TV06R (D38999/26) – Crimp, Metal
CTV06R (D38999/26) – Crimp, Composite
Straight Plug
PART #
To complete,
see how to order
pages 25-27.
Connector
Type
Shell
Style
Amphenol
Aerospace
Service Shell Size
Class & Insert Arrg
Contact Alternate
Special
Type
Position Variations
38999
TV
TVS
TVS
TVS
CTV
CTVS
D38999/
06 RW
06
RK
06
RF
06
RS
06 RW
METAL
06
RF
26
X
9-35
X-X
X-X
X-X
X-X
X-X
X-X
P
X
X
X
X
X
X
B
X
X
X
X
X
X
(453)
(XXX)
(XXX)
(XXX)
(XXX)
(XXX)
NA
METAL
1.234 MAX
31.34 MAX
1.220 MAX
31.00 MAX
B THREAD
VIEW D
FOR SIZE 8 COAXIAL ONLY,
RELATIVE TO –A–
1.656 MAX
42.06 MAX
III
HD
Dualok
II
I
SJT
A
ccessori
A
quacon
H
erm/Sea
PCB
Q
D
HIgH
SPEED
Fiber
Optics
V THREAD
BLUE BAND
†
.359 MAX
9.12 MAX
.591 +.003
–.000
15.01 +.08
–.00
Contacts
Cables
Connecto
EMI Filter
Transient
–A–
COMPOSITE
1.234 MAX
31.34 MAX
B THREAD
Q
VIEW D
FOR SIZE 8 TWINAX ONLY,
RELATIVE TO –A–
1.797 MAX
45.64 MAX
Matrix 2
Matrix|Pyle
26482
83723 III
D
26500
Pyle
V THREAD
BLUE BAND
†
.359 MAX
9.12 MAX
.591 +.003
–.000
15.01 +.08
–.00
Crimp Rear
Release
Matrix
–A–
5015
† Blue band indicates rear release contact retention system
Inches
Millimeters
22992
Class L
Shell
Size
9
11
13
15
17
19
21
23
25
MS Shell Size
Code
A
B
C
D
E
F
G
H
J
B Thread
0.1P-0.3L-TS-2B
(Plated)
.6250
.7500
.8750
1.0000
1.1875
1.2500
1.3750
1.5000
1.6250
Q Dia. Max.
.858
.984
1.157
1.280
1.406
1.516
1.642
1.768
1.890
Shell
Size
9
11
13
15
17
19
21
23
25
MS Shell Size
Code
A
B
C
D
E
F
G
H
J
Q Max.
21.8
25.0
29.4
32.5
35.7
38.5
41.7
44.9
48.0
V Thread Metric
M12X1-6g
M15X1-6g
M18X1-6g
M22X1-6g
M25X1-6g
M28X1-6g
M31X1-6g
M34X1-6g
M37X1-6g
Back-
Shells
Options
Others
All dimensions for reference only.
Contact Amphenol Aerospace for more information at 800-678-0141 • www.amphenol-aerospace.com
