Product Family Data Sheet
LH351A
-
3535 Ceramic LED
@
25
℃
Introduction
Features
Package : Ceramic Substrate LED Package
View Angle: 125
˚
Precondition : JEDEC Level 2a
Dimension : 3.5 x 3.5 x 1.89 mm
ESD withstand Voltage : up to ±5KV [HBM]
Reliability Test : IES-LM-80-08 qualified
Applications
INDOOR LIGHTING : Spot light, Down light
OUTDOOR LIGHTING : Street light, Security light, Tunnel light, Parking lots light
INDUSTRIAL LIGHTING : High-bay light, Low-bay light
CONSUMER LIGHTING : Torch light
SAMSUNG ELECTRONICS
95, Samsung2-Ro, Giheung-Gu,
Yongin-City, Gyeonggi-Do 446-711, KOREA
Copyright © 2009-2011 SAMSUNG ELECTRONICS Co.,Ltd. All rights reserved. The information in this document is subject to
change without notice. SAMSUNG,
is a registered trademark of SAMSUNG ELECTRONICS.
http://www.samsungled.com
1 / 27
Contents
1. Luminous Flux Characteristics
2. Characteristics
3. Typical Characteristics Graph
4. Outline Drawing & Dimension
-----------------------
-----------------------
-----------------------
3
6
7
----------------------- 13
5. Reliability Test Items and Conditions ----------------------- 14
6. Solder Conditions
7. Tape & Reel
8. Label Structure
9. Packing Structure
10. Precaution For Use
11. Hazard Substance Analysis
12
Revision History
----------------------- 15
----------------------- 16
----------------------- 17
----------------------- 18
----------------------- 20
----------------------- 22
----------------------- 27
http://www.samsungled.com
2 / 27
1. Luminous Flux Characteristics (T
j
= 25
℃
)
Sorting condition
Nominal Minimum
CCT
CRI
1)
Flux
2)
@350mA
Rank
Min Flux
2)
Calculated Minimum Flux
3)
Product Code
@700mA
@1000mA
@1500mA
SPHWHTL3D305E6W0G4
SPHWHTL3D305E6WUG4
G4
100
182
244
334
SPHWHTL3D305E6WPG4
SPHWHTL3D305E6WMG4
80
SPHWHTL3D305E6W0H3
SPHWHTL3D305E6WUH3
H3
110
200
268
368
SPHWHTL3D305E6WPH3
SPHWHTL3D305E6WMH3
SPHWHTL3D307E6W0E6
SPHWHTL3D307E6WUE6
2700K
E6
80
146
195
267
SPHWHTL3D307E6WPE6
SPHWHTL3D307E6WME6
SPHWHTL3D307E6W0F5
SPHWHTL3D307E6WUF5
90
F5
90
164
219
301
SPHWHTL3D307E6WPF5
SPHWHTL3D307E6WMF5
SPHWHTL3D307E6W0G4
SPHWHTL3D307E6WUG4
G4
100
182
244
334
SPHWHTL3D307E6WPG4
SPHWHTL3D307E6WMG4
SPHWHTL3D303E6V0H5
H5
110
200
268
368
SPHWHTL3D303E6VPH5
SPHWHTL3D303E6V0J4
3000K
70
J4
120
218
293
401
SPHWHTL3D303E6VPJ4
SPHWHTL3D303E6V0K3
K3
130
237
317
434
SPHWHTL3D303E6VPK3
Quater
Quater
Whole
Quater
Whole
Quater
M3
Whole
Quater
M3
Whole
Half
Quater
M3
