SML-K19 series
Rank Reference of Brightness
White (WB)
Package
structure
Package Height
size
（mm）
I
F
(mA)
Luminous
Intensity
(cd)
S1
S2
T1
T2
U1
U2
V1
V2
W1
W2
X1
X2
Y1
Y2
Z1
Z2
90to110 110to140 140to180 180to220 220to280 280to360 360to450 450to560 560to710
710to
900to1100 1100to1400 1400to1800 1800to2200 2200to2800 2800to3600
PSML2
4520 0.6
90
SMLK19WBECW
SMLK19WBEDW
SMLK19WBEAW
SMLK19WBEBW
※Brightnessonspecificationsheetincludetoleranceofwithin±10%.
Part No. Construction
Chromaticity sort
∗2
Rank sign (Brightness Rank)
∗1
S M L
Series name
K 1 9 W B E A W 1
Package name
Chip Type
Emitting Color
Resin Color
Taping
Specifications
2 Y1
Rank sign
(Brightness Rank)
∗
WB
White
W
Milky White
1
Cathode at sprocket hole side
∗
Concerning the Brightness rank
• Please refer to the rank chart above for luminous intensity classification.
• Please refer to the Specification sheet for color classification.
• Part name is individual for each rank.
• When shipped as sample, the part name will be a representative part name.
General products are free of ranks. Please contact sales if rank appointment is needed.
∗ ∗2:
Please refer to Chromaticity diagram.
Packing Specification
ROHMLEDproductsarebeingshippedwithdesiccant(silicagel)concludedinmoisture-proofbags.
Pastingthemoisturesensitivelabelontheoutersurfaceofthemoisture-proofbagsorenclosingthehumidityindicationcardinsidethebagisavailableuponrequest.
Pleasecontactthenearestsalesofficeordistributerifnecessary.
© 2012 ROHM Co., Ltd. All rights reserved.
www.rohm.com
3/3
2012.03 - Rev.A
