552230-1 Product Details
Live Product Chat
Product Photo
2.16 [.085] Printed Circuit Board Connectors
Not EU R oHS or ELV C om plia nt
(
Find R oHS C om plia nt Alte rna te s
)
Quick Links
C heck Pricing & Availability
Search for Tooling
Product Feature Selector
C ontact Us About This Product
552230-1
T E I nternal N umber: 5 5 2 2 3 0 - 1
Product Highlights:
l
Receptacle
l
Number of Positions = 24
l
PC B Mount Style = Edge Mount
l
Standard Orientation
l
Standard Profile
View all Features
Obsolete
C ontact Product Information C enter
A dd to M y P art L is t
Reques t Sample
Find Similar P roduc ts
Buy P roduc t
Documentation & Additional Information
Documents are temporarily unavailable. We are working hard to correct the problem. Please try
again later.
Additional Information:
l
Product Line Information
Additional Product Images:
l
Recommended PC Board Mtg Dim
l
Recommended PC Board Mtg Dim
Related Products:
l
Tooling
Product Features
(Please use the Product Drawing for all design activity)
Product Type Features:
l
Gender
= Receptacle
l
Number of Positions
= 24
l
PC B Mount Style
= Edge Mount
l
Orientation
= Standard
l
Profile
= Standard
l
Shielded
= No
l
Mating C onnector Lock = With
l
Mating C onnector Lock Type = Bail Lock, Screwlocks
l
PC B Retention Feature
= No
l
Grounded
= No
l
PC B Thickness (mm [in]) = 1.57 [0.062]
l
C olor = Black
l
Bracket Material = Thermoplastic
l
PC Board Material = Glass-filled Polyester
Mechanical Attachment:
l
Panel Attachment
= Without
l
Plate Material = Thermoplastic
l
C omb Material = Thermoplastic
Termination Related Features:
l
Solder Tail C ontact Plating = Tin
Contact Related Features:
l
C ontact Mating Area Plating Material
= Gold
l
C ontact Base Material = C opper Alloy
Housing Related Features:
l
Housing Material = Thermoplastic
l
Housing Flammability Rating = UL 94V-0
Industry Standards:
l
RoHS/ELV C ompliance
= Not ELV/RoHS compliant
l
Lead Free Solder Processes
= Wave solder capable to 240?C , Wave
solder capable to 260?C , Wave solder capable to 265?C
Other:
l
Brand = AMP
