3467CSL005

Description
Wire And Cable, 7 Conductor(s), 28AWG, 300V, ROHS COMPLIANT
CategoryThe connector    Connector bracket
File Size145KB,4 Pages
ManufacturerAlpha Wire
Websitehttp://www.alphawire.com/zh-CN/
Environmental Compliance
Download Datasheet Parametric View All

3467CSL005 Overview

Wire And Cable, 7 Conductor(s), 28AWG, 300V, ROHS COMPLIANT

3467CSL005 Parametric

Parameter NameAttribute value
Is it Rohs certified?conform to
MakerAlpha Wire
package instructionROHS COMPLIANT
Reach Compliance Codecompliant
CertificationCSA, UL
conductor materialTINNED COPPER
Connector bracket typeWIRE AND CABLE
structureCOMMUNICATION AND CONTROL CABLE
Cross-sectional area0.08 mm2
diameter5.13 mm
insulator materialPOLYVINYL CHLORIDE
Jacket materialPOLYVINYL CHLORIDE
length30.5 mm
Number of conductors7
Maximum operating temperature80 °C
Minimum operating temperature-20 °C
Rated voltage300 V
shieldYES
stay7X0.13
Wire gauge28 AWG
Base Number Matches1
Alpha Wire | 711 Lidgerwood Avenue, Elizabeth, NJ 07207
Tel: 1-800-52 ALPHA (25742), Web: www.alphawire.com
Customer Specification
PART NO. 3467C
Construction
Diameters (In)
1) Component 1
a) Conductor
b) Insulation
(1) Color Code
Cond
1
2
3
2) Cable Assembly
a) Twists:
3) Shield:
a) Foil Direction
b) Drain Wire
c) Braid
4) Jacket
a) Color(s)
Color
BLACK
RED
WHITE
7 X 1 COND
28 (7/36) AWG TC
0.010" Wall, Nom. PVC, Semi Rigid
Alpha Wire Color Code D
Cond
4
5
6
7 Components Cabled
8.0 Twists/foot (min)
Alum/Mylar Tape, 25% Overlap, Min.
Foil Facing Out
28 (7/36) AWG TC
TC,65% Coverage, Min.
0.035" Wall, Nom.,PVC
SLATE
ALPHA WIRE-* P/N 3467C 7C 28 AWG
SHIELDED 75C (UL) TYPE CL2 OR AWM 2464
b) Print
OR C(UL) 60C TYPE CMG FT4 CE ROHS
* = Factory Code
[Note: Product may have c(UL) or CSA markings depending upon plant of manufacture.]
0.202 (0.214 Max.)
Color
GREEN
ORANGE
BLUE
Cond
7
Color
BROWN
0.015
0.035
Applicable Specifications
1) UL
AWM/STYLE 2464
CL2
VW-1
2) CSA International
C(UL) TYPE CMG
FT4
3) CE:
EU Low Voltage Directive 2006/95/EC
60°C
80°C / 300 V
75°C
RMS
Environmental
