293D
Vishay Sprague
Solid Tantalum Chip Capacitors
T
ANTAMOUNT
®
, Commercial, Surface Mount
FEATURES
•
Terminations: 100 % Tin, standard SnPb
available
•
Compliant Terminations
•
Molded case available in six case codes
•
Compatible with “High Volume” automatic pick
and place equipment
•
Optical character recognition qualified
•
Meets IEC Specification QC300801/US0001 and
EIA 535BAAC
Pb-free
Available
RoHS*
COMPLIANT
PERFORMANCE/ELECTRICAL CHARACTERISTICS
Operating Temperature:
- 55 °C to + 85 °C
(to + 125 °C with voltage derating)
Note:
Refer to Doc. 40088
Capacitance Range:
0.10 µF to 680 µF
Capacitance Tolerance:
± 20 %, ± 10 % standard
(20 % only for P case code)
100 % Surge Current Tested (D & E Case Codes)
Voltage Rating:
4 WVDC to 50 WVDC
OTHER SPECIFICATIONS
CECC
30801-005
30801-009
30801-011
30801-801
793DX
CTC3
CTC4
793DE
IECQ
PQC32/GB003
300801/FR001
793DX
CTC3
ORDERING INFORMATION
293D
TYPE
107
CAPACITANCE
This is expressed in
picofarads. The first
two digits are the
significant figures.
The third is the
number of zeros to
follow.
X9
010
CAPACITANCE DC VOLTAGE RATING
TOLERANCE
AT + 85 °C
X0 = ± 20 %
X9 = ± 10 %
X5 = ± 5 %
(Special Order)
This is expressed in
volts. To complete the
three-digit block, zeros
precede the voltage
rating. A decimal point
is indicated by an “R”
(6R3 = 6.3 volts).
D
CASE CODE
See Ratings
and Case
Codes Table.
2WE3
TERMINATION AND
PACKAGING
2TE3: 100 % tin terminations, 7" (178 mm) reel
2WE3: 100 % tin terminations, 13" (330 mm) reel
8T: 90/10 SnPb Solder Plate terminations,
7" (178 mm) reel
8W: 90/10 SnPb Solder Plate terminations,
13" (330 mm) reel
** 2T: Not recommended for new designs
** 2W: Not recommended for new designs
Note:
We reserve the right to supply higher voltage ratings, tighter capacitance tolerance and higher grade capacitors in the same case size.
Voltage substitutions will be marked with the higher voltage rating.
DIMENSIONS
in inches [millimeters]
L
TW
H
TH MIN.
W
P
CASE CODE
A
B
C
D
E
EIA SIZE
3216-18
3528-21
6032-28
7343-31
7343-43
L
0.126 ± 0.008
[3.2 ± 0.20]
0.138 ± 0.008
[3.5 ± 0.20]
0.236 ± 0.012
[6.0 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
0.287 ± 0.012
[7.3 ± 0.30]
W
0.063 ± 0.008
[1.6 ± 0.20]
0.110 ± 0.008
[2.8 ± 0.20]
0.126 ± 0.012
[3.2 ± 0.30]
0.170 ± 0.012
[4.3 ± 0.30]
0.170 ± 0.012
[4.3 ± 0.30
H
0.063 ± 0.008
[1.6 ± 0.20]
0.075 ± 0.008
[1.9 ± 0.20]
0.098 ± 0.012
[2.5 ± 0.30]
0.110 ± 0.012
[2.8 ± 0.30]
0.158 ± 0.012
[4.0 ± 0.30]
P
0.031 ± 0.012
[0.80 ± 0.30]
0.031 ± 0.012
[0.80 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
0.051 ± 0.012
[1.3 ± 0.30]
TW
0.047 ± 0.004
[1.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.087 ± 0.004
[2.2 ± 0.10]
0.095 ± 0.004
[2.4 ± 0.10]
0.095 ± 0.004
[2.4 ± 0.10]
T
H
(MIN.)
