Heavy Service Ever-Lok
Heavy Service Ever-Lok
®
– Ordering Information
Plugs
Connectors
Receptacles
Configuration
30 Amp
60 Amp
100 Amp
2P, 3W
3P, 4W
2P, 3W
3P, 4W
3P, 4W
8407
8408
8417
8418†
8428-72
8443
8444
8453
8454
8464-72
HSF Series
Basic Receptacle
HSF8403
HSF8404
HSF8413
HSF8414
HSF8424-72
HSA Series*
8403
8404
8413
8414
8424-72
Note:
Reverse service available by adding “R” suffix to catalog number. Solder lugs on 100
amp only.
Connectors –
can be furnished with conduit adapters to accommodate rigid conduit or
standard connectors for armored and non-metallic cable or flexible conduit. See page
93.
* Can be furnished with 45° angle adapter when specified on order. Add suffix -45 to
catalog number.
Flap Covers are standard on all receptacles.
Std. Cable Bushing (see page 10 for other bushings)
Current Rating
30
60
100
Bushing
g"
1i"
1d"
Max. AWG Size
#8, -7 strand or flexible
#4, -7 strand or flexible
#2, -7 strand or flexible
Conduit Size
Current Rating
30
60
100
Std. Size
1"
1"
2"
Max. Size
1b"
1"
2"
Cable Conduit Adapters: see page 93.
†Note:
9418/F27194 Automotive 480VAC Version
Industrial and Commercial
Outlet Location: Standard Series
B Std.
A
D
30 & 60
Amp
C A
D
100 Amp
Box is square and
may be rotated to
bring outlets into
desired position.
B Std.
108
© 2001 Thomas & Betts Corporation. Specifications are subject to change without notice.
www.tnb.com
