SPECIFICATIONS
Insulation Material:
Contact Material:
Current Rating:
Contact Resistance:
Insulation Resistance:
Withstanding:
Operating Temp:
PBT, UL94V-0
Phosphor Bronze
1 Amp
30mΩ max.
3000MΩ min.
500V AC for 1 minute
-40°C to +105°C
A
B
C
D
E
Series
JS-D
Pluggable Con-
nector
Positions
A
4
5.59
6
8.13
8
10.67
10
13.21
12
15.75
14
18.29
16
20.83
18
23.37
20
25.91
22
28.45
24
30.99
26
33.53
Type
Positions
A28B
XX
Top Entry Board
See Table
Mount, Female
F
RoHS compliant
Rev.
Description
Date
Approved
Drawing
Name
Approved Howard
Checked Lizzy
Drawn Tina
0.0 ± 0.35
1
2
3
4
Dimensions
B
C
D
3.81
9.66
6.98
6.35
12.20
9.52
8.89
14.74
12.06
11.43
17.28
14.60
13.97
19.82
17.14
16.51
22.36
19.68
19.05
24.90
22.22
21.59
27.44
24.76
24.13
29.98
27.30
26.67
32.52
39.84
29.21
35.06
32.38
31.75
37.60
34.92
Plating
Options
XX
X
TN=Tin
Blank=None
SGXX=Selective P=Polarized
Gold
L=Lock
GDXX=Gold
XX=Flash if blank
5,10, 15, 30u”
C
D
E
F
Date
06/14/07
06/14/07
06/14/07 Part No.:
Central Components Manufacturing
440 Lincoln Blvd., Middlesex, New Jersey 08846
Phone 732 469-5720 888 288-5152 Fax 732 469-1919
JS-D-A28B-XX-XX-X
G
7
8
9
G
0.00 ± 0.20 Angles ± 3’
UNIT: mm
5
6
Description: Mini-Size Connector, Female Top Entry Board Mount