0.028
[0.70]
0.028
[0.70]
0.039
[1.0]
0.039
[1.0]
0.039
[1.0]
** Terminations and packaging codes 2T and 2W will be discontinued by January 2008
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 40002
Revision: 16-Apr-07
For technical questions, contact: tantalum@vishay.com
www.vishay.com
41
293D
Vishay Sprague
Solid Tantalum Chip Capacitors
T
ANTAMOUNT
®
, Commercial, Surface Mount
RATINGS AND CASE CODES
µF
0.10
0.15
0.22
0.33
0.47
0.68
1.0
1.5
2.2
3.3
4.7
6.8
10
15
22
33
47
68
100
150
220
330
470
680
A
A
A
A/B
A/B
A/BC
A/B/C
A/B/C
B/C/D
A/B/C/D
B/C/D
B/C/D/E
D/E
D/E
E
A
A
A/B
A/B
A/B/C
A/B/C
A/B/C
A/B/C
A/B/C/D
B/C/D
B/C/D
C/D/E
C/D/E
D/E
E
A
A
A
A/B
A/B
A/B/C
A/B/C
A/B/C
B/C/D
B/C/D
B*/C/D
C/D
D/E
D/E
D*/E
A
A
A/B
A/B
A/B
A/B/C
A/B/C
B/C
B/C/D
B/C/D
C/D
D
D/E
D*/E
A
A
A
A/B
A/B
A/B/C
A/B/C
B/C
B/C/D
B/C/D
C/D
D/E
D/E
E
A
A
A/B
A/B
A/B
A*/B/C
A/B/C
B/C
B/C/D
C/D
D
D/E
E
4V
6.3 V
10 V
16 V
20 V
25 V
35 V
A
A
A
A
A/B
A/B
A/B
B/C
B/C
B/C
B/C/D
C/D
C/D
D/E
D/E
50 V
A
A/B
A/B
A/B
A/B/C
B/C
B/C
B/C
C/D
C/D
D
D/E
D/E
* Preliminary values, contact factory for availability.
MARKING
Capacitance Code,
pF
Vishay
Sprague
Logo
Capacitance
Code
Polarity Band
Indicates
Lead (Pb)-free
Voltage
Capacitance
µF
Polarity
Band
Indicates
Lead (Pb)-free
X
X
V 104L
22
XX
10L
2
Vishay
Sprague
Logo
Polarity Band
Voltage
Code
Voltage
Code
Date Code
"P" Case Size
"A" Case Size
"B, C, D, E" Case Sizes
www.vishay.com
42
For technical questions, contact: tantalum@vishay.com
Document Number: 40002
Revision: 16-Apr-07
293D
Solid Tantalum Chip Capacitors
T
ANTAMOUNT
®
, Commercial, Surface Mount
STANDARD/EXTENDED RATINGS
MAX. DC
MAX. DF
MAX. ESR
LEAKAGE
AT + 25 °C
AT + 25 °C
CASE CODE
PART NUMBER
AT + 25 °C
120 Hz
100 kHz
(µA)
(%)
(Ohms)
4 WVDC AT + 85 °C, SURGE = 5.2 V . . . 2.7 WVDC AT + 125 °C, SURGE = 3.4 V
3.3
A
293D335X_004A2_E3
0.5
6
7.6
4.7
A
293D475X_004A2_E3
0.5
6
6.3
6.8
A
