IP series
Pushbutton switches for harsh environments - bushing Ø 12 mm - latching
Distinctive features and specifications
K
Latching action
Actuator remains in the low position when “ON”.
K
Illuminated or non-illuminated
K
Compact
Behind-panel depth less than 20 mm (.787)
K
Flat round actuator for optional marking
K
Sealed to IP67
ENVIRONMENTAL SPECIFICATIONS
GENERAL SPECIFICATIONS
B1
• Panel thickness : 1,5 mm (.059) min.
5,5 mm (.217) max.
• Total travel : 2,5 mm (.098)
+/- 0,3 mm
• Typical operating force : 5 N
+/- 2N
• Low level/mech. life : 200.000 cycles
• Torque : 1,5 Nm max. applied to nut
• Soldering : 320°C max. for 3 sec.
MATERIALS
• Front panel sealing : IP67 according to IEC 60529
• Shock resistance : 100 g according to IEC 512-4, test 6c
• Vibration resistance : 10-500Hz - 10 g according to IEC 512-4, test 6d
• Salt spray : IEC 512-6, test 11f
• Robustness (non-illuminated) : IK06 according to EN 50102 (1 joule)
• Operating temperature : -40°C to +85°C
ELECTRICAL SPECIFICATIONS
• Max. current/voltage rating with resistive load :
4A 12VDC, 200.000 cycles
1A 48VDC, 200.000 cycles
2A 48VDC, 100.000 cycles
3A 48VDC, 75.000 cycles
1A 72VDC, 15.000 cycles
• Initial contact resistance : 100 mΩ max.
• Insulation resistance : 1 GΩ min. at 500VDC
• Dielectric strength : 1.500 Vrms between terminals
1.000 VAC rms between terminals and frame
LED COMPONENT SPECIFICATIONS
• Case : thermoplastic, UL 94-V0
• Actuator : polyamide 6/6
• Bushing/bezel : zinc die-cast
(zamak), black painted
• Contacts : silver, gold plated
• Multi-wire lead AWG20,
section 0,6 mm
2
• LED wire : AWG26, section 0,12 mm
2
• Lens : polycarbonate
• Terminal seal : epoxy
LED colour
Super red (L0S)
Yellow (L0Y)
Green (L0G)
Blue (L0B)
Forward current
20mA
20mA
20mA
20mA
Typ. forward voltage Max. forward voltage
1,95V
2V
2,1V
3,2V
1,95V
2,05V
2,5V
4V
A resistor must be series-connected by the user.
Resistor value = supply voltage - LED forward voltage
LED forward current
MOUNTING
Panel cut-out
1.50min-5.50Max
(.059 min-.216max)
12.90
(.507)
1
Matrix mounting
20.00
(.787)
20.00
(.787)
Back of panel space requirement
Ø13.60
(.535DIA)
ø13.50
(.531DIA)
O-ring
APEM
www.apem.com
B1-21
20.00
(.787)
19.10
(.751)
IP series
Pushbutton switches for harsh environments - bushing Ø 12 mm - latching
Overview
IP
SERIES
Actuator shapes
C
R
P
Square
Round, curved
Round, flat
1
Electrical function
OFF - ON
S
F
Z1
P
Terminals
Solder lug
Flying leads
Quick-connect
Straight PC
Contacts
AD
Silver, gold
plated
B1
Actuator colours
1
B
2
3
5
6
7/1
8
9
Blue
Dark blue
Black
Green
Yellow
Red
White
Bright chrome
Orange
LED colours
Blank
L0S
L0Y
L0G
L0B
Non-illum.
Super red
Yellow
Green
Blue
100
101
104
Options
Satin chrome
bezel
Bright chrome
bezel
High actuator
(non-illum. round
models only)
ABOUT THIS SERIES
On the following pages, you will find successively :
model structure of switches and options in the same order as in above chart
Dimensions :
first dimensions are in mm while inches are shown as bracketed numbers.
: please note that not all combinations of above numbers are available.
Refer to the following pages for further information.
NOTICE
A sealing boot
is available to protect the switches against frost and sand (P/N U5125).
It is presented after the IA series and in section H.
Mounting accessories
: Standard hardware supplied : 1 hex nut 14 mm (.551) across flats and 1 O-Ring.
