F-217
ESQ–132–14–G–D
ESQ–110–44–T–D
ESW–115–12–G–S
(2.54 mm) .100"
ESW, ESQ SERIES
ELEVATED SOCKET
Mates with:
TSW, MTSW, EW,
MTLW, TSS, ZSS, TSM,
DW, ZW, HW, TSSH, HTSS
TYPE
STRIP
1
NO. PINS
PER ROW
LEAD
STYLE
PLATING
OPTION
ROW
OPTION
OTHER
OPTION
SPECIFICATIONS
For complete specifications
see www.samtec.com?ESW or
www.samtec.com?ESQ
Insulator Material:
Black Glass Filled Polyester
Contact Material:
Phosphor Bronze
Plating:
Au or Sn over
50 µ" (1.27 µm) Ni
Current Rating (ESW/TSW):
5.2 A per pin
(1 pin powered per row)
Current Rating (ESQ/TSW):
5.7 A per pin
(1 pin powered per row)
Voltage Rating:
550 VAC mated with
TSW or ESQ
Operating Temp Range:
-55 °C to +125 °C with Gold
-55 °C to +105 °C with Tin
Contact Resistance:
10 mΩ
Insertion Depth:
(3.68 mm) .145" to
(6.35 mm) .250"
Normal Force:
Standard = 125 grams (4.4 N)
Max Cycles:
100 with 10 µ" (0.25 µm) Au
RoHS Compliant:
Yes
Lead-Free Solderable:
Wave only
ESW
= Solder Tail
ESQ
= Square Tail
ALSO AVAILABLE
(MOQ Required)
• Other platings
Contact Samtec.
= 10 µ" (0.25 µm)
Gold contact,
Matte Tin on tail
–L
= Single
Row
–S
= Locking
Lead
–LL
= 20 µ" (0.51 µm)
Gold contact,
Gold Flash on Balance
–G
–T
= Double
Row
–D
–T
01 thru 36
(2.54) .100 X No. of Positions + (0.51) .020
= Matte Tin
(N/A w/LIF contact)
= Triple
Row
(ESQ only)
Two leads per
strip crimped.
N/A with single
row 1 or 2
positions.
–“XXX”
= Polarized
(2.41)
.095
–S
01
72
(2.54)
.100
36
02
–D
(2.54)
.100
71
108
(4.95)
.195
(2.54)
.100
01
03
Specify LEAD STYLE
from chart below.
LOW
STANDARD
INSERTION FORCE INSERTION FORCE
A
(2.29)
.090
(7.36)
.290
(4.83)
.190
(2.29)
.090
(12.19)
.480
(9.65)
.380
(7.11)
.280
(4.57)
.180
B
(11.05)
.435
(13.59)
.535
(16.13)
.635
(11.05)
.435
(13.59)
.535
(16.13)
.635
(18.67)
.735
– 12
– 13
(7.49)
.295
– 37
– 38
– 48
– 58
– 39
– 49
– 59
– 69
RECOGNITIONS
For complete scope
of recognitions see
www.samtec.com/quality
(5.08)
.200 (2.54)
.100
– 23
– 33
– 14
– 24
– 34
– 44
B
(ESQ
only)
FILE NO. E111594
FILE NO: 090871_0_000
–T
106
01
A
APPLICATIONS
Note:
Some lengths,
styles and options are
non-standard, non-returnable.
(2.54)
.100
TYP
ESW
(0.41) x (0.79)
.016 .031
ESQ
(0.64)
.025
SQ
Self g
Nestints
Socke
(ESQ Series)
PC/104
™
J1/P1 “Stackthrough” Connectors
Standard Insertion Force
ESQ-132-14-G-D
Low Insertion Force
ESQ-132-39-G-D
PC/104
™
J1 “Non-Stackthrough” Connectors
Standard Insertion Force
ESQ-132-12-G-D
Low Insertion Force
ESQ-132-37-G-D
PC/104
™
J2/P2 “Stackthrough” Connectors
Standard Insertion Force
ESQ-120-14-G-D
Low Insertion Force
ESQ-120-39-G-D
PC/104 is a trademark of the PC/104 Consortium.
WWW.SAMTEC.COM
Due to technical progress, all designs, specifications and components are subject to change without notice.
