227-152
High-Pressure Environmental In-Line Gender Changer
How To Order
Sample Part Number
Series No.
Finish Sym
Shell Size
Insert Arrangement
Alternate Key Position
227 -152
Z1
10, 12, 14, 16, 18, 20, 22, 24
See Table I
N, 1, 2, 3 or 4
12
10
Table I: Insert Arrangements
Z1
16
-19 N
Shell Size
Insert
Arrangement
Dash No.
- 4
- 6
- 13
- 8
- 10
- 22
- 12
- 19
- 37
- 19
- 26
- 55
- 22
- 32
- 66
- 30
- 38
- 41
- 79
- 38
- 55
- 85
- 48
- 61
-100
Contact Size and
Quantity
22
6
13
8
10
22
12
19
37
19
26
55
22
32
66
30
41
79
38
55
85
48
61
100
30
8
20
4
16
227-152
Table II: Dimensions
Shell Size
10
12
14
16
18
20
22
24
A Thread
.750-.1P-.1L
.875-.1P-.1L
1.000-.1P-.1L
1.125-.1P-.1L
1.250-.1P-.1L
1.375-.1P-.1L
1.500-.1P-.1L
1.625-.1P-.1L
B Dia
.906
1.031
1.156
1.281
1.531
1.656
1.781
1.906
14
16
18
Notes:
20
1. Assembly identified with manufacturer's name and P/N, space permitting.
2. Glenair 227-152 connector receptacle is designed to mate with Glenair
220-16 series Geo-Marine®connectors. (scoop-proof )
3. Material/Finish:
Shell, lock nut - CRES/passivate.
Contacts - copper alloy/gold plate.
Insulators - high grade rigid dielectric/n.a.
Interface seal - fluorosilicone/n.a.
O-rings - nitrile/n.a.
22
24
MATES
WITH 220-16
Master Key Indicator
2.100 Max
O-ring
A Thread
Class 2a
Both Sides
ØB
Max
Red Color Band For Visual
Indication Of Full Mate Typ.
