Thick Film Chip Resistors
Features:
•
Small size and lightweight
•
Suitable for both flow and reflow soldering
•
Reduction of assembly costs and matching with placement machines
Standard
: 2, 5 and 10% - A series
: 1%
- B series
Performance Specifications:
Temperature Coefficient
: 1
Ω
to 10
Ω ≤
±400 PPM/°C
11
Ω
to 100
Ω ≤
±200 PPM/°C
> 100
Ω ≤ ±100
PPM/°C (0201 > 100
Ω ≤
±200 PPM/°C)
: ±5% : ± (2% + 0.1
Ω)
Max.
±1% : ± (1% + 0.1
Ω)
Max.
: 1,000 MΩ
: No evidence of flashover, mechanical damage, arcing or insulation breakdown
: ± (1% + 0.05
Ω)
Max.
: Resistance change rate is ± (1% + 0.05
Ω)
Max.
: 95% coverage
: ±5% : ± (1% + 0.05
Ω)
Max.
±1% : ± (0.5% + 0.05
Ω)
Max.
: ±5% : ± (3% + 0.1
Ω)
Max.
±1% : ± (0.5% + 0.1
Ω)
Max.
: ±5% : ± (3% + 0.1
Ω)
Max.
±1% : ± (1% + 0.1
Ω)
Max.
: ±5% : ± (3% + 0.1
Ω)
Max.
±1% : ± (1% + 0.1
Ω)
Max.
Short-time Overload
Minimum Insulation Resistance
Dielectric Withstanding Voltage
Terminal Bending
Soldering Heat
Minimum Solderability
Temperature Cycling
Humidity (Steady State)
Load Life in Humidity
Load Life
Construction
Power Rating and Dimension
www.element14.com
www.farnell.com
www.newark.com
Page <1>
06/01/12 V1.1
Thick Film Chip Resistors
Power
Max.
Max.
Operating
Rating
Tolerance Resistance Standard
Type
Working Overload Temperature
%
Range
Series
at
Voltage Voltage
(ºC)
70ºC
Jumper
0402 1/16 W
1A
50 V
2A
100 V
-55 to +155
±1
±2
±5
Jumper
0603
1/10 W-S
1/16 W
1A
50 V
2A
100 V
-55 to +155
±1
±2
±5
Jumper
1/ 8 W-S
0805
1/10 W
2A
150 V
4A
300 V
-55 to +155
±1
±2
±5
Jumper
1206
1/4 W-S
1/8 W
2A
200 V
4A
400 V
-55 to +155
±1
±2
±5
Jumper
1210
1/3 W-S
1/4 W
2A
200 V
4A
400 V
-55 to +155
±1
±2
±5
Jumper
3/4 W-S
2010
1/2 W
2A
200 V
4A
400V
-55 to +155
±1
±2
±5
Jumper
2512
1W
2.5 A
200 V
5A
400 V
-55 to +155
±1
±2
±5
< 50 mΩ
10
Ω
- 1 MΩ
1
Ω
-1 MΩ
1
Ω
-1 MΩ
< 50 mΩ
10
Ω
- 1 MΩ
1
Ω
-1 MΩ
1
Ω
-1 MΩ
< 50 mΩ
10
Ω
- 1 MΩ
1
Ω
-1 MΩ
1
Ω
-1 MΩ
< 50 mΩ
10
Ω
- 1 MΩ
1
Ω
-1 MΩ
1
Ω
-1 MΩ
< 50 mΩ
10
Ω
- 1 MΩ
1
Ω
-1 MΩ
1
Ω
-1 MΩ
< 50 mΩ
10
Ω
- 1 MΩ
1
Ω
-1 MΩ
1
Ω
-1 MΩ
< 50 mΩ
10
Ω
- 1 MΩ
1
Ω
-1 MΩ
1
Ω
-1 MΩ
B
A
A
B
A
A
B
A
A
B
A
A
B
A
A
B
A
A
B
A
A
Dimension (mm)
L
W
H
1 ±0.1
0.5 ±0.05
0.35
±0.05
0.2 ±0.1
0.25
±0.1
+0.15
1.6 ±0.1 0.8
-0.1
0.45
±0.1
0.3 ±0.2
0.3
±0.2
+0.15
2 ±0.15 1.25
-0.1
0.55
±0.1
0.4 ±0.2
0.4
±0.2
3.1
±0.15
+0.15
1.55
-0.1
0.55
±0.1
0.45 ±0.2
0.45
±0.2
3.1 ±0.1 2.6 ±0.15
0.55
±0.1
0.5 ±0.25
0.5
±0.2
5 ±0.1
2.5 ±0.15
0.55
±0.1
0.6 ±0.25
0.5
±0.2
6.35
±0.1
3.2 ±0.15
0.55
±0.1
0.6 ±0.25
0.5
±0.2
www.element14.com
www.farnell.com
www.newark.com
Page <2>
06/01/12 V1.1
Thick Film Chip Resistors
Derating Curve
Percentage Rated Load (%)
Ambient Temperature (°C)
Multiplier Code (for 0603 1% marking)
Code
Multiplier
A
10
0
B
10
1
C
10
2
D
10
3
E
10
4
F
10
5
G
10
6
H
10
7
X
10
-1
Y
10
-2
Z
10
-3
Standard B Series Resistance Value Code (for 0603 1% marking)
Ω
Value
100
102
105
107
110
113
115
118
121
124
127
130
133
137
140
143
147
150
154
158
www.element14.com
www.farnell.com
www.newark.com
Code
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
19
20
Ω
Value
162
165
169
174
178
182
187
191
196
200
205
210
215
221
226
232
237
243
249
255
Code
21
22
23
24
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
Ω
Value
261
267
274
280
287
294
301
309
316
324
332
340
348
357
365
374
383
392
402
412
Code
41
42
43
44
45
46
47
48
49
50
51
52
53
54
55
56
57
58
59
60
Ω
Value
422
432
442
453
464
475
487
499
511
523
536
549
562
576
590
604
619
634
649
665
Code
61
62
63
64
65
66
67
68
69
70
71
72
73
74
75
76
77
78
79
80
Ω
Value
681
698
715
732
750
768
787
806
825
845
866
887
909
931
953
976
Code
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
-
-
-
-
-
-
-
-
Page <3>
06/01/12 V1.1
Thick Film Chip Resistors
Marking on the Resistors Body:
•
For 0402 size, no marking on the body due to the small size of the resistor.
