ZR6XT
Oxyride Dry Battery AA type
Dimensions
Unit:：mm
Ａ
Ｂ
Ｃ
Ｄ
Ｅ
Ｆ
Ｇ
Ｐ
Ｐ½½
Max .
50.5
−
−
（4.0）
0.5
5.5
−
14.5
0.5
0.4
Min .
（49.2）
49.2
7.0
−
−
（4.2）
1.0
13.5
−
−
●（ ）is
reference
Discharge characteristic（20℃±2℃）
1000
※Label
will vary.
■
Specifications
Model number
Nominal voltage
Approximate weight
Terminal
Insulation of terminal
and exterior
Externals size
Diameter 14.5(
○
cap
+
ZR6XT
1.5V (Initial Voltage : 1.7V)
23g
○
base
-
Duration (h)
100
1.0V
10
1.2V
1.1V
0.9V
10MΩ（500V.D.C）
Height
50.5(
+0
-1.3
+0
-1.0
1
)mm
0.1
)mm
1
10
100
1000
10000
Load
（mA）
！
Caution
Since the initial voltage is higher than standard batteries
(1.7V), Oxyride
batteries may not be compatible with all electronic equipment.
・Electronic
equipment containing a remaining capacity
indicator may not function properly when using Oxyride
batteries.
・When
Oxyride batteries are used with an external-type
camera flash,the flash may not respond,or the flash may
retain more heat compared to use with Alkaline batteries.
・When
equipment that operates on rechargeable batteries is
changed with Oxyride batteries, the equipment may retain
more heat compared to charging with Alkaline batteries.
・Do
not use oxyride batteries with flashlights or headlamps
that use standard light bulbs, excessive current will flow
which will produce a bright light but reduce the life of the
bulb and/or generate heat which may cause the bulb
housing to warp.
・Oxyride
batteries may not function in certain clocks.
Temperature characteristic
100
Test end voltage： 1.0V
10
※The
data in this document are for descriptive purposes
only and are not intended to make or imply any guarantee or warranty.
Duration (h)
1
0.1
10
45℃
0℃
−10℃
20℃
100
1000
10000
Load
（mW）
Dry Battery
2006
Discharge Curves
1.8
1.7
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.7
0
Test end voltage
Cut off voltage
Test temperature
10
20
Discharge schedule：1000mW
(Continuousness)
：1.0V
：0.7V
：20℃±2℃
30
40
50
60
70
80
0.7
0
1.8
1.7
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0.9
0.8
Test end voltage
Cut off voltage
Test temperature
50
Discharge schedule：500mW
(Continuousness)
：1.0V
：0.7V
：20℃±2℃
80
120
160
200
※The
data in this document are for descriptive purposes
only and are not intended to make or imply any guarantee or warranty.
Dry Battery
Voltage (V)
Voltage (V)
Voltage (V)
Voltage (V)
Duration
（minutes）
Duration
（minutes）
1.8
1.7
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.7
0
100
200
300
400
500
600
700
Test end voltage
Cut off voltage
Test temperature
Discharge schedule：250mW
(Continuousness)
：1.0V
：0.7V
：20℃±2℃
1.8
1.7
1.6
1.5
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.7
0
Test end voltage
Cut off voltage
Test temperature
200
400 600
Discharge schedule：100mW
(Continuousness)
：1.0V
：0.7V
：20℃±2℃
800 1000 1200 1400 1600 1800 2000
Voltage (V)
Duration
（minutes）
Duration
（minutes）
1.8
1.7
1.6
Test end voltage
1.5
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.7
0
10
20
30
40
50
60
Cut off voltage
Test temperature
Discharge schedule：1000mA
(Continuousness)
：0.9V
：0.7V
1.8
1.7
1.6
1.5
Discharge schedule：100mA
(Continuousness)
Test end voltage
Cut off voltage
Test temperature
：0.9V
：0.7V
：20℃±2℃
Voltage (V)
：20℃±2℃
1.4
1.3
1.2
1.1
1.0
0.9
0.8
0.7
0
200
400
600
800
1000
1200
1400
Duration
（minutes）
Duration
（minutes）
2006
