Series 518 Single and Dual Row Socket Strips
w/Collet Contacts & Solder Pin Tails
FEATURES
• Collet Sockets available in Single or Dual Rows
• Cuttable to the number of pins desired to fit the application
• Side-to-side and End-to-end Stackable
GENERAL SPECIFICATIONS
•
BODY MATERIAL: Black UL 94V-0 Glass-filled 4/6 Nylon
•
PIN BODY: Brass 360 1/2-hard per UNS C36000 ASTM B16/B16M-05
•
PIN BODY PLATING: 10µ [0.25µ] min. Au per MIL-G-45204 –OR–
200µ [5.08µ]
ORDERING INFORMATION
min. 93/7 Sn/Pb per ASTM B545 or 200µ [5.08µ] min. Sn per ASTM B545 Type 1
XX X 518-1 XX XX
over 100µ [2.54µ] min. Ni per SAE AMS-QQ-N-290B
•
4-FINGER COLLET CONTACT: BeCu per UNS C17200 ASTM B194-08
Additional Options
H = Heavy Au on Collet Shell
•
CONTACT PLATING: 200µ [5.08µ] min. 93/7 Sn/Pb per ASTM B545 –OR–
200µ
T = Sn Collet, Sn Shell
[5.08µ] min. Sn per ASTM B545 Type 1 or 10µ [0.25µ] Au per MIL-G-45204 over
TL = Sn/Pb Collet & Shell
50µ [1.27µ] min. [1.27µ] Ni per SAE AMS-QQ-N-290 Heavy 30µ [0.76µ]
E = Extra Long Solder Pin Tail
•
CONTACT CURRENT RATING: 3 amps
Plating
•
INSERTION FORCE: 180g/pin, based on 0.018 [0.46] dia. test lead
0 = Au Collet, Sn Shell
•
WITHDRAWAL FORCE: 90g/pin, based on 0.018 [0.46] dia. test lead
0TL = Au Collet, Sn/Pb Shell
•
NORMAL FORCE: 140g/pin, based on 0.018 [0.46] dia. test lead
1 = Au Collet & Shell
•
OPERATING TEMPERATURE: 221°F [105°C] for Sn and Sn/Pb plating; 257°F
Solder Pin Tail
[125°C] for Au plating
Series
•
INSERTION FORCE: 180g/pin, based on 0.018 [0.46] dia. test lead
No. of Rows
•
WITHDRAWAL FORCE: 90g/pin, based on 0.018 [0.46] dia. test lead
0 = Single
•
NORMAL FORCE: 140g/pin, based on 0.018 [0.46] dia. test lead
1 = Dual
•
ACCEPTS LEADS:
0.015-0.025 [0.38-0.64] dia.
No. of Pins
•
LEAD LENGTHS: from 0.100 [2.54] min.
1 to 40 – Single Row
2 to 40 – Dual Row
MOUNTING CONSIDERATIONS
•
SUGGESTED PCB HOLE SIZE:
0.030 ±0.002 [0.76 ±0.05] dia.
ALL DIMENSIONS: INCHES [MILLIMETERS]
ALL TOLERANCES: ±0.005 [0.13] UNLESS OTHERWISE SPECIFIED
FOR SOCKET STRIPS WITH WIRE WRAP PINS, SEE DATA SHEETS 12021
CONSULT FACTORY FOR OTHER SIZES AND CONFIGURATIONS
CUSTOMIZATION: ARIES SPECIALIZES IN CUSTOM DESIGN AND PRODUCTION.
SPECIAL MATERIALS, PLATINGS, SIZES, AND CONFIGURATIONS CAN BE
FURNISHED, DEPENDING ON QUANTITY.
ARIES RESERVES THE RIGHT TO CHANGE PRODUCT GENERAL SPECIFICATIONS
WITHOUT NOTICE
PRINTOUTS OF THIS DOCUMENT MAY BE OUT-OF-DATE AND SHOULD BE
CONSIDERED UNCONTROLLED
