3610TR22K

Description
1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, SMD
CategoryPassive components    inductor
File Size100KB,1 Pages
ManufacturerTE Connectivity
Websitehttp://www.te.com
Download Datasheet Parametric Compare View All

3610TR22K Overview

1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, SMD

3610TR22K Parametric

Parameter NameAttribute value
MakerTE Connectivity
Reach Compliance Codeunknown
ECCN codeEAR99
DC Resistance1.84 Ω
Nominal inductance(L)0.22 µH
Inductor ApplicationsRF INDUCTOR
Inductor typeGENERAL PURPOSE INDUCTOR
Manufacturer's serial number3610
Number of functions1
Number of terminals2
Minimum quality factor (at nominal inductance)10
Maximum rated current0.17 A
self resonant frequency500 MHz
Shape/Size DescriptionRECTANGULAR PACKAGE
shieldNO
surface mountYES
Terminal locationDUAL ENDED
Terminal shapeWRAPAROUND
Test frequency25.2 MHz
Tolerance10%
Base Number Matches1
C orporate Hom e
|
Electronic Components
|
Se gm e nts
|
W ho W e Are
My Account
Searc h
Products
Documentation
Resources
My Account
Customer Support
Home
>
Products
>
By Type
>
Passive C omponents
>
Product Feature Selector
> Product Details
3610TR22K Product Details
Live Product Chat
Inductors
C onve rte d to EU R oHS/ELV C om plia nt
(
Sta te m e nt of C om plia nce
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
3610TR22K
(1624099-9)
T E I nternal N umber: 1 6 2 4 0 9 9 - 9
Product Highlights:
l
Inductor
l
Inductor Type = Molded Wirewound
l
Lead Type = Surface Mount Terminals
l
Wirewound
l
Inductance = .22 ?H
View all Features
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Active
Buy P roduc t
Documentation & Additional Information
Product Drawings:
l
0805 MOULDED C HIP INDUC TOR SERIES 3610T
(PDF, English)
Catalog Pages/Data Sheets:
l
0805 Moulded C hip Inductor - Type 3610 Series - Tyco...
(PDF, English)
Product Specifications:
l
None Available
Application Specifications:
l
None Available
Instruction Sheets:
l
None Available
CAD Files:
l
None Available
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Product Type
= Inductor
l
Inductor Type = Molded Wirewound
l
Element
= Wirewound
l
Shielded
= No
Electrical Characteristics:
l
Inductance (?H)
= 0.22
l
DC Resistance (?)
= 1.84
l
C urrent, Maximum (mA)
= 170
l
Quality Factor
= 10
l
Package Type
= Taped and Reeled
l
Tolerance (%) = 10
Body Related Features:
l
Lead Type
= Surface Mount Terminals
l
Series
= 3610
l
Packaging Style
= 0805
l
Package, C omponent Size
= 2.0 x 1.25
l
Mount Style
= Surface Mount
Industry Standards:
l
RoHS/ELV C ompliance
= RoHS compliant, ELV compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C
l
RoHS/ELV C ompliance History = C onverted to comply with RoHS
directive
Operation/Application:
l
Application
= Standard
Other:
l
Brand = Sigma Inductors
Additional Information:
l
Product Line Information
Related Products:
l
Tooling
Provide Website Feedback
|
Need Help?
Home
|
C ustomer Support
|
Suppliers
|
Site Map
|
Privacy Policy
|
Browser Support
©
2009 Tyco Electronics C orporation All Rights Reserved

3610TR22K Related Products

3610TR22K 1624099-9
Description 1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, SMD 1 ELEMENT, 0.22uH, GENERAL PURPOSE INDUCTOR, SMD, CHIP, 0805, ROHS COMPLIANT
Reach Compliance Code unknown unknown
ECCN code EAR99 EAR99
DC Resistance 1.84 Ω 1.84 Ω
Nominal inductance(L) 0.22 µH 0.22 µH
Inductor type GENERAL PURPOSE INDUCTOR GENERAL PURPOSE INDUCTOR
Manufacturer's serial number 3610 3610
Number of functions 1 1
Number of terminals 2 2
Minimum quality factor (at nominal inductance) 10 10
Maximum rated current 0.17 A 0.17 A
Shape/Size Description RECTANGULAR PACKAGE RECTANGULAR PACKAGE
shield NO NO
surface mount YES YES
Terminal location DUAL ENDED DUAL ENDED
Terminal shape WRAPAROUND WRAPAROUND
Tolerance 10% 10%
