ALUMINUM ELECTROLYTIC CAPACITORS
PM
Item
Extremely Low Impedance, High Reliability
series
(through 100V only)
High reliability withstanding 5000 hour load life at +105
°C
(3000/2000 hours
for smaller case sizes as specified below).
Capacitance ranges available based on the numerical values in E12 series
under JIS.
Adapted to the RoHS directive (2002/95/EC).
PM
Smaller
Specifications
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Leakage Current
PW
Performance Characteristics
– 55 ~ +105°C (6.3 ~ 100V), –40 ~ +105°C (160 ~ 400V), –25 ~ +105°C (450V)
6.3 ~ 450V
0.47 ~ 15000µF
± 20% at 120Hz, 20°C
Rated Voltage (V)
6.3 ~ 100
Leakage current
160 ~ 450
After 1 minute's application of rated voltage, leakage current is not more CV < 1000 :
I
= 0.1CV+40 (µA) max. (1 minute's)
=
than 0.03CV or 4 (µA), whichever is greater.
CV > 1000 :
I
= 0.04CV+100 (µA) max. (1 minute's)
Measurement frequency : 120Hz, Temperature : 20°C
For capacitance of more than 1000µF, add 0.02 for every increase of 1000µF.
tan
δ
Rated Voltage (V)
tan
δ
(MAX.)
6.3
0.22
10
0.19
6.3 · 10
—
—
4
16
0.16
16
—
—
3
25
0.14
25 · 35
—
—
3
35
0.12
50
0.10
63 ~ 100
0.08
250
—
6
—
160 ~ 350 400 · 450
0.20
0.25
400
—
10
—
450
15
—
—
120Hz
Stability at Low Temperature
Rated voltage (V)
Z– 25°C / Z+20°C
Impedance
Z– 40°C / Z+20°C
ratio (MAX.)
Z– 55°C / Z+20°C
50~100 160~200
—
—
4
—
—
2
315~350
—
8
—
Endurance
Shelf Life
Marking
After an application of D.C. bias voltage plus the rated ripple
current for 5000 hours (2000 hours for D = 5 and 6.3,
3000 hours for D=8) at 105°C the peak voltage shall not
exceed the rated D.C. voltage, capacitors meet the
characteristic requirements listed at right.
After storing the capacitors under no load at 105°C
for 1000 hours, and after performing voltage treatment based
on JIS C 5101-4 clause 4.1 at 20°C, they will meet the
characteristic requirements listed at right.
Printed with white color letter on dark brown sleeve.
Capacitance change
tan
δ
Leakage current
Within ±20% of initial value
200% or less of initial specified value
Initial specified value or less
Within ±20% of initial value
150% or less of initial specified value
Initial specified value or less
Capacitance change
tan
δ
Leakage current
Radial Lead Type
Sleeve (P.E.T.)
Type numbering system (Example : 25V 470
µ
F)
1
2
3
4
5
6
7
8
9 10 11 12
UPM 1 E 4 7 1 M PD
φ
d
Configuration
φD
+
0.5
MAX.
Size code
Type
Small Dia
Low Profile
Code
6
Capacitance tolerance (± 20%)
P
±
0.5
Rated Capacitance (470µF)
Rated voltage (25V)
Series name
Pressure
relief vent
(φ6.3up)
Type
L
+
MAX.
15
MIN
4
MIN
Configuration
φ
D
Pb-free leadwire
Pb-free PET sleeve
(φD < 10) 1.5
(φD > 10) 2.0
=
(mm)
5
6.3
8 · 10
12.5 ~ 18
DD
ED
PD
HD
Frequency coefficient
15000
10000
φD
P
φd
5
2.0
0.5
6.3
2.5
0.5
8
3.5
0.6
10
5.0
0.6
12.5
5.0
0.6
16
7.5
0.8
18
7.5
0.8
Frequency coefficient of
Rated voltage
rated ripple current
Rated voltage
Frequency coefficient
In case L > 25 for the
φ12.5
dia. unit, lead dia.
φ
d = 0.8mm.
15000
10000
6800
4700
3300
•
Please refer to page 21 about the end seal configulation.
6800
4700
2200
3300
1500
1000
2200
680
1500
470
1000
6.3~100V
(10kHz~
200kHz=1)
Cap.(
µ
F)
680
470
330
220
330
220
150
100
68
6.3~100V
(10kHz~
200kHz=1)
150
47
100
33
120Hz
300Hz
1kHz
Cap.(
µ
F)
68
22
47
15
33
10
22
0.68
0.47
0
0.5
0.6
0.7
0.8
Frequency coefficient
0.9
1.0
120Hz
300Hz
1kHz
Please refer to page 21, 22, 23 about the formed or taped product spec.
Please refer to page 3 for the minimum order quantity.
15
10
Dimension table in next page.
160~450V
50Hz
0.80
0.68
0.47
0
120Hz
1.00
0.5
100Hz
1.25
11kHz
1.40
0.9
110kHz~
1.60
1.0
0.6
0.7
0.8
Frequency coefficient
CAT.8100V-1
