22142523 Product Details
Impact High Density Backplane Connectors
Always EU RoHS/ELV Compliant
(
Statement of Compliance
)
Product Highlights:
Connector Style = Receptacle
120/Signal, 60/Ground
180 Positions
BoardtoBoard Configuration = Orthogonal, Right Angle
Number of Differential Pairs Per Column = 6
View all Features
Share
Print
Email
Quick Links
Pricing & Availability
Search for Tooling
Product Feature Selector
Contact Us About This Product
22142523
TE Internal Number: 22142523
Active
Add to My Part List
Request Sample
Find Similar Products
Buy Product
View 3D PDF
Documentation & Additional Information
Product Drawings:
None Available
Catalog Pages/Data Sheets:
None Available
Product Specifications:
None Available
Application Specifications:
None Available
Instruction Sheets:
None Available
CAD Files: (CAD Format & Compression Information)
2D Drawing (DXF, Version A)
3D Model (IGES, Version A)
3D Model (STEP, Version A)
Related Products:
Tooling
List all Documents
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
PCB Mount Retention Type = Action/Compliant Tail, None
Electrical Characteristics:
Impedance (Ω) = 85
Operating Voltage Reference = AC/DC
Operating Voltage (VAC) = 120
Operating Voltage (VDC) = 120
Dimensions:
Tail Length (mm [in]) = 1.2 [0.047]
Length (XAxis) (mm [in]) = 20.25 [0.797]
Width (ZAxis) (mm [in]) = 37.30 [1.469]
Profile Height (YAxis) (mm [in]) = 25.40 [1.000]
PCB Hole Diameter (mm [in]) = 0.39 [0.015]
Contact Features:
Contact Type = Socket
Contact Plating, Termination Area, Material = Matte Tin
Contact Plating, Termination Area, Thickness (µm [μin]) = 1.27 [50]
Contact Base Material = CopperNickelSilicon
Underplate Material = Nickel
Underplate Material Thickness (µm [μin]) = 1.27 [50.000]
Housing Features:
Connector Style = Receptacle
Housing Color = Gray
Housing Material = Liquid Crystal Polymer (LCP)
Industry Standards:
RoHS/ELV Compliance = RoHS compliant, ELV compliant
Lead Free Solder Processes = Not reviewed for lead free solder
process
RoHS/ELV Compliance History = Always was RoHS compliant
UL Rating = Recognized
UL File Number = E28476
UL Flammability Rating = UL 94V0
CSA Certified = Yes
Environmental:
Operating Temperature (°C [°F]) = 55 – +85 [67 – +185]
Conditions for Usage:
BoardtoBoard Configuration = Orthogonal, Right Angle
Operation/Application:
Industry Application = Networking (Communications)
Packaging Features:
Packaging Method = Tube
Other:
Brand = TE Connectivity
Configuration Features:
Connector Contact Configuration (No. of Pos./Type) = 120/Signal,
60/Ground
Number of Positions = 180
Number of Differential Pairs Per Column = 6
Number of Columns = 10
Number of Rows = 18
Guide Location = Unguided
Tail Orientation = Inline
