Peaking Coils - Radial
ctparts.com
SPECIFICATIONS
CTRFB1010F Series
From 12 µH to 18,000 µH
Part
Number
CTRFB1010F-120K
CTRFB1010F-150K
CTRFB1010F-180K
CTRFB1010F-220K
CTRFB1010F-270K
CTRFB1010F-330K
CTRFB1010F-390K
CTRFB1010F-470K
CTRFB1010F-560K
CTRFB1010F-680K
CTRFB1010F-820K
CTRFB1010F-101K
CTRFB1010F-121K
CTRFB1010F-151K
CTRFB1010F-181K
CTRFB1010F-221K
CTRFB1010F-271K
CTRFB1010F-331K
CTRFB1010F-391K
CTRFB1010F-471K
CTRFB1010F-561K
CTRFB1010F-681K
CTRFB1010F-821K
CTRFB1010F-102K
CTRFB1010F-122K
CTRFB1010F-152K
CTRFB1010F-182K
CTRFB1010F-222K
CTRFB1010F-272K
CTRFB1010F-332K
CTRFB1010F-392K
CTRFB1010F-472K
CTRFB1010F-562K
CTRFB1010F-682K
CTRFB1010F-822K
CTRFB1010F-103K
CTRFB1010F-123K
CTRFB1010F-153K
CTRFB1010F-183K
Not shown at actual size.
Parts are available in ±10% tolerance only.
Inductance
(µH ±10%)
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
10000
12000
15000
18000
L Test
Freq.
(kHz)
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
100
DCR
Max.
Ω
(Ω)
.025
.028
.030
.042
.046
.055
.075
.082
.090
.120
.140
.150
.210
.245
.300
.360
.490
.570
.620
.810
.920
1.20
1.35
1.45
2.10
2.40
3.50
4.10
5.20
6.00
7.00
8.50
10.0
13.0
15.8
19.0
22.0
29.0
33.0
SRF
Typ.
(MHz)
20
19
16
15
12
11
10.3
9.5
8.6
7.5
7.0
7.0
6.0
5.0
5.0
4.3
4.0
3.5
3.0
3.0
2.3
2.0
2.0
2.0
1.6
1.4
1.3
1.3
1.2
1.0
0.9
0.8
0.8
0.7
0.6
0.6
0.5
0.5
0.4
Isat
(A)
5.60
5.00
4.60
4.10
3.70
3.40
3.10
2.80
2.60
2.30
2.10
1.90
1.75
1.60
1.45
1.30
1.20
1.10
1.00
0.90
0.80
0.75
0.68
0.60
0.55
0.50
0.45
0.41
0.37
0.34
0.31
0.28
0.26
0.23
0.21
0.19
0.17
0.16
0.14
Irms
20° Rise
(A)
4.00
3.75
3.50
3.30
3.00
2.80
2.60
2.40
2.20
2.00
1.90
1.70
1.60
1.50
1.40
1.30
1.20
1.00
0.90
0.80
0.70
0.60
0.55
0.50
0.47
0.44
0.41
0.38
0.35
0.32
0.29
0.25
0.23
0.19
0.16
0.13
0.12
0.11
0.10
Irms
40° Rise
(A)
5.70
5.40
5.00
4.70
4.40
4.10
3.80
3.50
3.20
2.80
2.50
2.20
2.10
1.90
1.80
1.70
1.60
1.40
1.30
1.20
1.05
0.93
0.80
0.67
0.63
0.59
0.55
0.50
0.47
0.43
0.39
0.35
0.30
0.26
0.22
0.18
0.17
0.15
0.13
Compliant
RoHS
CHARACTERISTICS
Description:
Radial leaded fixed inductor (UL sleeved)
Applications:
Ideal as a choke coil for noise filtering.
Operating Temperature:
-40°C to +85°C
Δ
T:
typically above 25°C ambient.
Inductance Tolerance:
±10%
Inductance Drop:
10% typically at rated Isat
Testing:
Inductance is tested on an HP4284A at 100 kHz,
0.1Vrms
Packaging:
Bulk packaging
Marking:
UL sleeving marked with inductance code
Miscellaneous:
RoHS Compliant.
Additional Information:
Additional electrical & physical
information available upon request
Samples available. See website for ordering information.
PHYSICAL DIMENSIONS
Size
mm
inches
A
Max.
11.0
0.43
B
Max.
11.5
0.45
C
4.0±0.5
0.16±0.02
D
6.0±0.5
0.24±0.02
E
0.8
0.031
UL TUBE
A
D
B
C
øE
08.06.07
Technologies
Manufacturer of Passive and Discrete Semiconductor Components
800-684-5322
Inside US
949-453-1811
Outside US
Copyright © 2007 by CT Magnetics, DBA Central Technologies. All rights reserved.
CT Magnetics reserves the right to make improvements or change specifications without notice
