DATASHEET
3-Phase Filters FN 3287 and FN 3288
Smallest book-style EMC/RFI Filter for Inverter and Power Drive Systems
Standard and high performance EMC solution
Footprint space-saving book-style housing
Solid safety connector blocks
Standard attenuation performance FN 3287
High attenuation performance FN 3288
HV versions for 690 VAC applications
HVIT- and IT versions for IT distribution
networks
Versions with low leakage current
Approvals
600 VAC
Features and benefits
FN 3287 and FN 3288 series of filters provides state-
of-the-art EMI attenuation based on an innovative
filter topology. They help to ensure compliance with
Class C2 or even C1 limits.
The slim book-style shape allows a convenient and
space-saving installation next to inverters,
converters or motor drives.
The compact FN3287 and FN3288 filter from 10 to
160A are designed for the most diverse applications
worldwide, including machinery and machine tools.
FN 3288 HV filters up to 160 A are applicable for 690
VAC distribution networks.
10
Performance indicators
FN 3288IT and FN 3288HVIT filters up to 160 A meet
the special requirements for IT distribution
networks.
Low leakage current filter versions help to fulfill
tough requirements (<3.5 mA) in respect of leakage
current limitation.
Technical specifications
Maximum continuous operating voltage
3x 530/305 VAC (FN 3287, FN 3288)
3x 530 VAC (FN 3288 IT )
3x 760/440 VAC (FN 3288 HV)
3x 760 VAC (FN 3288 HVIT )
10 to 160 A @50°C
DC to 60 Hz
P -> E 2260 VDC for 2 s (FN 3287, FN 3288)
P -> E 2900 VDC for 2 s (FN 3288 IT )
P -> P 2280 VDC for 2 s (FN 3287, FN 3288, FN 3288 IT )
P -> E 2650 VDC for 2 s (FN 3288 HV)
P -> E 3530 VDC for 2 s (FN 3288 HVIT )
P -> P 3270 VDC for 2 s (FN 3288 HV)
II acc. IEC 60664-1
2 acc. IEC 60664-1
IP 20 acc. to IEC 60529
6x rated current for 1 sec, once per hour
1.5x rated current for 1 minute, once per hour
-40°C to +100°C (with current derating >50°C)
-40/100/21 acc. to IEC 60068-1
3M4 (operation); 2M2 (transport) acc. to IEC 60721-3-3;
IEC 60721-3-2
UL 94 V-0
> 1MOhm acc. to IEC 60204-1
UL 60939-3, IEC 60939-3
> 200,000 hours
Typical applications
Three-phase variable speed drives and power drive
systems (PDS)
Machine tool and machinery equipment
IT power distribution networks (FN 3288IT and FN
3288 HVIT )
General energy conversion devices (inverters,
converters)
Process automation equipment
Three-phase power supplies
Low-leakage current requirements
Rated currents
Operating frequency
High potential test voltage
Overvoltage category
Pollution degree
Protection category
Overload capability
Temperature range (operation and storage)
Climatic class
Vibration and shock
Flammability according to
Compliance with insulation requirement
Design corresponding to
MTBF
Typical electrical schematic
Note: IT and HVIT versions without discharge resistor
to ground.
3
EMC/EMI Products
Schaffner Group
Datasheets
13 Nov 2018
Filter selection table
Filter*
Rated current
@ 50°C (40°C)
[A]
High voltage versions*:
FN 3288HV-10-44-C34-R65
FN 3288HV-16-44-C34-R65
FN 3288HV-20-33-C36-R65
FN 3288HV-25-33-C36-R65
FN 3288HV-40-33-C36-R65
FN 3288HV-50-53-C36-R65
FN 3288HV-63-53-C36-R65
FN 3288HV-80-34-C36-R65
FN 3288HV-100-35-C36-R65
FN 3288HV-125-35-C36-R65
FN 3288HV-160-40-C36-R65
HV for IT power networks****:
FN 3288HVIT-10-44-C42-R60
FN 3288HVIT-16-44-C43-R60
FN 3288HVIT-20-33-C43-R60
FN 3288HVIT-25-33-C43-R60
FN 3288HVIT-40-33-C43-R60
FN 3288HVIT-50-53-C43-R60
FN 3288HVIT-63-53-C43-R60
FN 3288HVIT-80-34-C43-R60
FN 3288HVIT-100-35-C43-R60
FN 3288HVIT-125-35-C44-R60
FN 3288HVIT-160-40-C43-R60
10 (11)
16 (17)
20 (22)
25 (27)
40 (44)
50 (55)
63 (69)
80 (88)
100 (110)
125 (137)
160 (175)
10
16
20
25
40
50
64
80
100
125
160
4.6
6.8
6.8
6.8
6.8
6.8
6.8
6.8
6.8
5.9
6.8
6.9
10.8
12.0
14.6
19.2
26.3
32.1
28.8
33.0
42.2
46.1
-44
-44
-33
-33
-33
-53
-53
-34
-35
-35
-40
1.2
1.5
1.8
1.9
2.9
3.3
3.5
4.9
5.8
5.9
7.2
I
J
K
K
L
M
M
N
O
O
P
10 (11)
16 (17)
20 (22)
25 (27)
40 (44)
50 (55)
63 (69)
80 (88)
100 (110)
125 (137)
160 (175)
10
16
20
25
40
50
64
80
100
125
160
8.4
8.4
10.9
10.9
12.4
12.4
12.4
12.4
12.4
12.4
12.4
6.9
10.8
12.0
14.6
19.2
26.3
32.1
28.8
33.0
42.0
46.1
-44
-44
-33
-33
-33
-53
-53
-34
-35
-35
-40
1.2
1.5
1.8
1.9
2.9
3.3
3.5
4.9
5.8
5.9
7.2
I
J
K
K
L
M
M
N
O
O
P
Typical drive
power rating**
[kW]
Leakage current***
@ 760 VAC/50 Hz
[mA]
Power loss
@ 25°C
[W]
Input/Output
Connections
[kg]
Weight
Frame
* Additional filter versions with lower leakage currents (lower Cy capacitors) available -> replace Cxx with C25.
** Typical power rating (400 VAC for FN 3287 and FN 3288 / 690 VAC for FN 3288 HV and FN 3288 HVIT) with cos phi=0.85. The exact value depends upon the efficiency of the drive,
the motor and the entire application.
*** Standardized calculated leakage current acc. IEC 60939 under normal operating conditions (FN 3287, FN 3288 and FN 3288 IT at 480 VAC, FN 3288 HV and FN 3288 HVIT at 690
VAC).
****These filters may be operated in IT system as long as the operation conditions and possible short circuit/fault (earth connection of one conductor) occurs between the supply
(line side) and the filter. The filters are not designed for short circuit/faults occurring between converter and motor.
