IEC Appliance Inlet C16, Screw-on Mounting, Front Side, Quick-connect or Screw-on Terminal
0161-Y
C16
120° C
Description
- Panel Mount:
Screw-on mounting, Front Side
- 1 Function:
- Appliance Inlet, Pin temperature 120 °C, Protection class I
- Solder, Quick Connect or Screw Terminals
Approvals
- VDE Certificate Number: 40009508
- UL File Number: E96454
- CSA File Number: 27324
Technical Data
Ratings IEC
Ratings UL/CSA
Dielectric Strength
Allowable Operation Temp.
Degree of Protection
Protection Class
Material: Housing
Dimensions
SE
48
16
5
3.
2
ø
10 A / 250 VAC; 50 Hz
15 A / 250 VAC; 60 Hz
> 3 kVAC between L-N
> 1.5 kVAC between L/N-PE
(1 min/50 Hz)
-25 °C to 120 °C
from front side IP 20 acc. to IEC 60529
Suitable for appliances with protection
class I acc. to IEC 61140
PA6, black or grey, UL 94V-0
PH
A
22
40
26.9
19.5
- 0
19.3
+0.2
27.1
- 0
+0.2
Length of the terminal please find at the order code configuration table
Config. Code
0161-Y
|
-
|
H
|
-
|
A
|
B
|
C
|
0-
|
D
|
-
|
E
|
G
|
O
|
The characters are placeholders for the correspondingly keys of selections from the key tables.
Connectors
R
4
-O
UT
Weblinks
pdf-datasheet, html-datasheet, General Product Information, Approvals,
CE declaration of conformity, RoHS, CHINA-RoHS, REACH, Mating
Connectors, e-Shop, SCHURTER-Stock-Check, Distributor-Stock-
Check, CAD-Drawings, Accessories, Detailed request for product
Appliance Inlet
C16 acc. to IEC 60320
UL 498, CSA C22.2 no. 42 (For hot
conditions) pin-temperature 120 °C,
10 A, Protection Class I
40
1
0161-Y
0161-Y
|
-
|
H
|
-
|
A
|
B
|
C
|
0-
|
D
|
-
|
E
|
G
|
O
|
= Type
Type
variant
Configuration
key
Y
Terminal Ground
Blade terminal (6.3 x 0.8 mm)
screw terminal
Symbols similar as in table A
Connectors (Inlets/Outlets)
www.schurter.com/PG07
Configuration
key
9
A
0161-Y
|
-
|
H
|
-
|
A
|
B
|
C
|
0-
|
D
|
-
|
E
|
G
|
O
|
= Terminals
Terminal L
Configuration
key
short solder terminal (L = 4.8 mm)
Blade terminal (4.8 x 0.8 mm)
Blade terminal (6.3 x 0.8 mm)
screw terminal
0161-Y
|
-
|
H
|
-
|
A
|
B
|
C
|
0-
|
D
|
-
|
E
|
G
|
O
|
= Terminals
Terminal N
short solder terminal (L = 4.8 mm)
Blade terminal (4.8 x 0.8 mm)
Blade terminal (6.3 x 0.8 mm)
screw terminal
Symbols similar as in table A
Configuration
key
0161-Y
|
-
|
H
|
-
|
A
|
B
|
C
|
0-
|
D
|
-
|
E
|
G
|
O
|
= Terminals
Terminal Ground
short solder terminal (L = 4.8 mm)
Blade terminal (4.8 x 0.8 mm)
Symbols similar as in table A
SE
Features
Configuration
key
without V-Lock
V-Lock
2
8
PH
A
Mating Outlets/Connectors
Category / Description
Connector Overview complete
IEC Connector C15A, Rewireable, Straight
IEC Connector C15A, Rewireable, Straight
IEC Connector C15A, Rewireable, Angled
IEC Connector C15A, Rewireable, Angled
Connector further types to 0161-Y
IEC Connector C15A, Rewireable, Straight
2
Connectors
The specifications, descriptions and illustrations indicated in this document are based on current
information. All content is subject to modifications and amendments. Information furnished is believed
to be accurate and reliable. However, users should independently evaluate the suitability and test each
product selected for their own applications.