Whole
Half
Quater
M3
Whole
Half
Whole
Half
Quater
M3
BIN
Structure
Whole
Half
http://www.samsungled.com
3 / 27
1. Luminous Flux Characteristics (T
j
= 25
℃
) (Continued)
Sorting condition
Nominal Minimum
CCT
CRI
1)
Flux
2)
@350mA
Rank
Calculated Minimum Flux
3)
Product Code
@1000mA
@1500mA
SPHWHTL3D305E6V0G4
SPHWHTL3D305E6VUG4
G4
100
182
244
334
SPHWHTL3D305E6VPG4
SPHWHTL3D305E6VMG4
3000K
80
SPHWHTL3D305E6V0H3
SPHWHTL3D305E6VUH3
H3
110
200
268
368
SPHWHTL3D305E6VPH3
SPHWHTL3D305E6VMH3
SPHWHTL3D305E6U0G4
SPHWHTL3D305E6UUG4
G4
100
182
244
334
SPHWHTL3D305E6UPG4
SPHWHTL3D305E6UMG4
3500K
80
SPHWHTL3D305E6U0H3
SPHWHTL3D305E6UUH3
H3
110
200
268
368
SPHWHTL3D305E6UPH3
SPHWHTL3D305E6UMH3
K3
70
M2
140
254
341
468
SPHWHTL3D303E6T0M2
SPHWHTL3D305E6T0G4
SPHWHTL3D305E6TUG4
G4
100
182
244
334
SPHWHTL3D305E6TPG4
SPHWHTL3D305E6TMG4
SPHWHTL3D305E6T0H3
4000K
SPHWHTL3D305E6TUH3
80
H3
110
200
268
368
SPHWHTL3D305E6TPH3
SPHWHTL3D305E6TMH3
SPHWHTL3D305E6T0J2
SPHWHTL3D305E6TUJ2
J2
120
218
293
401
SPHWHTL3D305E6TPJ2
SPHWHTL3D305E6TMJ2
Quater
M3
Quater
M3
Whole
Half
Half
Quater
M3
Whole
Whole
Whole
Half
130
237
317
434
SPHWHTL3D303E6T0K3
Quater
M3
Whole
Whole
Half
Quater
M3
Quater
M3
Whole
Half
Whole
Half
Quater
M3
BIN
Structure
Whole
Half
Min Flux
2)
@700mA
http://www.samsungled.com
4 / 27
1. Luminous Flux Characteristics (T
j
= 25
℃
) (Continued)
Sorting condition
Nominal Minimum
CCT
CRI
1)
Flux
2)
@350mA
Calculated Minimum Flux
3)
Product Code
@1000mA
293
317
341
293
317
293
317
341
293
317
293
317
341
293
317
@1500mA
401
434
468
401
434
401
434
468
401
434
401
434
468
401
434
SPHWHTL3D303E6RTJ4
SPHWHTL3D303E6RTK3
SPHWHTL3D303E6RTM2
SPHWHTL3D304E6RTJ4
SPHWHTL3D304E6RTK3
SPHWHTL3D303E6QTJ4
SPHWHTL3D303E6QTK3
SPHWHTL3D303E6QTM2
SPHWHTL3D304E6QTJ4
SPHWHTL3D304E6QTK3
SPHWHTL3D303E6PTJ4
SPHWHTL3D303E6PTK3
SPHWHTL3D303E6PTM2
SPHWHTL3D303E6N0J4
SPHWHTL3D303E6N0K3
BIN
Structure
half
half
half
half
half
half
half
half
half
half
half
half
half
Whole
Whole
Rank Min Flux
2)
@700mA
J4
120
130
140
120
130
120
130
140
120
130
120
130
140
120
130
218
237
254
218
237
218
237
254
218
237
218
237
254
218
237
70
5000K
75
K3
M2
J4
K3
J4
70
5700K
75
K3
M2
J4
K3
J4
6500K
70
K3
M2
J4
7600K
68
K3
Notes:
1) SAMSUNG ELECTRONICS maintains a tolerance of ±3.0 on CRI measurements.
2) SAMSUNG ELECTRONICS maintains a tolerance of ±7% on flux measurements.
3) Calculated flux values are for reference only.
http://www.samsungled.com
5 / 27