293D685X_004A2_E3
0.5
6
5.5
10
A
293D106X_004A2_E3
0.5
6
5.1
10
B
293D106X_004B2_E3
0.5
6
3.5
15
A
293D156X_004A2_E3
0.6
6
3.4
15
B
293D156X_004B2_E3
0.6
6
2.9
22
A
293D226X_004A2_E3
0.9
6
2.9
22
B
293D226X_004B2_E3
0.9
6
2.5
22
C
293D226X_004C2_E3
0.9
6
1.8
33
A
293D336X_004A2_E3
1.3
6
2.9
33
B
293D336X_004B2_E3
1.3
6
2.0
33
C
293D336X_004C2_E3
1.3
6
1.8
47
A
293D476X_004A2_E3
1.9
14
2.5
47
B
293D476X_004B2_E3
1.9
6
1.9
47
C
293D476X_004C2_E3
1.9
6
1.8
68
B
293D686X_004B2_E3
2.7
6
1.9
68
C
293D686X_004C2_E3
2.7
6
1.4
68
D
293D686X_004D2_E3
2.7
6
0.8
100
A
293D107X_004A2_E3
10.0
30
2.5
100
B
293D107X_004B2_E3
4.0
8
1.8
100
C
293D107X_004C2_E3
4.0
6
0.8
100
D
293D107X_004D2_E3
4.0
6
0.7
150
B
293D157X_004B2_E3
6.0
14
1.6
150
C
293D157X_004C2_E3
6.0
12
0.7
150
D
293D157X_004D2_E3
6.0
8
0.6
220
B
293D227X_004B2_E3
8.8
18
1.5
220
C
293D227X_004C2_E3
8.8
8
0.7
220
D
293D227X_004D2_E3
8.8
8
0.6
220
E
293D227X_004E2_E3
8.8
8
0.5
330
D
293D337X_004D2_E3
13.2
8
0.6
330
E
293D337X_004E2_E3
13.2
8
0.5
470
D
293D477X_004D2_E3
18.8
10
0.6
470
E
293D477X_004E2_E3
18.8
10
0.5
680
E
293D687X_004E2_E3
27.2
12
0.5
6.3 WVDC AT + 85 °C, SURGE = 8 V . . . 4 WVDC AT + 125 °C, SURGE = 5 V
2.2
A
293D225X_6R3A2_E3
0.5
6
7.6
3.3
A
293D335X_6R3A2_E3
0.5
6
6.3
4.7
A
293D475X_6R3A2_E3
0.5
6
5.5
6.8
A
293D685X_6R3A2_E3
0.5
6
5.0
6.8
B
293D685X_6R3B2_E3
0.5
6
3.4
10
A
293D106X_6R3A2_E3
0.6
6
3.4
10
B
293D106X_6R3B2_E3
0.6
6
2.9
15
A
293D156X_6R3A2_E3
0.9
6
2.9
15
B
293D156X_6R3B2_E3
0.9
6
2.5
15
C
293D156X_6R3C2_E3
0.9
6
1.8
22
A
293D226X_6R3A2_E3
1.3
6
2.9
22
B
293D226X_6R3B2_E3
1.3
6
2.0
22
C
293D226X_6R3C2_E3
1.3
6
1.8
33
A
293D336X_6R3A2_E3
2.0
14
2.5
33
B
293D336X_6R3B2_E3
2.0
6
1.9
33
C
293D336X_6R3C2_E3
2.0
6
1.5
47
A
293D476X_6R3A2_E3
2.8
12
1.6
47
B
293D476X_6R3B2_E3
2.8
6
1.9
47
C
293D476X_6R3C2_E3
2.8
6
1.4
* For 10 % tolerance, specify “9”; for 20 % tolerance, change to “0”.
