POWERMITE
®
8700 E. Thomas Road
Scottsdale, AZ 85251
Tel: (480) 941-6300
Fax: (480) 947-1503
3.0 WATT
Zener Diodes
1PMT5913B
thru
1PMT5956B
DESCRIPTION
In Microsemi's Powermite surface mount package, these zener diodes
provide power-handling capabilities (3.0
WATTS)
found in larger packages.
In addition to its size advantages, Powermite package features include a
full metallic bottom that eliminates the possibility of solder flux entrapment
during assembly, and a unique locking tab acts as an integral heat sink. Its
innovative design makes this device ideal for use with automatic insertion
equipment.
®
®
DO-216
FEATURES
•
•
•
•
•
Surface Mount Packaging
Integral Heat Sink Locking Tabs
Compatible with automatic insertion equipment
Full metallic bottom eliminates flux entrapment
Zener voltage 3.3 to 200 Volts
Low reverse leakage
Tight tolerance available
ESD Rating of >16kV per human body model
CIRCUIT DIAGRAM
MECHANICAL CHARACTERISTICS
•
•
•
•
•
Cathode designated by TAB 1
Mounting position any way
Molded package
Weight: 0.016 gram (approximate)
Thermal resistance 30°C/W junction to TAB1
•
•
•
•
•
•
MAXIMUM RATINGS
Junction and storage temperatures: -55°C to +150°C
DC power dissipation: 3.0 watt with TAB 1 60°C
Forward voltage:
@ 200 mA 1.2 volts
Packaging
•
PACKAGING
EIA Standard 481
Tape & Reel
•
•
•
Tape & Reel EIA Standard 481
7 inch 3,000 pieces
13 inch 12,000 pieces
Mechanical Specifications
Mounting Pad Dimensions
All dimensions +/- .005 inches
Inches
MSC0995.PDF
ISO 9001 CERTIFIED
REV F 11/01/99
1PMT5913B thru 1PMT5956B
Electrical Characteristics @ T
L
= 30° C
°
MICROSEMI
NUMBER
DEVICE
MARKING
ZENER
VOLTAGE
(1)
TEST
CURRENT
DYNAMIC
IMPEDANCE
(2)
KNEE
CURRENT
KNEE
IMPEDANCE
REVERSE
CURRENT
REVERSE
VOLTAGE
V
Z
VOLTS
I
ZT
mA
113.6
104.2
96.1
87.2
79.8
73.5
66.9
60.5
55.1
50
45.7
41.2
37.5
34.1
31.2
28.8
25
23.4
20.8
18.7
17
15.6
13.9
12.5
11.4
10.4
9.6
8.7
8.0
7.3
6.7
6.0
5.5
5.0
4.6
4.1
3.7
3.4
3.1
2.9
2.5
2.3
2.1
1.9
Z
ZT
OHMS
10
9.0
7.5
6.0
5.0
4.0
2.0
2.0
2.5
3.0
3.5
4.0
4.5
5.5
6.5
7.0
9.0
10
12
14
17.5
19
23
28
33
38
45
53
67
70
86
100
120
140
160
200
250
300
380
450
600
700
900
1200
I
ZK
mA
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
1.0
0.5
0.5
0.5
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
0.25
Z
ZK
OHMS
500
500
500
500
500
350
250
200
200
400
400
500
500
550
550
550
600
600
650
650
650
700
700
750
800
850
900
950
1000
1100
1300
1500
1700
2000
2500
3000
3100
4000
4500
5000
6000
6500
7000
8000
I
R
(MAX)
µ Adc
100
75
25
5
5
5
5
5
5
5
5
5
5
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
V
R
VOLTS
1.0
1.0
1.0
1.0
1.5
2.0
3.0
4.0
5.2
6.0
6.5
7.0
8.0
8.4
9.1
9.9
11.4
12.2
13.7
15.2
16.7
18.2
20.6
22.8
25.1
27.4
29.7
32.7
35.8
38.8
42.6
47.1
51.2
56
62.2
69.2
76
83.6
91.2
98.8
114
121.6
136.8
152
MAX
ZENER
CURRENT
(3)
I
ZM
mA
749.1
686.4
633.6
547.2
526.4
481.8
432.3
397.7
363.0
330.0
300.3
270.6
247.5
224.4
206.2
189.8
165.0
153.5
68.5
123.8
112.2
102.3
90.8
82.5
74.3
67.7
62.7
56.1
51.2
47.9
42.9
38.6
36.3
33.0
29.7
26.4
24.8
21.5
19.8
18.1
16.5
14.9
13.2
11.6
1PMT5913B
1PMT5914B
1PMT5915B
1PMT5916B
1PMT5917B
1PMT5918B
1PMT5919B
1PMT5920B
1PMT5921B
1PMT5922B
1PMT5923B
1PMT5924B
1PMT5925B
1PMT5926B
1PMT5927B
1PMT5928B
1PMT5929B
1PMT5930B
1PMT5931B
1PMT5932B
1PMT5933B
1PMT5934B
1PMT5935B
1PMT5936B
1PMT5937B
1PMT5938B
1PMT5939B
1PMT5940B
1PMT5941B
1PMT5942B
1PMT5943B
1PMT5944B
1PMT5945B
1PMT5946B
1PMT5947B
1PMT5948B
1PMT5949B
1PMT5950B
1PMT5951B
1PMT5952B
1PMT5953B
1PMT5954B
1PMT5955B
1PMT5956B
913
914
915
916
917
918
919
920
921
922
923
924
925
926
927
928
929
930
931
932
933
934
935
936
937
938
939
940
941
942
943
944
945
946
947
948
949
950
951
952
953
954
955
956
3.3
3.6
3.9
4.3
4.7
5.1
5.6
6.2
6.8
7.5
8.2
9.1
10
11
12
13
15
16
18
20
22
24
27
30
33
36
39
43
47
51
56
62
68
75
82
91
100
110
120
130
150
160
180
200
NOTE 1:
Product shown has a standard tolerance of
±5%
on the nominal zener voltage. Also available in 2% and 1%
tolerance with suffix C and D respectively. V
Z
is measured at I
ZT
with Tc (TAB 1) 30°C . Voltage measurement to be
performed 20 seconds after application of dc current.
NOTE 2:
Zener impedance is derived by superimposing on I
ZT
a 60Hz rms ac current equal to 10% of I
ZT
.
NOTE 3:
Based upon 3 W maximum power dissipation. Allowance has been made for the higher voltage associated with
operation at higher currents and temperature. For determination of voltage change with current deviations from I
ZT
see Micro Note 202.
MSC0995.PDF
ISO 9001 CERTIFIED
REV F 11/01/99
