DUAL-IN-LINE SOCKETS
Solderless Press-Fit
Open Frame
•
Designed for solderless
press-fit into plated-thru
holes.
•
Pin lengths are suitable for
.062” and .093”-.125” thick
panels.
•
Required plated thru-hole
is .036”-.041”, ie: use a
1.1mm drill prior to
plating.
•
Uses M-M# 0477 or 0478
with #30 contact, rated for
3 amps. See page 131 for
pin details.
Total number
of pins
Series 104
Quantity
per tube
Ordering Information
L = .175
(for .062 thick panel)
104-13-210-41-770
104-13-304-41-770
104-13-306-41-770
104-13-308-41-770
104-13-310-41-770
104-13-314-41-770
104-13-316-41-770
104-13-318-41-770
104-13-320-41-770
104-13-322-41-770
104-13-324-41-770
104-13-328-41-770
104-13-420-41-770
104-13-422-41-770
104-13-424-41-770
104-13-428-41-770
104-13-432-41-770
104-13-624-41-770
104-13-628-41-770
104-13-632-41-770
104-13-636-41-770
104-13-640-41-770
104-13-642-41-770
104-13-648-41-770
104-13-650-41-770
104-13-652-41-770
104-13-950-41-770
104-13-952-41-770
104-13-964-41-770
PLATING CODE =
A
B
C
L = .250
(for .125 thick panel)
104-13-210-41-780
104-13-304-41-780
104-13-306-41-780
104-13-308-41-780
104-13-310-41-780
104-13-314-41-780
104-13-316-41-780
104-13-318-41-780
104-13-320-41-780
104-13-322-41-780
104-13-324-41-780
104-13-328-41-780
104-13-420-41-780
104-13-422-41-780
104-13-424-41-780
104-13-428-41-780
104-13-432-41-780
104-13-624-41-780
104-13-628-41-780
104-13-632-41-780
104-13-636-41-780
104-13-640-41-780
104-13-642-41-780
104-13-648-41-780
104-13-650-41-780
104-13-652-41-780
104-13-950-41-780
104-13-952-41-780
104-13-964-41-780
13
10µ” Au
30µ” Au
10
4
6
8
10
14
16
18
20
22
24
28
20
22
24
28
32
24
28
32
36
40
42
48
50
52
50
52
64
0.5
0.2
0.3
0.4
0.5
0.7
0.8
0.9
1.0
1.1
1.2
1.4
1.0
1.1
1.2
1.4
1.6
1.2
1.4
1.6
1.8
2.0
2.1
2.4
2.5
2.6
2.5
2.6
3.2
0.2
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.3
0.4
0.4
0.4
0.4
0.4
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.6
0.9
0.9
0.9
0.3
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.4
0.5
0.5
0.5
0.5
0.5
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
0.7
1.0
1.0
1.0
40
102
67
50
40
28
25
22
20
18
16
14
20
18
16
14
12
16
14
12
11
10
9
8
8
7
8
7
6
For High
Temperature
Insulators
Add ‘100’
To End Of
Part Numbers
Sleeve (Pin)
Contact (Clip)
