A
0.3
0.4
0.7
0.8
0.9
1.0
1.2
1.4
1.1
1.2
1.4
1.6
2.0
2.4
3.2
B
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.6
0.6
0.6
0.6
0.6
0.9
C
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.7
0.7
0.7
0.7
0.7
1.0
67
50
28
25
22
20
16
14
18
16
14
12
10
8
6
101-93-306-41-56X
101-93-308-41-56X
101-93-314-41-56X
101-93-316-41-56X
101-93-318-41-56X
101-93-320-41-56X
101-93-324-41-56X
101-93-328-41-56X
101-93-422-41-56X
101-93-624-41-56X
101-93-628-41-56X
101-93-632-41-56X
101-93-640-41-56X
101-93-648-41-56X
101-93-964-41-56X
6
8
14
16
18
20
24
28
22
24
28
32
40
48
64
For High
Temperature
Insulators
Add ‘100’
To End Of
Part Numbers
Clinch Pins:
Two Opposite Corner Pins
X = 0
Four Corner Pins
X = 8
SPECIFY PLATING CODE XX=
93
200µ” Sn/Pb
30µ” Au
Sleeve (Pin)
Contact (Clip)
w w w. m i l l - m a x . c o m
18
516-922-6000
