T-1, (3-mm) Round, PCB Mount
Direct View Array, G61XS Series
www.ledidea.com
The G61XS is a T-1 size indicator array designed for direct viewing. The LEDs are located on 4.57 mm(0.18") centers. The G61XS can
be supplied with the desired lamps preassembled from 1 to 9 sections long. (G611S thru G619S) This series provides easier handling
in multiple lamp applications, and can be supplied with any combination of colors. This series can also be supplied with pinout reversed
from that shown by adding “-RL” to the order code of the part number.
1
2
3
...
...
...
...
...
X
3 typ
2.5±.5
6.35
7.4
5.08
2.54
ref
LED 1
Red or
yellow
Anode
+ –
(typ for single color)
2.54(0.10)
2.03(0.08)
typ
typ
Specify part desired as follows:
G61XS/Order Code LED1 + Order Code LED 2 + ... + Order Code LED X
For example:
“G618S/4H+4G” designates an assembly with 4 red LEDs followed by 4 green LEDs.
“G618S/(4H+4G)-RL” designates the same assembly with all pins reversed
Green
Anode
(typ for bi-color)
ORDER CODE AND INFORMATION (ALL RATINGS AT 25°C AMBIENT)
LED Lamp
Epoxy & Type
Color
Hi Eff Red
TInted Diffused
Resistor Required
Green
Yellow
Orange
Hi Eff Red
Tinted Transparent
High Brightness
Green
Yellow
Hi Eff Red
Tinted Diffused
For 2mA Operation
Green
Yellow
Hi Eff Red
Tinted Diffused
5V Operation
Green
Yellow
Red/Green
White Diffused
Bipolar, Bicolor
Yellow/Green
Red/Yellow
Order Code
I
G
Y
O
IT
GT
YT
I2
G2
Y2
I5
G5
Y5
EG
YG
EY
Peak
λ
(nm)
635
565
585
610
635
565
585
635
565
585
635
565
585
635/565
585/565
635/585
Typical Characteristics
Vf
(V)
@If=20mA
2.0
2.1
2.0
2.0
2.0
2.1
2.0
2.0
2.1
2.0
-
-
-
2.0/2.1
2.0/2.1
2.0/2.0
Iv
(mcd)
@If=10mA
10
10
10
10
40
40
40
1.0 @ 2mA
1.0 @ 2mA
1.0 @ 2mA
10
10
10
4/4
4/4
4/4
2
Θ
1/2
(Deg)
60
60
60
60
40
40
40
60
60
60
60
60
60
90
90
90
Recom.
Op. If
(mA)
10-20
10-20
10-20
10-20
10-20
10-20
10-20
2-10
2-10
2-10
5V
5V
5V
10-20
10-20
10-20
* Specifications subject to change without notice. Dimensions are in mm±0.25 unless stated otherwise.
