3316X105M datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Passive components> The resistor> 3316X105M

3316X105M: DescriptionRESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.25W, 1000000ohm, ROHS COMPLIANT; CategoryPassive components The resistor; File Size115KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com; Environmental Compliance

Download Datasheet Parametric View All

3316X105M Overview

RESISTOR, TRIMMER, CERMET, 1 TURN(S), 0.25W, 1000000ohm, ROHS COMPLIANT

3316X105M Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
Objectid	1666347834
package instruction	SMT, 2018
Reach Compliance Code	unknown
ECCN code	EAR99
Actuator direction	VERTICAL
Actuator type	SCREW
structure	Rectangular
Installation features	SURFACE MOUNT
Number of terminals	3
number of turns	1
Maximum operating temperature	125 °C
Minimum operating temperature	-55 °C
Package height	2.3 mm
Package length	5 mm
Package shape	RECTANGULAR PACKAGE
Package form	SMT
Package width	4.5 mm
method of packing	Tape, Embossed
Rated power dissipation(P)	0.25 W
resistance	1000000 Ω
resistance law	LINEAR
Resistor type	TRIMMER
rotation angle	210 deg
size code	2018
surface mount	YES
technology	CERMET
Terminal shape	GULL WING
Tolerance	20%
Operating Voltage	200 V

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Resistors

Product Feature Selector

> Product Details

3316X105M Product Details

Live Product Chat

Variable Resistors

C onve rte d to EU R oHS/ELV C om plia nt

(

Sta te m e nt of C om plia nce

)

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

3316X105M

(1623906-1)

T E I nternal N umber: 1 6 2 3 9 0 6 - 1

Product Highlights:

Variable Resistor

Resistor Type = Trimmer

Resistance Selection = M ?

Resistance = 1M ?

Power Rating = .25 W

View all Features

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Active

Buy P roduc t

Documentation & Additional Information

Product Drawings:

SMD PROFESSIONAL TRIMMERS SERIES 3316

(PDF, English)

Catalog Pages/Data Sheets:

SMD Professional Trimmers - Type 3315 Series - Tyco ...

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Product Type = Variable Resistor

Resistor Type

= Trimmer

Resistance (?)

= 1M

Element

= C ermet

Sealed

= Yes

Mount Angle

= Horizontal

Termination Type

= Surface Mount Terminals

Electrical Characteristics:

Resistance Selection (?) = M

Power Rating (W)

= 0.25

Tolerance (%)

= 20

Termination Related Features:

Termination Post Orientation

= Delta

Body Related Features:

Series

= 3315

Package, C omponent Size

= 5

Configuration Related Features:

Sections

= Single

Adjustment Location

= Top

Adjustment Style

= Screwdriver Slot

Operating Function

= Single Turn

Industry Standards:

RoHS/ELV C ompliance

= RoHS compliant, ELV compliant

Lead Free Solder Processes

= Reflow solder capable to 245?C

RoHS/ELV C ompliance History = C onverted to comply with RoHS

directive

Conditions for Usage:

Temperature C oefficient (ppm/?C )

= 100

Other:

Brand = C itec

Additional Information:

Product Line Information