CAPACITANCE
(µF)
MAX. RIPPLE
100 kHz
Irms
(Amps)
0.10
0.11
0.12
0.12
0.16
0.15
0.17
0.16
0.18
0.25
0.16
0.21
0.25
0.17
0.21
0.25
0.21
0.28
0.43
0.22
0.22
0.37
0.46
0.23
0.40
0.50
0.24
0.40
0.50
0.57
0.50
0.57
0.50
0.57
0.57
0.10
0.11
0.12
0.12
0.16
0.15
0.17
0.16
0.18
0.25
0.16
0.21
0.25
0.17
0.21
0.27
0.22
0.21
0.28
Vishay Sprague
Document Number: 40002
Revision: 16-Apr-07
For technical questions, contact: tantalum@vishay.com
www.vishay.com
43
293D
Vishay Sprague
Solid Tantalum Chip Capacitors
T
ANTAMOUNT
®
, Commercial, Surface Mount
STANDARD/EXTENDED RATINGS
CAPACITANCE
(µF)
MAX. ESR
MAX. DF
MAX. DC
AT + 25 °C
AT + 25 °C
LEAKAGE
CASE CODE
PART NUMBER
100 kHz
120 Hz
AT + 25 °C
(Ohms)
(%)
(µA)
6.3 WVDC AT + 85 °C, SURGE = 8 V . . . 4 WVDC AT + 125 °C, SURGE = 5 V
D
293D476X_6R3D2_E3
2.8
6
0.8
B
293D686X_6R3B2_E3
4.1
6
1.8
C
293D686X_6R3C2_E3
4.1
6
0.8
D
293D686X_6R3D2_E3
4.1
6
0.7
B
293D107X_6R3B2_E3
6.0
15
1.7
C
293D107X_6R3C2_E3
6.0
6
0.8
D
293D107X_6R3D2_E3
6.0
6
0.7
C
293D157X_6R3C2_E3
9.0
8
0.7
D
293D157X_6R3D2_E3
9.0
8
0.6
E
293D157X_6R3E2_E3
9.0
8
0.5
C
293D227X_6R3C2_E3
13.9
14
0.7
D
293D227X_6R3D2_E3
13.2
8
0.6
E
293D227X_6R3E2_E3
13.2
8
0.5
D
293D337X_6R3D2_E3
19.8
8
0.6
E
293D337X_6R3E2_E3
19.8
8
0.5
E
293D477X_6R3E2_E3
28.2
10
0.5
10 WVDC AT + 85 °C, SURGE = 13 V . . . 7 WVDC AT + 125 °C, SURGE = 8 V
A
293D155X_010A2_E3
0.5
6
8.0
A
293D225X_010A2_E3
0.5
6
6.3
A
293D335X_010A2_E3
0.5
6
5.5
A
293D475X_010A2_E3
0.5
6
5.0
B
293D475X_010B2_E3
0.5
6
3.4
A
293D685X_010A2_E3
0.7
6
4.2
B
293D685X_010B2_E3
0.7
6
2.9
A
293D106X_010A2_E3
1.0
6
3.4
B
293D106X_010B2_E3
1.0
6
2.5
C
293D106X_010C2_E3
1.0
6
1.8
A
293D156X_010A2_E3
1.5
6
2.9
B
293D156X_010B2_E3
1.5
6
2.0
C
293D156X_010C2_E3
1.5
6
1.8
A
293D226X_010A2_E3
2.2
8
2.5
B
293D226X_010B2_E3
2.2
6
1.9
C
293D226X_010C2_E3
2.2
6
1.5
B
293D336X_010B2_E3
3.3
6
1.9
C
293D336X_010C2_E3
3.3
6
1.4
D
293D336X_010D2_E3
3.3
6
0.8
B
293D476X_010B2_E3
4.7
6
1.8
C
293D476X_010C2_E3
4.7
6
1.1
D
293D476X_010D2_E3
4.7
6
0.7
C
293D686X_010C2_E3
6.8
6
1.0
D
293D686X_010D2_E3
6.8
6
0.7
C
293D107X_010C2_E3
10
8
0.9
D
293D107X_010D2_E3
10
8
0.6
D
293D157X_010D2_E3