•
±5% tolerance product. (Including resistance values less than 1
Ω;
both 1% and 5%) The marking is 3 digits, the first 2 digits are
the significant figures of the resistance and the 3rd digit denotes number of zeros.
Ω
153 = 15,000
Ω
= 15 KΩ 120 = 12
Ω
Below 10
Ω
shown as this: 6R8 = 6.8
Ω
0.1
Ω
to 0.99
Ω
shown as this: R33 = 0.33
Ω
•
±1% tolerance marking of case size 0805 and bigger is 4 digits, the first 3 digits are the significant figures of the resistance and the
4th digit denotes number of zeros.
Ω
2372 = 23700
Ω
= 23.7 KΩ
;
1430 = 143
Ω
0.1
Ω
to 0.99
Ω
shown as this: R33 = 0.33
Ω
Below 10
Ω
shown as this: 3R24 = 3.24
Ω
•
Standard B series values (±1% tolerance) of 0603 size. Due to the small size of the resistor’s body, 3 digits marking will be used to
indicate the accurate resistance value by using the Multiplier code & Standard B Series Resistance Value Code.
12.4
Ω
= 124 × 10
-1
Ω
= 10X
Ω
1.96 KΩ = 196 × 10
1
Ω
= 29B
•
Standard A series values which does not belong to B series values (in ±1% tolerance) of 0603 size
The marking is the same as 5% tolerance but marked with underline.
Ω
122 = 1200 = 1.2 KΩ
680 = 68
Ω
Part Number Table
Description
Thick Film Resistor
Thick Film Resistor
Thick Film Resistor
Thick Film Resistor
Thick Film Resistor
Thick Film Resistor
Thick Film Resistor
Part Number
MC0402WG00000TCE-TC
MC0603SAF0000T5E
MC0805S8F0000T5E
MC1206S4F0000T5E
MC1210S3F1000T5E
MC2010W2F0000T4E
MC25121WF1000T4E
www.element14.com
www.farnell.com
www.newark.com
Page <4>
06/01/12 V1.1
Thick Film Chip Resistors
Part Number Explanation
MC1206
S4
F
0000
T
5
E
Resistor Type
Chip resistor types
Normal size
Small size
Resistance Value
Wattage
Tolerance
Resistance Value
Packing Type
Packing Quantity
Special Feature
: 0402, 0603, 0805, 1206, 1210, 2010, 2512
: WG=1/16W, W2=1/2W, 1W=1W
: SA=1/10W-S, S8=1/8W-S, S4=1/4W-S, S3=1/3W-S
: A-series :
1
st
digit is “0”
2
nd
& 3
rd
digits are significant figures of the resistance
4
th
indicate the number of zeros
: B-series :
1
st
to 3
rd
digits are significant figures of the resistance
4
th
digit indicate the number of zeros “J” to 0.1, “K” to 0.01, “L” to 0.001
Ex. 012J to 1
Ω2,
226K to 2
Ω26
Jumper : use “0” for 1
st
to 4
th
digits
: 0 = Jumper, F = ±1%
: T = Tape / reel
: 4 = 4,000 pieces, 5 = 5,000 pieces, C = 10,000 pieces
: E = lead (Pb) free plating type
Tolerance
Packing Type
Packing Quantity
Special Feature
Important Notice :
This data sheet and its contents (the "Information") belong to the members of the Premier Farnell group of companies (the "Group") or are licensed to it. No licence is granted for the use of
it other than for information purposes in connection with the products to which it relates. No licence of any intellectual property rights is granted. The Information is subject to change without notice and replaces
all data sheets previously supplied. The Information supplied is believed to be accurate but the Group assumes no responsibility for its accuracy or completeness, any error in or omission from it or for any use
made of it. Users of this data sheet should check for themselves the Information and the suitability of the products for their purpose and not make any assumptions based on information included or omitted.
Liability for loss or damage resulting from any reliance on the Information or use of it (including liability resulting from negligence or where the Group was aware of the possibility of such loss or damage arising)
is excluded. This will not operate to limit or restrict the Group's liability for death or personal injury resulting from its negligence. Multicomp is the registered trademark of the Group. © Premier Farnell plc 2012.
www.element14.com
www.farnell.com
www.newark.com
Page <5>
06/01/12 V1.1
