1
TM
SUSSEX
1.0 AMP
BRIDGE RECTIFIERS
12251 TOWNE LAKE DRIVE, FORT MYERS, FLORIDA, 33913 TEL: (239) 768-6800 FAX: (239) 768-6868
SEMICONDUCTOR, INC.
SINGLE - PHASE BRIDGE RECTIFIER
REVERSE VOLTAGES - 50 TO 1000 VOLTS
FORWARD CURRENT - 1.0 AMPS
1.0 AMP BRIDGE RECTIFIER
SPECIFICATIONS
♦
Plated Leads Guarantee Excellent Solderability
♦
Molded Plastic Case
♦
Typical Leakage Current Less Than .1µA
♦
Ideal For Printed Circuit Boards
♦
Polarity Indicated By Solvent Resistant Marking
♦
Operating Temperature: -55 to 150°C
♦
Storage Temperature: -55 to 150°C
♦
High Isolation Resistance From Case To Leads
TABLE 1A - STANDARD DEVICE ELECTRICAL SPECIFICATIONS
(NOTE 1)
MAX.
MAX. LEAKAGE
MAX. INSTANTANEOUS
AVERAGE
CURRENT
FORWARD VOLTAGE PER
FORWARD
I
R
@ V
DC
BRIDGE ELEMENT
RECTIFIED
FORWARD
PEAK
OUTPUT
FORWARD
CURRENT VOLTAGE TEST
V
DC
I
R
T
CASE
=55 °C CURRENT (I
F
) VOLTAGE @ I
F
AMPS
VOLTS
VOLTS
µ
A
AMPS
1.0
1.0
1.1
50
1.0
1.0
1.1
100
1.0
1.0
1.1
200
1.0
1.0
1.1
400
1.0
1.0
1.1
600
1.0
1.0
1.1
800
1.0
1.0
1.1
1000
PEAK
MAX.
MAX.
FORWARD RECURRENT
RMS
PEAK
SURGE
INPUT
REVERSE
CURRENT
VOLTAGE
VOLTAGE
(NOTE 2)
(V
RMS
)
(V
)
RRM
SUSSEX
PART
NUMBER
AMPS
5
5
5
5
5
5
5
50
50
50
50
50
50
50
VOLTS
VOLTS
BDG-D1.0-50
BDG-D1.0-100
BDG-D1.0-200
BDG-D1.0-400
BDG-D1.0-600
BDG-D1.0-800
BDG-D1.0-1000
NOTE 1
♦ELECTRICAL
CHARACTERISTICS MEASURED AT 25°C UNLESS OTHERWISE STATED.
NOTE 2
♦PEAK
FORWARD SURGE CURRENT MEASURED FROM A SINGLE SINE-WAVE BEING SUPERIMPOSED ON THE
RATED LOAD (JEDEC METHOD).
NOTES
5
50
100
200
400
600
800
1000
35
70
140
280
420
560
700
