IP Rating............................................................. IP 40 .....................................................................IP 40
*RoHS Directive 2002/95/EC Jan 27, 2003 including Annex.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
Model 97 & 99
-
5/8 ” Square Single-Turn Panel Control with Rotary Switch
Potentiometer Specifications
Mechanical Characteristics
1
Stop Strength (1/4 ” D shaft) .............................................................................................................................................45.19 N-cm (4 lb.-in.)
(1/8 ” D shaft) .............................................................................................................................................33.89 N-cm (3 lb.-in.)
Starting ........................................................................................................................................... 0.3 max. above average running torque
Running Torque
Single or Dual Section (A & R Bushings) .................................................................................................. 0.21 to 1.06 N-cm (0.3 to 1.5 oz.-in.)
Single or Dual Section (C & U Bushings) .................................................................................................. 0.14 to 1.06 N-cm (0.2 to 1.5 oz.-in.)
Mounting .............................................................................................................................................1.7-2.0 N-m (15-18 lb.-in.) maximum
Variation ...................................................................................................................... 0.35 N-cm (0.5 oz.-in.) maximum in 45 ° shaft travel
Weight (Single Section, Metal Bushing)...............................................................................................................................12.7 grams nominal
Terminals .................................................................................................................................Printed circuit terminals, J-Hooks or solder lugs
Soldering Condition ...........................................Recommended hand soldering using Sn95/Ag5 no clean solder, 0.025 ” wire diameter.
Maximum temperature 399 °C (750 °F) for 3 seconds. No wash process to be used with no clean flux.
Marking ..................................................................................Manufacturer’s trademark, date code, resistance, manufacturer’s part number
Ganging (Multiple Section Potentiometers).............................................................................................................................2 cups maximum
Hardware ...................One lockwasher and one mounting nut is shipped with each potentiometer, except where noted in the part number.
NOTE:
1
At
Performance specifications do not apply to units subjected to printed circuit board cleaning procedures.
room ambient: +25 °C nominal and 50 % relative humidity nominal, except as noted.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
Model 97 & 99
-
5/8 ” Square Single-Turn Panel Control with Rotary Switch
Rotary Switch Specifications
Initial Electrical Characteristics
1
Contacts:
DPST ........................................................................................................................................................N.O/N.O., N.C./N.C. or N.O./N.C.
DPDT ..........................................................................................................................................................2 N.O./N.C. (break before make)
Power Rating (Resistive Load):
DPST ..................................................................................... 2 A @ 125 volts RMS-60 Hz or 2 A @ 28 VDC, 1 A @ 250 volts RMS-60 Hz
DPDT .....................................................................................................................................1 A @ 125 volts RMS-60 Hz or 1 A @ 28 VDC
Contact Bounce ...........................................................................................................................................................5 milliseconds maximum
Dielectric Withstanding Voltage (MIL-STD-202, Method 301)
Operating Temperature Range .................................................................................................................................................... 0 °C to +70 °C
Exposure Temperature Range ................................................................................................................................................-65 °C to +125 °C
Vibration (Dual Section).................................................................................................................................................................................. 8 G
Contact Resistance .................................................................................................................................................. 10 milliohms maximum
Contact Bounce ................................................................................................................................................... 0.1 millisecond maximum
Shock (Dual Section).................................................................................................................................................................................... 20 G
Contact Resistance .................................................................................................................................................. 10 milliohms maximum
Contact Bounce ................................................................................................................................................... 0.1 millisecond maximum
Rotational Life ................................................................................................................................................................................25,000 cycles
Switch Actuating Torque (50% Duty cycle @ Rated Power Load) ........................................................... 1.41 to 4.94 N-cm (2 to 7 oz.-in.)
Contact Resistance ................................................................................................................................................ 100 milliohms maximum
Moisture Resistance (MIL-STD-202, Method 106, Condition B)
Contact Resistance (0.1 VDC-10 mA) ..................................................................................................................... 10 milliohms maximum
Housing Material .......................................................................................................High temperature, flame retardant, thermosetting plastic
Mechanical Characteristics
1
Actuating Torque (Each Section, Switch Module Only).............................................................................. 3.53 to 10.59 N-cm (5 to 15 oz.-in.)
Running Torque (Out of Detent, 2-4 Module Assembly) ............................................................................. 0.21 to 1.41 N-cm (0.3 to 2 oz.-in.)
Detent ................................................................................................................................................................................CW or CCW standard
Contact Materials.................................................................................................................................................... Fine silver with gold overlay
Terminal Styles .............................................................................................................................................................................Solder lug only
Standard Orientation ........................................................................................................................................ In-line with control terminals
Optional ....................................................................................................................................................Rotated 90 ° CCW from standard
Terminal Strength (Before and After Soldering Heat Exposure) .................................................................................... 0.9 kg (2 lbs.) minimum
NOTE:
1
At
Performance specifications do not apply to units subjected to printed circuit board cleaning procedures.
room ambient: +25 °C nominal and 50 % relative humidity nominal, except as noted.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
Model 97 & 99
-
5/8 ” Square Single-Turn Panel Control with Rotary Switch
Product Dimensions
Model 97 PC Pin Terminals, “L” Pattern
MOUNTING
SURFACE
L
12.70 ± .229
(.500 ± .009)
0.79 ± .025
(.031 ± .010)
DIA.
13.72 ± 0.38
(.540 ± .015)
1.37 ± 0.08
(.054 ± .003)
2.36 ± 0.08
(.093 ± .003)
15.88
(.625)
7.92
(.312)
SEE
HOW TO ORDER
CHART FOR
BUSHING OPTIONS.
DIA.
0.81
TYP.
(.032)
5.08 ± 0.38
(.200 ± .015)
11.05 ± 0.20
(.435 ± .008)
R1
1.19
(.047)
“A” STYLE
A.R. LUG
R
9.53
(.375)
12.7 ± 1.02
(.500 ± .040)
2.54
(.100)
2.54
(.100)
0.76 ± 0.05
(.030 ± .002)
TYP.
1
3
2
SEE
NEXT PAGE
FOR SHAFT
OPTIONS.
Model 99 Solder Lug Terminals, "Triangular" Pattern