15
8
0.6
E
293D157X_010E2_E3
15
8
0.5
D
293D227X_010D2_E3
22
8
0.6
E
293D227X_010E2_E3
22
8
0.5
D
293D337X_010D2_E3
33
10
0.5
E
293D337X_010E2_E3
33
10
0.5
16 WVDC AT + 85 °C, SURGE = 20 V . . . 10 WVDC AT + 125 °C, SURGE = 12 V
A
293D105X_016A2_E3
0.5
4
9.3
A
293D155X_016A2_E3
0.5
6
6.7
A
293D225X_016A2_E3
0.5
6
5.9
B
293D225X_016B2_E3
0.5
6
4.6
A
293D335X_016A2_E3
0.5
6
5.0
B
293D335X_016B2_E3
0.5
6
3.5
A
293D475X_016A2_E3
0.8
6
5.0
B
293D475X_016B2_E3
0.8
6
2.9
MAX. RIPPLE
100 kHz
Irms
(Amps)
0.43
0.22
0.37
0.46
0.22
0.37
0.46
0.40
0.50
0.57
0.39
0.50
0.57
0.50
0.57
0.57
0.10
0.11
0.12
0.12
0.16
0.13
0.17
0.15
0.18
0.25
0.16
0.21
0.25
0.17
0.21
0.27
0.21
0.28
0.43
0.22
0.32
0.46
0.33
0.46
0.35
0.50
0.50
0.57
0.50
0.57
0.57
0.57
0.09
0.11
0.11
0.14
0.12
0.16
0.12
0.17
47
68
68
68
100
100
100
150
150
150
220
220
220
330
330
470
1.5
2.2
3.3
4.7
4.7
6.8
6.8
10
10
10
15
15
15
22
22
22
33
33
33
47
47
47
68
68
100
100
150
150
220
220
330
330
1.0
1.5
2.2
2.2
3.3
3.3
4.7
4.7
* For 10 % tolerance, specify “9”; for 20 % tolerance, change to “0”.
www.vishay.com
44
For technical questions, contact: tantalum@vishay.com
Document Number: 40002
Revision: 16-Apr-07
293D
Solid Tantalum Chip Capacitors
T
ANTAMOUNT
®
, Commercial, Surface Mount
STANDARD/EXTENDED RATINGS
MAX. ESR
MAX. DF
MAX. DC
AT + 25 °C
AT + 25 °C
LEAKAGE
CASE CODE
PART NUMBER
100 kHz
120 Hz
AT + 25 °C
(Ohms)
(%)
(µA)
16 WVDC AT + 85 °C, SURGE = 20 V . . . 10 WVDC AT + 125 °C, SURGE = 12 V
6.8
A
293D685X_016A2_E3
1.1
6
4.2
6.8
B
293D685X_016B2_E3
1.1
6
2.5
6.8
C
293D685X_016C2_E3
1.1
6
1.9
10
A
293D106X_016A2_E3
1.6
6
3.0
10
B
293D106X_016B2_E3
1.6
6
2.0
10
C
293D106X_016C2_E3
1.6
6
1.8
15
B
293D156X_016B2_E3
2.4
6
2.0
15
C
293D156X_016C2_E3
2.4
6
1.5
22
B
293D226X0016B2_E3
3.5
6
1.9
22
C
293D226X_016C2_E3
3.5
6
1.4
22
D
293D226X_016D2_E3
3.5
6
0.8
33
B
293D336X0016B2_E3
5.3
6
1.8
33
C
293D336X_016C2_E3
5.3
6
1.1
33
D
293D336X_016D2_E3
5.3
6
0.7
47
C
293D476X_016C2_E3
7.5
6
1.0
47
D
293D476X_016D2_E3
7.5
6
0.7
68
D
293D686X_016D2_E3
10.9
6
0.6
100
D
293D107X_016D2_E3
16
8
0.6
100
E
293D107X_016E2_E3
16
8
0.6
150
E
293D157X_016E2_E3
