BA682, BA683
www.vishay.com
Vishay Semiconductors
Band Switching Diodes
FEATURES
• Silicon planar diodes
• Low dynamic forward resistance
• Low diode capacitance
• High reverse impedance
• AEC-Q101 qualified
94 9371
MECHANICAL DATA
Case:
MiniMELF SOD-80
Weight:
approx. 31 mg
Cathode band color:
black
Packaging codes/options:
GS18/10K per 13" reel (8 mm tape), 10K/box
GS08/2.5K per 7" reel (8 mm tape), 12.5K/box
• Material categorization: For definitions of compliance
please see
www.vishay.com/doc?99912
APPLICATIONS
• Band switching in VHF-tuners
PARTS TABLE
PART
BA682
BA683
TYPE DIFFERENTIATION
V
R
= 35 V, r
f
at I
F
3 mA = max. 0.7
V
R
= 35 V, r
f
at I
F
3 mA = max. 1.2
ORDERING CODE
BA682-GS18 or BA682-GS08
BA683-GS18 or BA683-GS08
REMARKS
Tape and reel
Tape and reel
ABSOLUTE MAXIMUM RATINGS
(1)
PARAMETER
Reverse voltage
Forward continuous current
Note
(1)
T
amb
= 25 °C, unless otherwise specified
TEST CONDITIONS
SYMBOL
V
R
I
F
VALUE
35
100
UNIT
V
mA
THERMAL CHARACTERISTICS
(1)
PARAMETER
Junction to ambient air
Junction temperature
Storage temperature range
(1)
TEST CONDITION
On PC board
50 mm x 50 mm x 1.6 mm
SYMBOL
R
thJA
T
j
T
stg
VALUE
500
150
- 55 to + 150
UNIT
K/W
°C
°C
Note
T
amb
= 25 °C, unless otherwise specified
ELECTRICAL CHARACTERISTICS
(1)
PARAMETER
Forward voltage
Reverse current
Diode capacitance
TEST CONDITION
I
F
= 100 mA
V
R
= 20 V
f = 100 MHz, V
R
= 1 V
f = 100 MHz, V
R
= 3 V
f = 200 MHz, I
F
= 3 mA
Dynamic forward resistance
f = 200 MHz, I
F
= 10 mA
Note
(1)
T
amb
= 25 °C, unless otherwise specified
BA682
BA683
BA682
BA683
BA682
BA683
PART
SYMBOL
V
F
I
R
C
D1
C
D2
C
D2
r
f1
r
f1
r
f2
r
f2
MIN.
TYP.
MAX.
1000
50
1.5
1.25
1.2
0.7
1.2
0.5
0.9
UNIT
mV
nA
pF
pF
pF
Rev. 1.6, 04-Mar-13
Document Number: 85530
1
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
BA682, BA683
www.vishay.com
TYPICAL CHARACTERISTICS
Tamb = 25 °C, unless otherwise specified
r
f
- Differential Forward Resistance (Ω)
Vishay Semiconductors
100
3.0
C
D
- Diode Capacitance (pF)
f = 200 MHz
T
j
= 25 °C
10
2.5
2.0
1.5
f = 200 MHz
T
j
= 25 °C
BA683
1
BA682
1.0
BA683
0.5
0
BA682
0.1
0.1
1
10
100
0.1
94 9075
1
10
100
94 9074
I
F
- Forward Current (mA)
V
R
- Reverse Voltage (V)
Fig. 1 - Dynamic Forward Resistance vs. Forward Current
Fig. 1 - Diode Capacitance vs. Reverse Voltage
PACKAGE DIMENSIONS
in millimeters (inches):
MiniMELF SOD-80
Cathode indentification
*
0.47 (0.019) max.
3.7 (0.146)
3.3 (0.130)
* The gap
between
plug and glass can
be
either on cathode or anode side
Foot print recommendation:
2.5 (0.098) max.
1.6 (0.063)
1.4 (0.055)
1.25 (0.49) min.
Document no.:6.560-5005.01-4
Rev.
8
- Date: 07.June.2006
96 12070
5 (0.197) ref.
Rev. 1.6, 04-Mar-13
Document Number: 85530
2
For technical questions within your region:
DiodesAmericas@vishay.com, DiodesAsia@vishay.com, DiodesEurope@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
2 (0.079) min.
