123-13-422-41-801100 datasheet, PDF

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > The connector> socket> 123-13-422-41-801100

Preview

123-13-422-41-801100: DescriptionIC Socket, DIP22, 22 Contact(s), ROHS COMPLIANT; CategoryThe connector socket; File Size230KB，1 Pages; ManufacturerMill-Max; Websitehttps://www.mill-max.com; Environmental Compliance

Download Datasheet Parametric View All

123-13-422-41-801100 Overview

IC Socket, DIP22, 22 Contact(s), ROHS COMPLIANT

123-13-422-41-801100 Parametric

Parameter Name	Attribute value
Is it lead-free?	Lead free
Is it Rohs certified?	conform to
package instruction	ROHS COMPLIANT
Reach Compliance Code	compli
ECCN code	EAR99
Other features	DIP SOCKET, LOW PROFILE
Contact to complete cooperation	GOLD (30) OVER NICKEL (100)
Contact completed and terminated	Gold (Au)
Contact material	NOT SPECIFIED
Device slot type	IC SOCKET
Type of equipment used	DIP22
JESD-609 code	e4
Number of contacts	22
Base Number Matches	1

Preview

Download Datasheet

View All

DUAL-IN-LINE SOCKETS

With Integral Decoupling Capacitor

Open Frame

0,38 0,64

0,25 0,46

2,41 3,71

●

Low profile DIP sockets with

Series 110, 122, 123...801

2,79

4,19

3,18

4,9

9,4

integral decoupling capacitor:

.1

µ

F 20%-50V multilayer

ceramic epoxy encapsulated.

Temp. range: -25°C to +85°C.

at 3 amps. See page 208 for

details.

0089 pins. See pages 134 &

162 for details.

can withstand infra-red reflow

and vapor phase soldering.

●

Hi-Rel, 4-finger #30 clip rated

12,96

0,51

0,64

●

Uses M-M #1001, 0088, or

●

High temperature insulator

Total number

of pins

2,54

Quantity

per tube

Or dering Inf ormation

Solder Tail

110-XX-314-41-801000

110-XX-316-41-801000

110-XX-318-41-801000

110-XX-320-41-801000

110-XX-322-41-801000

110-XX-324-41-801000

110-XX-328-41-801000

110-XX-422-41-801000

110-XX-624-41-801000

110-XX-628-41-801000

110-XX-632-41-801000

110-XX-640-41-801000

2 Level Wrapost

L = 9,4mm

122-XX-314-41-801000

122-XX-316-41-801000

122-XX-318-41-801000

122-XX-320-41-801000

122-XX-322-41-801000

122-XX-324-41-801000

122-XX-328-41-801000

122-XX-422-41-801000

122-XX-624-41-80 1000

122-XX-628-41-801000

122-XX-632-41-801000

122-XX-640-41-801000

3 Level Wrapost

L = 12,96mm

123-XX-314-41-80 1000

123-XX-316-41-801000

123-XX-318-41-801000

123-XX-320-41-801000

123-XX-322-41-80 1000

123-XX-324-41-801000

123-XX-328-41-801000

123-XX-422-41-80 1000

123-XX-624-41-801000

123-XX-628-41-801000

123-XX-632-41-801000

123-XX-640-41-801000

A

17,7

20,3

22,8

25,3

27,8

30,4

35,5

B

7,62

C

10,1

28

25

22

20

18

16

14

18

16

14

12

10

14

16

18

20

22

24

28

22

24

28

32

40

27,8 10,16 12,7

30,5

35,5

40,6

50,8

15,24

17,7

XX= Plating Code

See Below

For RoHS compliance,

select



plating code.

For the all gold option

(XX=13) also change

part number from

1XX-XX-XXX-41-801000

to

1XX-13-XXX-41-801100

SPECIFY PLATING CODE XX=

13



0,25µm Au

0,76µm Au

93

5,08µm Sn/Pb

0,76µm Au

43



5,08µm Sn

0,76µm Au

Sleeve (Pin)

Contact (Clip)

w w w. m i l l - m a x . c o m

21m



516-922-6000
