Tension spring |
Spacing 5.0 mm
AK3100/..-5.0-PEBBLE GREY
1- to n-poles
Technical Data
Wire Sizes
Solid min
solid max
Stranded (flexible)
min
Stranded (flexible)
max
0.14 mm²
2.5 mm²
0.14 mm²
2.5 mm²
Insulating Material
Material
Flammability Class
Temperatures
Operating Temperature
Wave Soldering Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Reflow Process
Soldering Temperature,
recommended
Peak Soldering Time,
recommended
Leere Zeile
-
-
265 °C
3-4 s
-30 °C - 105 °C
PA 6.6
UL 94 V-0
Order Data (Spacing 5.0 mm)
Poles
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Width (mm)
12.20
17.20
22.20
27.20
32.20
37.20
42.20
47.20
52.20
57.20
62.20
67.20
72.20
77.20
82.20
87.20
92.20
97.20
102.20
107.20
112.20
117.20
122.20
Article Designation
AK3100/2-5.0-PEBBLE GREY
AK3100/3-5.0-PEBBLE GREY
AK3100/4-5.0-PEBBLE GREY
AK3100/5-5.0-PEBBLE GREY
AK3100/6-5.0-PEBBLE GREY
AK3100/7-5.0-PEBBLE GREY
AK3100/8-5.0-PEBBLE GREY
AK3100/9-5.0-PEBBLE GREY
AK3100/10-5.0-PEBBLE GREY
AK3100/11-5.0-PEBBLE GREY
AK3100/12-5.0-PEBBLE GREY
AK3100/13-5.0-PEBBLE GREY
AK3100/14-5.0-PEBBLE GREY
AK3100/15-5.0-PEBBLE GREY
AK3100/16-5.0-PEBBLE GREY
AK3100/17-5.0-PEBBLE GREY
AK3100/18-5.0-PEBBLE GREY
AK3100/19-5.0-PEBBLE GREY
AK3100/20-5.0-PEBBLE GREY
AK3100/21-5.0-PEBBLE GREY
AK3100/22-5.0-PEBBLE GREY
AK3100/23-5.0-PEBBLE GREY
AK3100/24-5.0-PEBBLE GREY
Article Number
53100020001F
53100030001F
53100040001F
53100050001E
53100060001E
53100070001E
53100080001D
53100090001D
53100100001D
53100110001D
53100120001D
53100130001D
53100140001D
53100150001D
53100160001D
53100170001D
53100180001D
53100190001D
53100200001D
53100210001D
53100220001D
53100230001D
53100240001D
PU
200
200
200
100
100
100
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
50
Stranded with Ferrule 0.14 mm²
min
Stranded with Ferrule 1.5 mm²
max
Dimensions
Stripped Length
PCB Hole Diameter
Materials
Solder Tag
Tension Spring
Copper Alloy
Stainless Steel
6.0 mm
1.0 mm
Colours
PEBBLE GREY
21
RAL7032
RAL7032
22
23
24
Colours according to RAL, there may be variations on colour due to production conditions.
Special colours on request.
Accessories
Figure
Designation
Bridge, 2-pole, insulated, BRI/2-5.0/5.08-
LIGHT GREY
Article Number
50000000006
Bridge, 3-pole, insulated, BRI/3-5.0/5.08-
LIGHT GREY
50000000007
Bridge, 2-pole, BR/2-5.0/5.08-L7.0
50000000008
Ratings
Usegroup
Rated Voltage
Rated Current
Rated Wire Size
solid
stranded
Test Voltage
B
300 V
16 A
AWG 28-14
AWG 28-14
1.6 kV
C
-
-
-
-
-
D
300 V
10 A
AWG 28-14
AWG 28-14
1.6 kV
min
0.5 mm²
0.5 mm²
250 V
24 A
max
2.5 mm²
2.5 mm²
2.0 kV
Test/Measurement
