Microwave SLC’s
GENERAL INFORMATION
In addition to the standard SLC products shown below,
AVX is now able to offer bordered versions in these
same dielectric families as detailed on the opposing
page utilizing micron resolution photolithography and
etching processes.
With borders precisely defined, these parts will be ben-
eficial in those applications that require enhanced visual
definition during placement and wire bonding.
Additionally, bordered devices have proven effective in
reducing susceptibility to conductive epoxy electrode
bridging.
Custom designs to meet stringent circuit trace width
matching requirements are available upon request.
GH SERIES: SINGLE LAYER CAPACITORS WITHOUT BORDERS
NP0, TEMPERATURE COMPENSATING & X7R DIELECTRICS
DIMENSIONS: inches (millimeters)
Case Code/Size
Length & Width
Thickness
Min/Max
Dielectric
GH16
.015±.003 (.381±.076)
Cap (pF)
Max
0.2
0.4
1
3
5.6
10
15
29
60
k
14
31
60
200
420
650
1100
2000
4200
A
A
A
4
7
Y
C
C
C
Min
0.06
0.1
0.3
0.8
1.5
2.7
3.3
6.2
13
Tol*
A
A
B
C
J
K
K
K
K
GH18
GH26
.018±.003 (.457±.076)
.025±.005 (.635±.127)
.0045/.012 (.114/.035)
Cap (pF)
Cap (pF)
Min
Max
Tol*
Min
Max
Tol*
0.08
0.2
A
0.2
0.4
A
0.2
0.5
A
0.4
1
A
0.4
1.1
A
0.8
2
B
1.2
3.6
C
2.4
6.8
C
2.2
6.2
D
4.3
12
D
4.3
11
D
7.5
22
J
6.8
18
J
13
36
J
13
36
J
24
68
J
30
75
J
56
150
J
GH35
.035±.005 (.889±.127)
Cap (pF)
Max
0.9
2
4.7
13
22
43
75
130
300
Min
0.4
0.7
1.5
4.7
8.2
15
27
47
110
Tol*
A
A
B
D
J
J
J
J
J
DIMENSIONS: inches (millimeters)
Case Code/Size
Length & Width
Thickness
Min/Max
Dielectric
GH50
.050±.010 (1.27±.254)
Cap (pF)
Max
2
4.7
9.1
30
51
100
160
300
680
k
14
31
60
200
420
650
1100
2000
4200
A
A
A
4
7
Y
C
C
C
Min
0.6
1.5
2.7
8.2
15
27
47
82
180
Tol*
A
B
C
G
G
G
J
J
J
GH70
.070±.010 (1.78±.254)
.0045/.012 (.114/.035)
Cap (pF)
Min
Max
Tol*
1.3
3.9
A
3
8.2
B
6.2
16
D
20
56
G
33
91
G
62
180
G
100
300
J
220
560
J
430
1200
J
GH90
.090±.010 (2.29±.254)
Cap (pF)
Max
5.6
13
27
82
150
270
470
820
1800
Min
2.2
5.1
10
33
56
110
180
330
750
Tol
A
C
G
G
G
G
J
J
J
Note: Tol* - Letter indicates tightest available
9
Microwave SLC’s
GB SERIES: SINGLE LAYER CAPACITORS WITH BORDERS
NP0, TEMPERATURE COMPENSATING & X7R DIELECTRICS
DIMENSIONS: inches (millimeters)
Case Code/Size
Length & Width
Thickness
Min/Max
(B) Border
Dielectric
GB15
.015±.002 (.381±.051)
k
14
31
60
200
420
650
1100
2000
4200
A
A
A
4
7
Y
C
C
C
Min
0.06
0.1
0.3
0.9
1.5
2.7
4.7
9.1
20
Cap (pF)
Max
0.1
0.2
0.4
1.3
2.4
4.7
7.5
13
33
Tol*
A
A
B
D
D
M
M
M
M
GB20
GB25
.020±.002 (.508±.051)
.025±.002 (.635±.051)
.0045/.012 (.114/.035)
.002+.002,-.001 (.051+.051,-.025)
Cap (pF)
Cap (pF)
Min
Max
Tol*
Min
Max
Tol*
0.1
0.2
A
0.2
0.3
A
0.3
0.4
B
0.4
0.7
B
0.5
0.8
C
0.8
1.3
C
1.5
2.7
D
2.7
4.7
M
2.7
4.7
M
4.7
8.2
M
4.7
9.1
M
8.2
15
M
8.2
15
M
15
24
M
16
27
M
27
47
M
36
62
M
56
100
M
GB30
.030±.002 (.762±.051)
Min
0.3
0.6
1.2
3.9
6.8
12
22
39
91
Cap (pF)
Max
0.4
1
2
6.8
12
22
36
68
150
Tol*
A
B
C
K
K
K
K
K
K
DIMENSIONS: inches (millimeters)
Case Code/Size
Length & Width
Thickness
Min/Max
(B) Border
Dielectric
GB35
.035±.002 (.899±.051)
k
14
31
60
200
420
650
1100
2000
4200
A
A
A
4
7
Y
C
C
C
Min
0.4
0.8
1.6
5.1
9.1
18
30
51
120
Cap (pF)
Max
0.6
1.5
3
9.1
16
30
51
91
200
GB40
.040±.002 (1.016±.051)
.0045/.012 (.114/.035)
.002+.002,-.001 (.051+.051,-.025)
Cap (pF)
Tol*
Min
Max
Tol*
A
0.5
0.9
B
C
1.1
2
C
C
2.2
3.9
C
K
6.8
13
K
K
12
22
K
K
22
39
K
K
39
68
K
K
68
120
K
K
160
270
K
GB50
.050±.002 (1.270±.051)
Min
0.8
1.8
3.6
11
20
36
62
110
270
Cap (pF)
Max
1.3
3
6.2
20
36
62
110
200
430
Tol
B
C
D
K
K
K
K
K
K
Note: Tol* - Letter indicates tightest available
HOW TO ORDER
GH
Type Code
GH = w/o borders
GB = w/ borders
16
Case
Code
5
Working
Voltage
5 = 50WVDC
1 = 100WVDC
A
Dielectric
Code
A = NP0*
4 = TC
7 = TC
Y = TC
C = X7R
6R8
Capacitance
Value
EIA Cap Code in pF
First two digits =
significant figures or
“R” for decimal place.
Third digit = number
of zeros or after “R”
significant figures.
K
Capacitance
Tolerance
A = ±0.05pF
B = ±0.1pF
C = ±0.25pF
D = ±0.5pF
G = ±2%
J = ±5%
K = ±10%
M = ±20%
N
Termination
Code
N = Ti/W-Ni-Au
Au (100μ-in min)
over
Ni (1500Å nom)
over
Ti/W (500Å nom)
6N
Packaging
Code
6N = Antistatic
Waffle Pack
NOTE: A Dielectric is not RoHS Compliant
10
