Thin Film Precision Resistors
Type CPF Series
1206
Rated Power @ 70°C:
Resistance Range (Ohms) Min:
Max:
Tolerance (%):
Code letter:
Selection Series:
Temp. Coefficient (ppm/°C):
Code Letter:
Limiting Element Voltage:
Max. Overload Voltage:
Operating Temp. Range:
Climatic Category (°C):
Insulation Resistance Dry Min:
Stability:
15
D
25 50
E
C
4R7
1M0
0.1
B
15
D
4R7
2M5
0.125W
4R7
1M0
0.5
D
E24 & E96
25 50
E
150V
300V
-55 to +155°C
55/125/55
1000MΩ
0.5%
C
15
D
25
E
50
C
15
D
E
1R0
2M5
4R7
1M0
1
F
1R0
2M5
4R7
1M0
0.1
B
E24 & E96
25
50
C
15
D
25 50
E
150V
300V
-55 to +155°C
55/125/55
1000MΩ
0.5%
C
15
D
25
E
50
C
4R7
2M5
4R7
1M0
0.5
D
1210
0.2W
1R0
2M5
4R7
1M0
1
F
1R0
2M5
2010
Rated Power @ 70°C:
Resistance Range (Ohms) Min:
Max:
Tolerance (%):
Code letter:
Selection Series:
Temp. Coefficient (ppm/°C):
Code Letter:
Limiting Element Voltage:
Max. Overload Voltage:
Operating Temp. Range:
Climatic Category (°C):
Insulation Resistance Dry Min:
Stability:
15
D
25 50
E
C
4R7
1M0
0.1
B
15
D
4R7
3M0
4R7
1M0
0.5
D
E24 & E96
25 50
E
150V
300V
-55 to +155°C
55/125/55
1000MΩ
0.5%
C
15
D
25 50
E
C
15
D
0.25W
1R0
3M0
4R7
1M0
1
F
1R0
3M0
4R7
1M0
0.1
B
E24 & E96
25 50
E
C
15
D
4R7
3M0
2512
0.5W
4R7
1M0
0.5
D
25 50
E
150V
300V
-55 to +155°C
55/125/55
1000MΩ
0.5%
C
15
D
1R0
3M0
4R7
1M0
1
F
25 50
E
C
1R0
3M0
Characteristics - Environmental
Item
Temperature Coefficient
of Resistance (TCR):
Short Time Overload:
Insulation Resistance:
Endurance:
Damp Heat with Load:
Bending Strength:
Solderability:
Resistance to Soldering Heat:
Dielectric Withstand Voltage:
Thermal Shock:
Low Temperature Operation:
Reference Standards: MIL-STD-202, JIS-C 5201-1
Storage Temperature: 25±3°C; Humidity < 80%RH
∆R ±0.05%
Requirement
Tol. ≤ 0.05%
Tol. > 0.05%
AS per TCRs specified in value range table on page 1
∆R ±0.05%
∆R ±0.2%
∆R ±0.2% for high power rating
>1000MΩ
∆R ±0.05%
∆R ±0.2%
>7kΩ ∆R ±0.5%
∆R ±0.5% for high power rating
∆R ±0.05%
∆R ±0.3%
∆R ±0.5% for high power rating
∆R ±0.05%
∆R ±0.05%
By Type
∆R ±0.25%
∆R ±0.05%
∆R ±0.2%
∆R ±0.5% for high power rating
∆R ±0.2%
∆R ±0.2%
95% min. coverage
Test Method
+25/-55/+25/+125/+25°C
RCWV* 2.5 or max. overload
voltage for 5 seconds
Apply 100VDC for 1 minute
70 ±2°C, max. working voltage
for 1000hrs with 1.5hrs
“ON” and 0.5 hrs “OFF”
40 ±2°C, 90 - 95% R.H. max. working voltage
hrs with 1.5hrs “ON” and 0.5hrs “OFF”