Packaging unit
: 25 pieces
B1-22
www.apem.com
APEM
IP series
Pushbutton switches for harsh environments - bushing Ø 12 mm - latching
Square or round - illuminated
• Four LED colours
• Tin plated LED terminals
Straight
P
Quick-connect
Z1
2.40
(.094)
2.30
(.090)
8.40
(.330)
Solder lug
S
3.40
(.133)
1.20
(.047)
2.80
(.110)
OFF
ON
2.80
(.110)
MODEL
STRUCTURE
CISCOSP
ECH: 0.9
5-05-03
3.20
(.125)
1.00
(.039)
1.40
(.055)
B1
1.50 Min
(.059 Min)
5.70
(.224)
Square models
Solder lug terminals
IPC1SAD
Flying lead terminals
IPC1FAD
©
Flat
7.00
(.275)
12.00
(.472SQ)
CISCOSZ-A
CIPNLF1COS
17.50
(.688SQ)
DESSIN ECH 0.9
DESSIN ECH 0.9
8.20
(.322)
OFF
-
ON
5-05-03
16.00 Max
(.629 Max)
5.70
(.224)
ø12.00x0.75SI
(.472DIAx0.75IS)
17.10.01
12.40
(.488)
OFF
-
ON
EPOXY
Also available with straight PC :
IPC1PAD
or quick-connect terminals :
IPC1Z1AD
Round models
©
Flat
CIPDTF1SFCT
Solder lug terminals
IPR1SAD
OFF
-
22.10.01
ON
7.00
(.275)
ø12.00
(.472DIA)
Wire colours : black : contact, red : LED anode(+),
blue : LED cathode(-)
1.50 Min
(.059 Min)
500±10
(19.68±.393)
CIPDTF1CLU
ø17.50
(.688DIA)
ECH0.9
16.00 Max
(.629 Max)
12.40
(.488)
Flying lead terminals
IPR1FAD
8.20
(.322)
OFF
-
ON
DESSIN ECH 0.9
ø12.00x0.75SI
(.472DIAx0.75IS)
17.10.01
EPOXY
Also available with straight PC :
IPR1PAD
or quick-connect terminals :
IPR1Z1AD
ACTUATOR COLOURS
LED COLOURS
1
: blue -
B
: dark blue -
2
: black -
3
: green -
5
: yellow
6
: red -
7/1
: white -
8
: bright chrome -
9
: orange
L0S
: super red -
L0Y
: yellow -
L0G
: green -
L0B
: blue
CIPDTF1RLU
DESSIN ECH 0.9
OPTIONS
17.10.01
100
: Satin chrome bezel
101
: Bright chrome bezel
APEM
www.apem.com
500±10
(19.68±.393)
B1-23
IP series
Pushbutton switches for harsh environments - bushing Ø 12 mm - latching
Square or round - non-illuminated
MODEL
STRUCTURE
Actuator marking available on IPP models (symbol 10 mm max.). On request.
Square models
Solder lug terminals
IPC1SAD
Flying lead terminals
IPC1FAD
©
Flat
7.00
(.275)
1.50 Min
(.059 Min)
5.70
(.224)
12.00
(.472SQ)
17.50
(.688SQ)
8.20
(.322)
OFF
-
ON
B1
12.40
(.488)
OFF
-
ON
EPOXY
500±10
(19.68±.393)
Also available with straight PC :
IPC1PAD
or quick-connect terminals :
IPC1Z1AD
Round models
CURVED ACTUATOR
©
Flat
2.00
(.078)
7.00
(.275)
16.00 Max
(.629 Max)
ø12.00x0.75SI
(.472DIAx0.75IS)
Ø17.50
(.688DIA)
2.00
(.078)
14.10
(.555)
7.00
(.275)
Ø12.00
(.472DIA)
Ø12.00
(.472DIA)
OFF
-
ON
8.20
(.322)
Solder lug terminals
IPR1SAD
Flying lead terminals
IPR1FAD
FLAT ACTUATOR
OFF
-
ON
1.50 Min
(.059 Min)
Ø12.00x0.75SI
(.472DIAx0.75IS)
12.40
(.488)
CIPDTF1CNL
OFF
-
ON
Also available with straight PC :
IP•1PAD
or quick-connect terminals :
IP•1Z1AD
ACTUATOR COLOURS
1
: blue -
B
: dark blue -
2
: black -
3
: green -
5
: yellow -
6
: red -
7/1
: white -
8
: bright chrome -
9
: orange
OPTIONS
100
: Satin chrome bezel
101
: Bright chrome bezel
104
: High actuator (for round model only)
4.70
(.185)
4.70
(.185)
Ø12.00
(.472DIA)
Ø12.00
(.472DIA)
104
IPR
104
IPP
B1-24
www.apem.com
500±10
(19.68±.393)
Solder lug terminals
IPP1SAD
Flying lead terminals
IPP1FAD
OFF
-
ON
EPOXY
DESSIN ECH 0.9
17.10.01
APEM
