SPR2213, SPR2214
Vishay Dale
Wirewound Resistors, Special Purpose,
Commercial, High Power
FEATURES
• High power/size ratio
• Quick connect terminals
• Complete welded construction
• High surge capability
• Non-inductive styles available
• Special inorganic potting compound and ceramic case
provide high thermal conductivity in a fireproof package
• SPR2214 is available with a center terminal option
• Compliant to RoHS Directive 2002/95/EC
STANDARD ELECTRICAL SPECIFICATIONS
GLOBAL
MODEL
SPR2213
SPR2214
HISTORICAL
MODEL
SPR-2213
SPR-2214
POWER RATING
P
25 °C
W
WITHOUT HEAT SINK
40
50
POWER RATING
P
25 °C
W
WITH HEAT SINK
(1)
70
100
RESISTANCE RANGE
0.5 to 24K
1.0 to 44K
TOLERANCE
±%
5, 10
5, 10
Note
(1)
Recommended heat sink is 12" x 12" x 0.125" thick aluminum panel (294 sq. in. surface area)
TECHNICAL SPECIFICATIONS
PARAMETER
Temperature Coefficient
Short Time Overload
Maximum Working Voltage
Operating Temperature Range
Dielectric Withstanding Voltage
UNIT
ppm/°C
-
V
°C
V
AC
SPR2213, SPR2214 RESISTOR CHARACTERISTICS
± 30 10
and above; ± 50 below 10
10 x rated power for 5 s
(P x R)
1/2
- 65 to + 275
2500
GLOBAL PART NUMBER INFORMATION
Global Part Numbering example: SPR221375R000JD
S
P
R
2
2
VALUE
1
3
7
5
R
0
0
0
J
D
SPECIAL
(Dash Number)
(up to 2 digits)
From
1 to 99
as
applicable
GLOBAL MODEL
SPR2213
SPR2214
TOLERANCE
J
= ± 5.0 %
K
= ± 10.0 %
PACKAGING
D
= Skin pack (S51)
K
= RoHS compliant,
skin pack (E51)
R
= Decimal
K
= Thousand
R15000
= 0.15
1K5000
= 1500
Historical Part Numbering example: SPR-2213 75
5 % S51
SPR-2213
HISTORICAL MODEL
75
RESISTANCE VALUE
5%
TOLERANCE CODE
S51
PACKAGING
Note
• Brackets used with “D” packaging code are not RoHS/Green compliant
* Pb containing terminations are not RoHS compliant, exemptions may apply
** Please see document “Vishay Material Category Policy”:
www.vishay.com/doc?99902
Document Number: 30224
Revision: 04-Feb-11
For technical questions, contact:
ww2aresistors@vishay.com
www.vishay.com
1
SPR2213, SPR2214
Vishay Dale
Wirewound Resistors, Special Purpose,
Commercial, High Power
DIMENSIONS
in inches [millimeters]
SPR2213
W
1.25
[31.75] typical
H
SPR2214
W
A
B
C
H
0.827 [21.01]
± 0.020 [0.508]
0.195 [4.95]
± 0.005 [0.127]
Diameter
0.195 [4.95]
± 0.005 [0.127]
GLOBAL
MODEL
SPR2213
SPR2214
A
TYPICAL
3.375
[85.73]
4.563
[115.90]
Dimensions
in inches [millimeters]
B
C
W
± 0.031 [0.794]
± 0.031 [0.794]
± 0.005 [0.127]
3.00
2.50
0.250 x 0.031
[76.20]
[63.50]
[6.35 x 0.794]
4.125
3.625
0.250 x 0.031
[104.78]
[92.08]
[6.35 x 0.794]
H
TYPICAL
0.810
[20.57]
0.810
[20.57]
MATERIAL SPECIFICATIONS
Element:
Copper-nickel alloy or nickel-chrome alloy,
depending on resistance value
Core:
Steatite ceramic
Body:
Steatite ceramic case with inorganic potting
compound
Terminals:
Nickel plated steel
Bracket:
Zinc plated steel
Part Marking:
DALE, model, wattage, value, tolerance, date
code
DERATING
RATED POWER IN %
120
100
80
60
40
20
0
- 65 - 25
25
75
125
175
225
275
HEAT SINK DERATING
RATED POWER IN %
100
80
60
SPR2214
40
20
0
AMBIENT TEMPERATURE IN °C
0
20
40
60
80
100
SPR2213
% OF RECOMMENDED HEAT
SINK
AREA
PERFORMANCE
TEST
Thermal Shock
Short Time Overload
Dielectric Withstanding Voltage
Low Temperature Storage
High Temperature Exposure
Moisture Resistance
Shock, Specified Pulse
Vibration, High Frequency
Load Life
CONDITIONS OF TEST
Rated power applied until thermally stable, then a minimum of 15 min at - 55 °C
10 x rated power for 5 s
1000 V
RMS
, 1 min
- 65 °C for 24 h
250 h at + 275 °C
MIL-STD-202 Method 106, 7b not applicable
MIL-STD-202 Method 213, 100
g’s
for 6 ms, 10 shocks
Frequency varied 10 Hz to 2000 Hz, 20 g peak, 2 directions 6 h each
1000 h at rated power, + 25 °C, 1.5 h “ON”, 0.5 h “OFF”
TEST LIMITS
± (2.0 % + 0.05
) R
± (2.0 % + 0.05
) R
± (0.1 % + 0.05
) R
± (2.0 % + 0.05
) R
± (2.0 % + 0.05
) R
± (2.0 % + 0.05
) R
± (0.2 % + 0.05
) R
± (0.2 % + 0.05
) R
± (3.0 % + 0.05
) R
www.vishay.com
2
For technical questions, contact:
ww2aresistors@vishay.com
Document Number: 30224
Revision: 04-Feb-11
