TO PIDSA HQ
DELIVERY SPECIFICATIONS
Orderer (Customer) Part Number
Panasonic Global Part Number
AN48836B-NL
1203003
Vendor Issue Number
Confirmation of Security Control
We confirm and certify that the products of these specifications shall not be supplied so as to be used for Military Purpose (defined herein
below). "Military Purpose" in this statement means the design, development, manufacture, storage or use of any weapons, including
without limitation nuclear weapons, biological weapons, chemical weapons and missiles.
ORDERER (CUSTOMER)
Receipt Date:
/
/
"Changes in the description of Delivery Specifications" and "changes that affect performance, quality or environment" are implemented
according to advance consultation.
VENDOR
2012.
3.12
Issuance Date:
/
/
SMART Puniness distraction
S423141-03#01
Industrial Devices Company, Panasonic Corporation
Request for your special attention and precautions in using the technical information and
semiconductors described in this book
(1) If any of the products or technical information described in this book is to be exported or
provided to non-residents, the laws and regulations of the exporting country, especially, those with
regard to security export control, must be observed.
(2)The technical information described in this book is intended only to show the main characteristics
and application circuit examples of the products. No license is granted in and to any intellectual
property right or other right owned by Panasonic Corporation or any other company. Therefore, no
responsibility is assumed by our company as to the infringement upon any such right owned by any other
company which may arise as a result of the use of technical information de-scribed in this book.
(3)The products described in this book are intended to be used for general applications (such as
office equipment, communications equipment, measuring instruments and household appliances), or for
specific applications as expressly stated in this book.
Consult our sales staff in advance for information on the following applications:
・Special applications (such as for airplanes, aerospace, automotive equipment, traffic signaling
equipment, combustion equipment, life support systems and safety devices) in which exceptional quality
and reliability are required, or if the failure or malfunction of the products may directly jeopardize
life or harm the human body.
It is to be understood that our company shall not be held responsible for any damage incurred as a
result of or in connection with your using the products described in this book for any special
application, unless our company agrees to your using the products in this book for any special
application.
(4)When designing your equipment, comply with the range of absolute maximum rating and the guaranteed
operating conditions (operating power supply voltage and operating environment etc.). Especially,
please be careful not to exceed the range of absolute maximum rating on the transient state, such as
power-on, power-off and mode-switching. Other-wise, we will not be liable for any defect which may
arise later in your equipment.
Even when the products are used within the guaranteed values, take into the consideration of incidence
of break down and failure mode, possible to occur to semiconductor products. Measures on the systems
such as redundant design, arresting the spread of fire or preventing glitch are recommended in order
to prevent physical injury, fire, social damages, for example, by using the products.
(5)Comply with the instructions for use in order to prevent breakdown and characteristics change due
to external factors (ESD, EOS, thermal stress and mechanical stress) at the time of handling, mounting
or at customer's process. When using products for which damp-proof packing is required, satisfy the
conditions, such as shelf life and the elapsed time since first opening the packages.
(6)This book may be not reprinted or reproduced whether wholly or partially, without the prior written
permission of our company.
Reprint from WARNING LABEL STANDARDS SC3-11-00007
This delivery specifications may include old company names such as “Matsushita Electronics Corporation” or
“Semiconductor Company, Matsushita Electric Industrial Co., Ltd
.“”Semiconductor Company, Panasonic
Corporation ” Please interpret these old company names as Industrial Devices Company, Panasonic
Corporation”
as of January 1, 2012.
AN48836B
Product Standards
Contents
Total Pages
14
Page
2
Overview ……………………………………………………………………………………………………………. 3
Features …………………………………………………………………………………………………………….. 3
Applications ………………………………………………………………………………………………………… 3
Package ……………………………………………………………………………………………………………. 3
Type …………………………………...……………………………………………………………………………. 3
Block Diagram ………………...……………………………………………………………………………………. 4
Pin Descriptions ……………………………………………………………………………………………………. 5
Absolute Maximum Ratings ………………………………………………………………………………………. 6
Operating Supply Voltage Range ……………..…………………………………………………………………. 6
Allowable Voltage Range ………………………..…………………………………………………………………. 6
Electrical Characteristics …………………………………………………………………………………………. 7
Electrical Characteristics (Reference values for design)
………...…………………………………………... 8
Test Circuit Diagram ………………………………………………………………………………………………. 9
Technical Data ………………………………………….…………………………………………………………… 11
Usage Notes ……………………………………….………………………………………………………………. 12
Caution on Use of Hall ICs ……………………….………………………………………………………………. 13
2011-03-11
Established
Revised
Semiconductor Company, Panasonic Corporation
AN48836B
Product Standards
Total Pages
14
Page
3
AN48836B
1.8 V Supply voltage, Low current consumption, high sensitivity CMOS Hall IC
Operates in both magnetic field directions
Overview
AN48836B is a Hall IC (a magnetic sensor) for 1.8 V supply voltage by using Bi-CMOS technology.
In this Hall IC, a Hall element, a offset cancel circuit, an amplifier circuit, a sample and hold circuit, a Schmidt circuit, and output
stage FET are integrated on a single chip housed in a small package by IC technique.
Features
High sensitivity (6 mT max) due to offset cancel circuit and a new sample and hold circuit.
Small current by using intermittent action. (average supply current : 3
μA
typ. sampling cycle : 42 ms typ at V
CC
= 1.8 V)
Small package (SMD)
CMOS inverter output (no pull-up resistance)
Applications
Magneto-electric Conversion Switch.
Package
5 pin Plastic Small Surface Mount Package (SMINI Type).
Type
Bi-CMOS IC.
2011-03-11
Established
Revised
Semiconductor Company, Panasonic Corporation
