572D
Vishay Sprague
Solid Tantalum Chip Capacitors
TANTAMOUNT
®
, Low Profile, Conformal Coated, Maximum CV
FEATURES
RATINGS AND CASE CODE
µF
4V
STD
A
P
B
A
A
S*
A*
B
A/T*/S*
EXT
STD
EXT
STD
EXT
STD
EXT
STD
6.3 V
10 V
16 V
25 V
STD
B*
A
35 V
EXT
P case offers single-sided lead (Pb)-free
terminations
Wraparound lead (Pb)-free terminations:
Q, S, A, B and T
COMPLIANT
RoHS
EXT
Q
S
P case
top
B
P case
bottom
B and T
cases
Q, S and
A cases
Images
not to
scale
P/Q/S
Q/S
S
A/T
B
Low Impedance
8 mm and 12 mm tape and reel packaging available per
EIA-481-1 and reeling per IEC 286-3
7" [178 mm] standard
13" [330 mm] available
PERFORMANCE CHARACTERISTICS
Capacitance Range:
2.2 µF to 220 µF
Capacitance Tolerance:
± 10 %, ± 20 % standard
Voltage Rating:
4 WVDC to 35 WVDC
Operating Temperature:
- 55 °C to + 85 °C
(To + 125 °C with voltage derating)
2.2
4.7
6.8
10
15
22
33
P
47
68
100
220
B/B**/T/S*
* Contact factory for availability
STANDARD / EXTENDED RATINGS
CAPACITANCE
CASE CODE
(µF)
PART NUMBER
MAX. DCL
AT + 25 °C
(µA)
MAX. DF
AT + 25 °C
120 Hz (%)
MAX. ESR
AT + 25 °C
100 kHz (Ohms)
MAX. RIPPLE
100 kHz
Irms (Amps)
0.13
0.63
0.63
0.37
0.26*
ORDERING INFORMATION
A
CASE CODE
See Ratings
and Case
Codes Table.
2 = 100 % Tin
T = Tape and Reel
4 = Gold Plated
7" [178 mm] Reel
W = 13" [330 mm] Reel
33
220
220
220
220*
P
B
B
T
S
572D
TYPE
336
CAPACITANCE
X0
CAPACITANCE
TOLERANCE
6R3
DC VOLTAGE RATING
AT + 85 °C
2
TERMINATION
T
REEL SIZE AND
PACKAGING
This is expressed in
picofarads. The first two
digits are the significant
figures. The third is the
number of zeros to
follow.
X0 =
±
20 %
X9 = ± 10 %
This is expressed in volts. To
complete the three-digit
block, zeros precede the
voltage rating. A decimal
point is indicated by an "R"
(6R3 = 6.3 volts).
Note:
Preferred Tolerance and reel sizes are in bold.
We reserve the right to supply higher voltage ratings and tighter capacitance tolerance capacitors in the same case size.
DIMENSIONS
in inches [millimeters]
Single-side electrodes
(Both electrodes at
bottom side only)
L
W
H
B
D
C
0.29
0.13
0.17
0.24
0.22
0.25
0.26
0.36
0.45
0.36
0.63
A
CASE CODE
P
L (Max.)
0.087 ± 0.012
[2.2 ± 0.3]
W
0.049 ± 0.012
[1.25 ± 0.3]
H
0.039 ± 0.008
[1.0 ± 0.2]
A
0.024 ± 0.012
[0.6 ± 0.3]
B
0.031 ± 0.012
[0.8 ± 0.3]
C
0.031 ± 0.012
[0.8 ± 0.3]
D (Ref.)
0.008
[0.2]
L
W
0.09
0.29
0.23*
0.28*
0.45
H
B
D
C
A
CASE CODE
0.22
0.45
0.22*
0.24*
Q
S
A
0.10
0.18
0.12
0.15
0.22*
B
NOTICE
Specifications of the products displayed herein are subject to change without notice. Vishay Intertechnology, Inc., or anyone on its behalf, assumes no responsibility or liability for any errors or inaccuracies. Information
contained herein is intended to provide a product description only. No license, express or implied, by estoppel or otherwise, to any intellectual property rights is granted by this document. Except as provided in Vishay’s terms and
conditions of sale for such products, Vishay assumes no liability whatsoever, and disclaims any express or implied warranty, relating to sale and/or use of Vishay products including liability or warranties relating to fitness for a particular
purpose, merchantability, or infringement of any patent, copyright, or other intellectual property right. The products shown herein are not designed for use in medical, life-saving, or life-sustaining applications. Customers using or selling
these products for use in such applications do so at their own risk and agree to fully indemnify Vishay for any damages resulting from such improper use or sale.
For technical questions, contact tantalum@vishay.com
Revision 30-Mar-06
T
L (Max.)
