L
Vishay Sfernice
Ultra Low Value
Thin Film Resistors
FEATURES
•
NiCr + Ta
2
O
5
resistive layer
•
Pre-soldered or gold terminations
•
No inductance for high frequency applications
•
Alumina substrates for high power handling
capability
•
Resistance range: 0.1
Ω
to 10
Ω
•
TCR: down to ± 50 ppm/°C
•
Power rating: up to 1 W at + 70 °C
With extremely low resistance and high power capabilities,
these ultra low value resistors are available with solderable
or weldable terminations.
Pb-free
Available
RoHS*
COMPLIANT
DIMENSIONS
in millimeters [inches]
A
D
D
C
B
E
E
DIMENSION
CASE
SIZE
A
MAX .TOL
+ 0.64 [+ 0.025]
MIN. TOL.
- 0.13 [- 0.005]
1.27 [0.050]
1.52 [0.060]
1.91 [0.075]
2.54 [0.100]
3.20 [0.126]
3.81 [0.150]
5.08 [0.200]
B
MAX. TOL.
+ 0.26 [+ 0.010]
MIN. TOL.
- 0.13 [- 0.005]
1.27 [0.050]
0.75 [0.030]
1.27 [0.050]
1.27 [0.050]
1.60 [0.063]
1.27 [0.050]
2.54 [0.100]
C
MAX .TOL
+ 0.64 [+ 0.025]
MIN. TOL.
- 0.13 [- 0.005]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
D/E
MAX. TOL.
+ 0.13 [+ 0.005]
MIN. TOL.
- 0.13 [- 0.005]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
0.38 [0.015]
POWER
RATING
mW
LIMITING
ELEMENT
VOLTAGE
V
RESISTANCE
RANGE
0505
0603
0705
0805
1005
1206
1505
2010
125
125
200
250
330
500
1000
50
50
50
50
50
50
50
0.1
Ω...
10
Ω
0.1
Ω...
10
Ω
0.1
Ω...
10
Ω
0.1
Ω...
10
Ω
0.1
Ω...
10
Ω
0.1
Ω...
10
Ω
0.1
Ω...
10
Ω
* Pb containing terminations are not RoHS compliant, exemptions may apply
Document Number: 53018
Revision: 12-Dec-07
For technical questions, contact: sfer@vishay.com
www.vishay.com
57
L
Vishay Sfernice
ELECTRICAL SPECIFICATIONS
Resistance range:
Resistance tolerance:
Power dissipation:
Temperature coefficient:
0.1
Ω
to 10
Ω
± 1 % to ± 10 %
0.125 mW to 1 W at + 70 °C
down to ± 50 ppm/°C
Ultra Low Value
Thin Film Resistors
TOLERANCE AND TCR VERSUS OHMIC
VALUE
MINIMUM
TOLERANCE
± 10 %
±5%
±2%
±1%
±1%
OHMIC
VALUES
0.1
Ω
0.25
Ω
0.5
Ω
1
Ω
5
Ω
BEST TCR
ppm/°C
± 300
± 200
± 100
± 100
± 50
MECHANICAL SPECIFICATIONS
Substrate:
Resistive layer:
Coating:
Terminations:
Alumina
NiCr + Ta
2
O
5
Silicone
Solderable
B type:
SnPb over nickel barrier
N type:
SnAg over nickel barrier
G type:
gold over nickel barrier
PACKAGING
Several types of packaging are proposed: tube, waffle-pack
and tape and reel.
NUMBER OF PIECES PER PACKAGE
SIZE
TUBE
WAFFLE
PACK
2" x 2"
TAPE AND REEL
MIN.
MAX.
TAPE
WIDTH
CLIMATIC SPECIFICATIONS
Operating temp. range:
- 55 °C to + 155 °C
POWER DERATING CURVE
Rated Power (%)
100
80
60
40
0505
0603
0805
0705
1005
1206
250
140
00
100
100
2000
12 mm
500
100
100
4000
8 mm
20
0
1505
2010
0
20
40
60 70
80
100
120
140 155
Ambient Temperature in °C
PERFORMANCE
VALUES AND DRIFT
TESTS
CONDITIONS
MIL-R-55342 C
MIL-STD-702-Method 107
MIL-R-55342 C
PARA 3.10.4.7.5
MIL-R-55342 C
PARA 3.9 and 4.7.4
MIL-R-55342 C
PARA 3.12, 4.7.7, 4.7.1.2
MIL-R-55342 C
PARA 3.13 and 4.7.8
MIL-STD-202-Method 106
MIL-R-55342 C
PARA 3.11 and 4.7.6
MIL-R-55342 C
2000 h Pn at 70 °C
MIL-STD-202-Method 108
MIL-R-55342
REQUIREMENTS
± 0.25 %
± 0.10 %
± 0.25 %
± 0.25 %
TYPICAL
PERFORMANCES
± 0.02 %
± 0.01 %
± 0.01 %
± 0.04 %
Thermal shock
Short time overload
Low temperature operation
Resistance to solder heat
Moisture resistance
± 0.40 %
± 0.01 %
High temperature
± 0.20 %
± 0.075 %
Load life
± 0.50 %
± 0.15 %
www.vishay.com
58
For technical questions, contact: sfer@vishay.com
Document Number: 53018
Revision: 12-Dec-07
L
Ultra Low Value
Thin Film Resistors
GLOBAL PART NUMBER INFORMATION
New Global Part Numbering: L0805K1R00FBT0028
Vishay Sfernice
L
GLOBAL
MODEL
L
0
8
0
5
K
1
R
0
0
F
B
T
0
0
2
8
SIZE
0505
0603
0705
0805
1005
1206
1505
2010
TCR
H
= ± 50 ppm
K
= ± 100 ppm
L
= ± 200 ppm
M
= ± 300 ppm
VALUE
R designated
decimal point
TOLERANCE
F
=±1%
G
=±2%
H
=±3%
J
=±5%
K
= ± 10 %
TERMINATION
B:
SnPb over
nickel barrier
N:
SnAg over
nickel barrier
G:
gold over
nickel barrier
PACKAGING
blank:
Waffle pack
T:
Tape
and reel
OPTION
leave blank
if no option
B:
Lead bearing version
N and G:
Lead (Pb)-free/
RoHS version
Historical Part Number example: L 0805 K 1R00 1 % B T R0028
L
MODEL
0805
SIZE
K
TCR
1R00
VALUE
1%
TOLERANCE
B
TERMINATION
T
PACKAGING
R0028
OPTION
Document Number: 53018
Revision: 12-Dec-07
For technical questions, contact: sfer@vishay.com
www.vishay.com
59
