T73
www.vishay.com
Vishay Sfernice
1/4" Square Single-Turn Cermet Sealed Trimmer
FEATURES
• Industrial grade
• Fully sealed
• Miniature package
• Rotor designed for automatic machine adjust interface
• Withstands harsh environments and immersion cleaning
process
• Tests according to CECC 41000 or IEC 60393-1
• Material categorization: for definitions of compliance
please see
www.vishay.com/doc?99912
DIMENSIONS
in millimeters (± 0.25 mm)
Common dimensions
Top adjust
T73Y
6.6
T73YP
T73YE
2.54*
3
1
2
2.54
2.54*
2
2.54*
3
1
2.54*
7
3.8
2.54*
1.02
3.53
4.7
Ø 0.46
T73YU
T73YB
90°
2
54
2.54*
5.46 ± 0.38
Base
level
Cruciform
slot
Ø 3
long 2.77, wide 0.64 - deep 0.89
3
2
1
2.54*
2.
54
3.53
3
1
2.
4.06 ± 0.38
Common dimensions
Side adjust
T73X
7
Ø 0.46 ± 0.05
T73XX
1.02
2.54*
3
2.54*
2
1
T73XH
1.02
2.54*
1
2.54*
2.54*
2
3
3.8
2.54*
6.6
4.7
4.7
5.46 ± 0.38
Base
level
T73XW
2.29
1
2.54*
T73XF
1.02
2.54*
1
2.54*
2.54*
2
3
Cruciform
slot
Ø 3
long 2.77, wide 0.64 - deep 0.89
2
3
2.54*
4.7
4.7
Revision: 23-Sep-15
Document Number: 51016
1
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
T73
www.vishay.com
Vishay Sfernice
Cermet
240° nominal
10
to 2 M
1-2-5
10 %
linear
0.5 W at +70 °C
ELECTRICAL SPECIFICATIONS
Resistive element
Electrical travel
Resistance range
Standard series
Tolerance standard
0.50
POWER IN W
Power rating
0.25
0
0
20
100
40
60 70
AMBIENT TEMPERATURE IN °C
a
c
(3)
b
(2)
cw
125
140
Circuit diagram
(1)
Temperature coefficient
Limiting element voltage
Contact resistance variation
Absolute minimum resistance
Adjustability
Resolution
Insulation resistance (500 V
DC
)
Dielectric strength
± 100 ppm/°C
300 V
1 % Rn or 3
max. whichever is greater
1 % Rn or 2
max. whichever is greater
± 0.05 % voltage
± 0.15 % resistance
infinite
10
3
M minimum
900 V
AC
sea level
350 V
AC
80 000 feet
MECHANICAL SPECIFICATIONS
Mechanical travel
Operating torque (max. Ncm)
End stop torque (max. Ncm)
Unit weight (max. g)
Terminals
270°
2.1
4.9
0.6
Pure Sn (code e3)
ENVIRONMENTAL SPECIFICATIONS
Temperature range
Climatic category
Sealing
-55 °C to +125 °C
55/100/56
Fully sealed - IP67
Revision: 23-Sep-15
Document Number: 51016
2
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
T73
www.vishay.com
Vishay Sfernice
CONDITIONS
1000 h - 0.5 W at + 70 °C
100 g
30 g
MIL-STD202 method 103 - 96 h
200 cycles
TYPICAL VALUES AND DRIFTS
R
T
/R
T
(%)
3%
±1%
±1%
±2%
±4%
CRV < 3
or 3 %
whichever is greater
V/V
± 1 %
V/V
± 1 %
i.R. 10 M
CRV < 3
or 3 %
whichever is greater
PERFORMANCES
TESTS
Load life
Shock
Vibration
Humidity
Rotational life
Load life
Note
• Nothing stated herein shall be construed as a guarantee of quality or durability.
STANDARD RESISTANCE ELEMENT DATA
STANDARD
RESISTANCE
VALUES
10
20
50
100
200
500
1K
2K
5K
10K
20K
50K
100K
200K
500K
1M
2M
LINEAR LAW
MAX. POWER
AT 70 °C
W
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.50
0.45
0.18
0.09
0.05
MAX. WORKING
VOLTAGE
V
2.2
3.2
5.0
7.1
10.0
15.8
22.4
31.6
50
70.7
100
158.1
223.6
300
300
300
300
MAX. WIPER
CURRENT
mA
224
160
100
70
50
32
22
16
10
7.1
5.0
3.2
2.2
1.5
0.60
0.30
0.15
± 100
TYPICAL
TCR
-55 °C
+125 °C
ppm/°C
MARKING
• Vishay trademark
• Resistance code
• Terminal numbers
• Date code
• Model
PACKAGING
• In tube of 50 pieces code T20 (TU50)
• On request: tape and reel for style YU, code R32 (TR750) and style XW code R15 (TR1000)
Revision: 23-Sep-15
Document Number: 51016
3
For technical questions, contact:
sferpottrimmers@vishay.com
THIS DOCUMENT IS SUBJECT TO CHANGE WITHOUT NOTICE. THE PRODUCTS DESCRIBED HEREIN AND THIS DOCUMENT
ARE SUBJECT TO SPECIFIC DISCLAIMERS, SET FORTH AT
www.vishay.com/doc?91000