Bending amplitude 3mm for 10 seconds
245 ±5°C for 3 seconds
260 ±5°C for 10 seconds
Max. overload voltage for 1 minute
-55°C to +150°C, 100 cycles
1 hour, -65°C, followed by 45 minutes of RCWV
1773200 CIS WR 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Thin Film Precision Resistors
Type CPF Series
Marking Codes - Case Sizes 0805 to 2512
IEC 4 Digit Marking
Resistance:
Marking Code:
100Ω
1000
2.2KΩ
2201
10KΩ
1002
49.9KΩ
4992
100KΩ
1003
Case Sizes 0603
E24 3 Digit Marking - Example: 101=100Ω 102=1KΩ
E24
10
33
11
36
12
39
13
43
15
47
16
51
18
56
20
62
22
68
24
75
27
82
30
91
E96 3 Digit Marking - Examples: 14C=13K7Ω, 13C=13K3Ω, 68B=4K99Ω, 68X=49.9Ω
14C
0603 E96 Marking Code Table
Code
01
02
03
04
05
06
07
08
09
10
11
12
13
14
15
16
17
18
19
20
21
22
23
24
Code
Multiplier
A
10
0
E96
100
102
105
107
110
113
115
118
121
124
127
130
133
137
140
143
147
150
154
158
162
165
169
174
B
10
1
Code
25
26
27
28
29
30
31
32
33
34
35
36
37
38
39
40
41
42
43
44
45
46
47
48
C
10
2
E96
178
182
187
191
196
200
205
210
215
221
226
232
237
243
249
255
261
267
274
280
287
294
301
309
D
10
3
Code
49
50
51
52
53
54
55
56
57
58
59
60
61
62
63
64
65
66
67
68
69
70
71
72
E
10
4
E96
316
324
332
340
348
357
365
374
383
392
402
412
422
432
442
453
464
475
487
499
511
523
536
549
G
H
6
Code
73
74
75
76
77
78
79
80
81
82
83
84
85
86
87
88
89
90
91
92
93
94
95
96
X
7
E96
562
576
590
604
619
634
649
665
681
698
715
732
750
768
787
806
825
845
866
887
909
931
953
976
Y
Z
-2
F
10
5
10
10
10
-1
10
10
-3
1773200 CIS WR 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Thin Film Precision Resistors
Type CPF Series
Power Derating Curve
100
80
Rated Load (%)
60
40
20
0
-55
-40
-20
0
20
40
60 70 80
100
120
140 155
Ambient Temperature (°C)
For resistors operated in ambient temperatures above 70°C, power rating must be derated in accordance with this curve.
Dimensions
a
L
W
t
b
1. Alumina Substrate
2. Bottom Electrode (Ag)
3. Top Electrode (Ag-Pd)
4. Edge Electrode (NiCr)
5. Barrier Layer (Ni)
6. External Electrode (Sn)
7. Resistor Layer (NiCr)
8. Overcoat (Epoxy)
9. Marking
Part Number
CPF0201
CPF0402
CPF0603
CPF0805
CPF1206
CPF1210
CPF2010
CPF2512
L
0.58 ±0.05
1.00 ±0.05
1.55 ±0.10
2.00 ±0.15
3.05 ±0.15
3.10 ±0.15
4.90 ±0.15
6.30 ±0.15
W
0.29 ±0.05
0.50 ±0.05
0.80 ±0.10
1.25 ±0.15
1.55 ±0.15
2.40 ±0.15
2.40 ±0.15
3.10 ±0.15
H
0.23 ±0.05
0.30 ±0.05
0.45 ±0.10
