BAS70TW /DW-04 /
DW-05 /DW-06 /BRW
200mW
SCHOTTKY BARRIER
Diode
SOT-363
Features
•
•
•
•
Fast Switching
Low Forward Voltage Drop
Low Power Dissipation
Ultra-Small Surface Mount Package
Case Material: Molded Plastic. UL Flammability
Classification Rating 94V-0
and MSL Rating 1
Maxim um Ratings
Symbol
V
RRM
V
RWM
V
R
I
F
I
FSM
R
©
JA
P
D
T
STG&
T
J
Rating
Peak Repetitive Reverse Voltage
Working Peak Reverse Voltage
DC Blocking Voltage
Forward Continuous Current
Peak Forward Surge Current @<1.0s
Thermal Resistance Junction to Ambient
Power dissipation
Storage &Operating JunctionTemperature
Rating
70
70
100
625
200
-55 to +125
Unit
V
mA
mA
/W
mW
K
G
B
C
A
H
M
J
D
L
NEW PRODUCT
Electrical Characteristics @ 25
O
C Unless Otherwise Specified
Symbol
I
R
Parameter
Reverse Voltage Leakage
Current
Min
---
Max
100nA
Test Conditions
V
R
=50V
DIM
A
B
C
D
G
H
J
K
L
M
INCHES
MIN
.006
.045
.085
.026
.047
.071
---
.035
.010
.003
DIMENSIONS
MM
MIN
MAX
0.15
0.35
1.15
1.35
2.15
2.45
0.65Nominal
1.20
1.40
1.80
2.20
---
0.10
0.90
1.10
0.26
0.46
0.08
0.15
MAX
.014
.053
.096
.055
.087
.004
.043
.018
.006
NOTE
V
F
C
T
t
rr
Forward Voltage
Total Capacitance
Reverse Recovery Time
---
---
---
---
0.41V
1.0V
2pF
5.0ns
I
F
=1mA
I
F
=15mA
V
R
=0V, f=1MHZ
I
F
=I
R
=10mA,
I
rr
=0.1XI
R
,R
L
=100
A
1
C
2
C
2
C
1
A
2
A
2
AC
1
C
2
A
2
AC
1
C
1
C
2
C
1
C
2
C
3
C
1
C
1
A
2
A
1
A
1
C
2
A
1
C
1
AC
2
A
1
A
2
AC
2
A
1
A
2
A
3
BAS70DW-06
Marking: K76
BAS70DW-05
Marking: K71
BAS70DW-04
Marking: K74
BAS70BRW
Marking: K75
BAS70TW
Marking: K73
Revision:
4
www.mccsemi.com
1 of 3
2008/12/31
BAS70TW/DW-04/DW-05/DW-06/BRW
I
F
, INSTANTANEOUS FORWARD CURRENT (mA)
100
T
A
= 125ºC
T
A
= 75ºC
T
A
= 25ºC
MCC
Micro Commercial Components
TM
10
1.0
T
A
= 0ºC
0.1
0
0.2
0.4
T
A
= -40ºC
0.6
0.8
1.0
1.2
1.4
1.6
V
F
, INSTANTANEOUS FORWARD VOLTAGE (V)
Fig. 1 Typical Forward Characteristics
I
R
, INSTANTANEOUS REVERSE CURRENT (nA)
10000
T
A
= 125ºC
1000
T
A
= 75ºC
100
10
T
A
= 25ºC
T
A
= 0ºC
1
T
A
= -40ºC
0.1
0
10
20
30
40
50
60
70
V
R
, REVERSE VOLTAGE (V)
Fig. 2 Typical Reverse Characteristics
1.8
1.6
250
f = 1.0MHz
P
d
, POWER DISSIPATION (mW)
40
C
T
, TOTAL CAPACITANCE (pF)
1.4
1.2
1.0
0.8
0.6
0.4
0.2
0
0
5
10
15
20
25
30
35
200
150
100
50
0
0
100
200
T
A
, AMBIENT TEMPERATURE (
°
C)
Fig. 4 Power Derating Curve, Total Package
V
R
, REVERSE VOLTAGE (V)
Fig. 3 Typical Capacitance
Revision:
4
www.mccsemi.com
2 of 3
2008/12/31
MCC
Micro Commercial Components
TM
Ordering Information
Device
(Part Number)-TP
Packing
Tape&Reel;3Kpcs/Reel
***IMPORTANT NOTICE***
Micro Commercial Components Corp
.
reserves the right to make changes without further notice to any
product herein to make corrections, modifications , enhancements , improvements , or other changes .
Micro Commercial Components Corp
.
does not assume any liability arising out of the application or
use of any product described herein; neither does it convey any license under its patent rights ,nor
the rights of others . The user of products in such applications shall assume all risks of such use
and will agree to hold
Micro Commercial Components Corp
.
and all the companies whose
products are represented on our website, harmless against all damages.
***APPLICATIONS DISCLAIMER***
Products offer by
Micro Commercial Components Corp
.
are not intended for use in Medical,
Aerospace or Military Applications.
www.mccsemi.com
Revision:
4
3 of 3
2008/12/31
