ESW-109-33-T-D-001: DescriptionBoard Connector, 17 Contact(s), 2 Row(s), Female, Straight, Solder Terminal,; CategoryThe connector The connector; File Size716KB，1 Pages; ManufacturerSAMTEC; Websitehttp://www.samtec.com/

Download Datasheet Parametric View All

ESW-109-33-T-D-001 Overview

Board Connector, 17 Contact(s), 2 Row(s), Female, Straight, Solder Terminal,

ESW-109-33-T-D-001 Parametric

Parameter Name	Attribute value
Objectid	7310801726
Reach Compliance Code	compliant
ECCN code	EAR99
YTEOL	9.1
Other features	POLARIZED
body width	0.195 inch
subject depth	0.635 inch
body length	0.92 inch
Body/casing type	SOCKET
Connector type	BOARD CONNECTOR
Contact to complete cooperation	NOT SPECIFIED
Contact completed and terminated	NOT APPLICABLE
Contact point gender	FEMALE
Contact material	NOT SPECIFIED
contact mode	RECTANGULAR
Contact style	SQ PIN-SKT
DIN compliance	NO
Durability	100 Cycles
empty shell	NO
Filter function	NO
IEC compliance	NO
Insulator color	BLACK
MIL compliance	NO
Plug contact pitch	0.1 inch
Match contact row spacing	0.1 inch
Plug information	MULTIPLE MATING PARTS ARE AVAILABLE
Mixed contacts	NO
Installation option 1	LOCKING
Installation method	STRAIGHT
Installation type	BOARD
Number of connectors	ONE
PCB row number	2
Number of rows loaded	2
Maximum operating temperature	105 °C
Minimum operating temperature	-55 °C
Options	GENERAL PURPOSE
PCB contact pattern	RECTANGULAR
PCB contact row spacing	2.54 mm
Rated current (power)	5.2 A
Guideline	UL
Terminal length	0.09 inch
Terminal pitch	2.54 mm
Termination type	SOLDER
Total number of contacts	17
UL Flammability Code	94V-0

Preview

Download Datasheet

View All

F-219

ESQ–132–14–G–D

ESQ–110–44–T–D

ESW–115–12–G–S

(2.54 mm) .100"

ESW, ESQ SERIES

ELEVATED SOCKET

Mates with:

TSW, MTSW, EW,

MTLW, TSS, ZSS, TSM,

DW, ZW, HW, TSSH, HTSS

TYPE

STRIP

NO. PINS

PER ROW

LEAD

STYLE

PLATING

OPTION

ROW

OPTION

OTHER

OPTION

SPECIFICATIONS

For complete specifications

see www.samtec.com?ESW or

www.samtec.com?ESQ

Insulator Material:

Black Glass Filled Polyester

Contact Material:

Phosphor Bronze

Plating:

Au or Sn over

50 µ" (1.27 µm) Ni

Current Rating (ESW/TSW):

5.2 A per pin

(2 pins powered)

Current Rating (ESQ/TSW):

5.7 A per pin

(2 pins powered)

Voltage Rating:

550 VAC mated with

TSW or ESQ

Operating Temp Range:

-55 °C to +125 °C with Gold

-55 °C to +105 °C with Tin

Insertion Depth:

(3.68 mm) .145" to

(6.35 mm) .250"

Normal Force:

Standard = 125 grams (4.4 N)

Max Cycles:

100 with 10 µ" (0.25 µm) Au

RoHS Compliant:

Yes

Lead-Free Solderable:

Wave only

ESW

= Solder Tail

ESQ

= Square Tail

= 10 µ" (0.25 µm)

Gold contact,

Matte Tin on tail

–L

= Single

Row

–S

= Locking

Lead

–LL

= 20 µ" (0.51 µm)

Gold contact,

Gold Flash on Balance

–G

–T

= Double

Row

–D

–T

01 thru 36

(2.54) .100 X No. of Positions + (0.51) .020

= Matte Tin

(N/A w/LIF contact)

= Triple

Row

(ESQ only)

Two leads per

strip crimped.

N/A with single

row 1 or 2

positions.

–“XXX”

= Polarized

(2.41)

.095

–S

(2.54)

.100

–D

(2.54)

.100

108

(4.95)

.195

(2.54)

.100

Specify LEAD STYLE

from chart below.

LOW

STANDARD

INSERTION FORCE INSERTION FORCE

(2.29)

.090

(7.36)

.290

(4.83)

.190

(2.29)

.090

(12.19)

.480

(9.65)

.380

(7.11)

.280

(4.57)

.180

(11.05)

.435

(13.59)

.535

(16.13)

.635

(11.05)

.435

(13.59)

.535

(16.13)

.635

(18.67)

.735

– 12

– 13

(7.49)

.295

– 37

– 38

– 48

– 58

– 39

– 49

– 59

– 69

RECOGNITIONS

For complete scope

of recognitions see

www.samtec.com/quality

(5.08)

.200 (2.54)

.100

– 23

– 33

– 14

– 24

– 34

– 44

FILE NO. E111594

(ESQ

only)

–T

106

APPLICATIONS

ALSO AVAILABLE

(MOQ Required)

• Other platings

Note:

Some lengths, styles and

options are non-standard,

non-returnable.

(2.54)

.100

TYP

ESW

(0.41) x (0.79)

.016 .031

ESQ

(0.64)

.025

Self g

Nestints

Socke

(ESQ Series)

PC/104

™

J1/P1 “Stackthrough” Connectors

Standard Insertion Force

ESQ-132-14-G-D

Low Insertion Force

ESQ-132-39-G-D

PC/104

™

J1 “Non-Stackthrough” Connectors

Standard Insertion Force

ESQ-132-12-G-D

Low Insertion Force

ESQ-132-37-G-D

PC/104

™

J2/P2 “Stackthrough” Connectors

Standard Insertion Force

ESQ-120-14-G-D

Low Insertion Force

ESQ-120-39-G-D

PC/104 is a trademark of the PC/104 Consortium.