0.55 ±0.10
0.55 ±0.10
0.55 ±0.10
0.55 ±0.10
0.55 ±0.10
a
0.12 ±0.05
0.20 ±0.10
0.30 ±0.20
0.30 ±0.20
0.42 ±0.20
0.40 ±0.20
0.60 ±0.30
0.60 ±0.30
b
0.15 ±0.05
0.20 ±0.10
0.30 ±0.20
0.40 ±0.25
0.35 ±0.25
0.55 ±0.25
0.50 ±0.25
0.50 ±0.25
Weight (g)
1000 pieces
0.14
0.54
1.83
4.71
9.02
10.00
23.61
38.08
Recommend Land Pattern
Type
CPF0201
CPF0402
CPF0603
CPF0805
CPF1206
CPF1210
CPF2010
CPF2512
A
0.25
0.5
0.8
1.0
2.0
2.0
3.6
4.9
B
0.3
0.5
1.0
1.0
1.15
1.15
1.4
1.6
C
0.40 ±0.2
0.60 ±0.2
0.90 ±0.2
1.35 ±0.2
1.70 ±0.2
2.50 ±0.2
2.50 ±0.2
3.10 ±0.2
1773200 CIS WR 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
Thin Film Precision Resistors
Type CPF Series
Packaging Quantity & Reel Specifications
Type
CPF0201
CPF0402
CPF0603
CPF0805
CPF1206
CPF1210
CPF2010
CPF2512
øA
178.0 ±1.0
178.0 ±1.0
178.0 ±1.0
178.0 ±1.0
178.0 ±1.0
178.0 ±1.0
178.0 ±1.0
178.0 ±1.0
øB
60.0 +1.0
60.0 +1.0
60.0 +1.0
60.0 +1.0
60.0 +1.0
60.0 +1.0
60.0 +1.0
60.0 +1.0
øC
13.5 ±0.7
13.5 ±0.7
13.5 ±0.7
13.5 ±0.7
13.5 ±0.7
13.5 ±0.7
13.5 ±0.7
13.5 ±0.7
W
9.5 ±1.0
9.5 ±1.0
9.5 ±1.0
9.5 ±1.0
9.5 ±1.0
9.5 ±1.0
13.5 ±1.0
13.5 ±1.0
T
11.5 ±1.0
11.5 ±1.0
11.5 ±1.0
11.5 ±1.0
11.5 ±1.0
11.5 ±1.0
15.5 ±1.0
15.5 ±1.0
Paper
Tape (EA)
1000 / 5000
1000 / 5000
1000 / 5000
1000 / 5000
1000 / 5000
1000 / 5000
-
-
Embossed
Plastic Tape (EA)
-
-
-
-
-
-
4000
4000
Paper Tape Specification
Type
CPF0201
CPF0402
CPF0603
CPF0805
CPF1206
CPF1210
A
0.40 ±0.05
0.70 ±0.05
1.10 ±0.05
1.60 ±0.05
2.00 ±0.05
2.75 ±0.05
B
0.70 ±0.05
1.16 ±0.05
1.90 ±0.05
2.37 ±0.05
3.55 ±0.05
3.40 ±0.05
W
8.00 ±0.10
8.00 ±0.10
8.00 ±0.10
8.00 ±0.10
8.00 ±0.10
8.00 ±0.10
E
1.75 ±0.05
1.75 ±0.05
1.75 ±0.05
1.75 ±0.05
1.75 ±0.05
1.75 ±0.05
F
3.5 ±0.05
3.5 ±0.05
3.5 ±0.05
3.5 ±0.05
3.5 ±0.05
3.5 ±0.05
P
0
4.00 ±0.10
4.00 ±0.10
4.00 ±0.10
4.00 ±0.10
4.00 ±0.10
4.00 ±0.05
P
1
2.00 ±0.05
2.00 ±0.05
4.00 ±0.10
4.00 ±0.10
4.00 ±0.10
4.00 ±0.10
P
2
øD
0
T
0.42 ±0.02
0.40 ±0.03
0.60 ±0.03
0.75 ±0.05
0.75 ±0.05
0.75 ±0.05
2.00 ±0.05 1.55 ±0.03
2.00 ±0.05 1.55 ±0.05
2.00 ±0.05 1.55 ±0.05
2.00 ±0.05 1.55 ±0.05
2.00 ±0.05 1.55 ±0.05
2.00 ±0.05 1.60 ±0.10
1773200 CIS WR 03/2012
Dimensions are in millimeters
and inches unless otherwise
specified. Values in brackets
are standard equivalents.
Dimensions are shown for
reference purposes only.
Specifications subject
to change.
For email, phone or live chat, go to:
te.com/help