0.126 ± 0.008
[3.2 ± 0.2]
0.126 ± 0.012
[3.2 ± 0.3]
0.126 ± 0.012
[3.2 ± 0.3]
0.130 ± 0.012
[3.3 ± 0.3]
0.138 ± 0.008
[3.5 ± 0.2]
W
0.063 ± 0.008
[1.6 ± 0.2]
0.063 ± 0.012
[1.6 ± 0.3]
0.067 ± 0.012
[1.7 ± 0.3]
0.106 ± 0.012
[2.7 ± 0.3]
0.106 ± 0.008
[2.7 ± 0.2]
H
0.031 ± 0.008
[0.8 ± 0.2]
0.039 ± 0.008
[1.0 ± 0.2]
0.05 ± 0.012
[1.3 ± 0.3]
0.066 ± 0.012
[1.7 ± 0.3]
0.039 ± 0.008
[1.0 ± 0.2]
A
0.031 ± 0.008
[0.8 ± 0.2]
0.031 ± 0.012
[0.8 ± 0.3]
0.031 ± 0.012
[0.8 ± 0.3]
0.031 ± 0.012
[0.8 ± 0.3]
0.031 ± 0.008
[0.8 ± 0.2]
B
0.047 ± 0.008
[1.2 ± 0.2]
0.047 ± 0.012
[1.2 ± 0.3]
0.047 ± 0.012
[1.2 ± 0.3]
0.047 ± 0.012
[1.2 ± 0.3]
0.047 ± 0.008
[1.2 ± 0.2]
C
0.031 ± 0.008
[0.8 ± 0.2]
0.031 ± 0.012
[0.8 ± 0.3]
0.031 ± 0.012
[0.8 ± 0.3]
0.043 ± 0.012
[1.1 ± 0.3]
0.043 ± 0.008
[1.1 ± 0.2]
D (Ref.)
0.008
[0.2]
0.008
[0.2]
0.008
[0.2]
0.008
[0.2]
0.008
[0.2]
4 WVDC AT + 85 °C, SURGE = 5.2 V . . . 2.7 WVDC AT + 125 °C, SURGE = 3.4 V
572D336X_004P2_001**
1.32
14
1.5
572D227X_004B2_
8.8
16
0.2
572D227X_004B2_001**
8.8
16
0.2
572D227X_004T2_
8.8
26
0.6
572D227X_004S2_*
8.8*
25*
0.8*
6.3 WVDC AT 85 °C, SURGE = 8 V . . . 4 WVDC AT + 125 °C, SURGE = 5 V
33
A
572D336X_6R3A2_
2.1
8
0.8
33
P
572D336XO6R3P2_
2.1
14
1.5
33
Q
572D336X_6R3Q2_
2.1
10
2.0
33
S
572D336X_6R3S2_
2.1
10
1.0
47
Q
572D476X_6R3Q2_
3.0
10
1.1
47
S
572D476X_6R3S2_
3.0
10
0.9
68
S
572D686X06R3S2_
4.3
12
0.9
100
A
572D107X_6R3A2_
6.3
14
0.5
100
B
572D107X_6R3B2_
6.3
14
0.4
100
T
572D107X_6R3T2_
6.3
14
0.5
220
B
572D227X_6R3B2_
13.9
16
0.2
10 WVDC AT + 85 °C, SURGE = 13 V . . . 7 WVDC AT + 125 °C, SURGE = 8 V
10
P
572D106X_010P2_
1.0
8
3.0
33
A
572D336X_010A2_
3.3
10
0.8
33*
S*
572D336X_010S2_*
3.3*
10*
1.1*
47*
A*
572D476X_010A2_*
4.7*
10*
0.8*
100
B
572D107X_010B2_
10
14
0.4
16 WVDC AT + 85 °C, SURGE = 20 V . . . 10 WVDC AT + 125 °C, SURGE = 12 V
22
A
572D226X_016A2_
3.5
8
1.4
22
B
572D226X_016B2_
3.5
6
0.5
22*
S*
572D226X_016S2_*
3.5*
8*
1.4*
22*
T*
572D226X_016T2_*
3.5*
8*
1.4*
25 WVDC AT + 85 °C, SURGE = 32 V . . . 17 WVDC AT + 125 °C, SURGE = 20 V
2.2
Q
572D225X_025Q2_
0.65
6
5.0
4.7
A
572D475X_025A2_
1.2
6
2.0
4.7
S
572D475X_025S2_
1.2
8
4.0
10
A
572D106X_025A2_
2.5
10
3.5
35 WVDC AT + 85 °C, SURGE = 46 V . . . 23 WVDC AT + 125 °C, SURGE = 28 V
4.7*
B*
572D475X_035B2_*
1.7*
6*
1.6*
** = 1.7 mm Max. height, 572D227X_004B2_001 and 1.0 mm Max. height, 572D336X_004P2_001
For 10 % tolerance, specify "9"; For 20 % tolerance change to "0".
Extended range ratings are in bold print.
VMN-PT9170-0603