24
8
0.5
20 WVDC AT + 85 °C, SURGE = 26 V . . . 13 WVDC AT + 125 °C, SURGE = 16 V
0.68
A
293D684X_020A2_E3
0.5
4
10
1.0
A
293D105X_020A2_E3
0.5
4
8.4
1.5
A
293D155X_020A2_E3
0.5
6
6.3
2.2
A
293D225X_020A2_E3
0.5
6
5.9
2.2
B
293D225X_020B2_E3
0.5
6
3.5
3.3
A
293D335X_020A2_E3
0.7
6
5.9
3.3
B
293D335X_020B2_E3
0.7
6
3.0
4.7
A
293D475X_020A2_E3
0.9
6
5.0
4.7
B
293D475X_020B2_E3
0.9
6
2.9
4.7
C
293D475X_020C2_E3
0.9
6
2.3
6.8
A
293D685X_020A2_E3
1.4
6
4.5
6.8
B
293D685X_020B2_E3
1.4
6
2.5
6.8
C
293D685X_020C2_E3
1.4
6
1.9
10
B
293D106X_020B2_E3
2.0
6
2.5
10
C
293D106X_020C2_E3
2.0
6
1.7
15
B
293D156X_020B2_E3
3.0
6
2.3
15
C
293D156X_020C2_E3
3.0
6
1.5
15
D
293D156X_020D2_E3
3.0
6
0.9
22
B
293D226X_020B2_E3
4.4
6
2.1
22
C
293D226X_020C2_E3
4.4
6
1.1
22
D
293D226X_020D2_E3
4.4
6
0.7
33
C
293D336X_020C2_E3
6.6
6
1.0
33
D
293D336X_020D2_E3
6.6
6
0.7
47
D
293D476X_020D2_E3
9.4
6
0.7
47
E
293D476X_020E2_E3
9.4
6
0.6
68
D
293D686X_020D2_E3
13.6
6
0.7
68
E
293D686X_020E2_E3
13.6
6
0.6
100
E
293D107X_020E2_E3
20.0
8
0.5
25 WVDC AT + 85 °C, SURGE = 32 V . . . 17 WVDC AT + 125 °C, SURGE = 20 V
0.47
A
293D474X_025A2_E3
0.5
4
12
0.68
A
293D684X_025A2_E3
0.5
4
8.4
1.0
A
293D105X_025A2_E3
0.5
4
7.6
1.0
B
293D105X_025B2_E3
0.5
4
5.0
1.5
A
293D155X_025A2_E3
0.5
6
6.7
1.5
B
293D155X_025B2_E3
0.5
6
4.6
2.2
A
293D225X_025A2_E3
0.6
6
6.3
2.2
B
293D225X_025B2_E3
0.6
6
3.8
3.3
B
293D335X_025B2_E3
0.8
6
3.1
3.3
C
293D335X_025C2_E3
0.8
6
2.3
4.7
A
293D475X_025A2_E3
1.2
6
5.5
4.7
B
293D475X_025B2_E3
1.2
6
2.8
4.7
C
293D475X_025C2_E3
1.2
6
2.0
* For 10 % tolerance, specify “9”; for 20 % tolerance, change to “0”.
CAPACITANCE
(µF)
Document Number: 40002
Revision: 16-Apr-07
For technical questions, contact: tantalum@vishay.com
MAX. RIPPLE
100 kHz
Irms
(Amps)
0.13
0.18
0.24
0.16
0.21
0.25
0.21
0.27
0.21
0.28
0.43
0.22
0.32
0.46
0.33
0.46
0.50
0.50
0.52
0.57
0.09
0.09
0.11
0.11
0.16
0.11
0.17
0.12
0.17
0.22
0.13
0.18
0.24
0.18
0.25
0.19
0.27
0.41
0.20
0.32
0.46
0.33
0.46
0.46
0.52
0.46
0.52
0.57
0.08
0.09
0.10
0.13
0.11
0.14
0.11
0.15
0.17
0.22
0.12
0.17
0.24
Vishay Sprague
www.vishay.com
45
京公网安备 11010802033920号
EEWORLD
