80524RX333128: DescriptionMicroprocessor, 32-Bit, CMOS, PPGA370, 1.950 X 1.950 INCH, STAGGERED, PLASTIC, PGA-370; CategoryThe embedded processor and controller Microcontrollers and processors; File Size951KB，86 Pages; ManufacturerIntel; Websitehttp://www.intel.com/

Download Datasheet Parametric Compare View All

80524RX333128 Overview

Microprocessor, 32-Bit, CMOS, PPGA370, 1.950 X 1.950 INCH, STAGGERED, PLASTIC, PGA-370

80524RX333128 Parametric

Parameter Name	Attribute value
Maker	Intel
Parts packaging code	PGA
package instruction	IPGA,
Contacts	370
Reach Compliance Code	unknown
ECCN code	3A001.A.3
Address bus width	32
bit size	32
boundary scan	YES
maximum clock frequency	333 MHz
External data bus width	64
Format	FLOATING POINT
Integrated cache	YES
JESD-30 code	S-PPGA-P370
length	49.53 mm
low power mode	YES
Number of terminals	370
Package body material	PLASTIC/EPOXY
encapsulated code	IPGA
Package shape	SQUARE
Package form	GRID ARRAY, INTERSTITIAL PITCH
Certification status	Not Qualified
Maximum seat height	3.33 mm
Minimum supply voltage	2 V
Nominal supply voltage	2 V
surface mount	NO
technology	CMOS
Terminal form	PIN/PEG
Terminal pitch	2.54 mm
Terminal location	PERPENDICULAR
width	49.53 mm
uPs/uCs/peripheral integrated circuit type	MICROPROCESSOR
Base Number Matches	1

Preview

Download Datasheet

View All

Intel

Celeron™ Processor

Datasheet

Product Features

Available at 500 MHz, 466 MHz,

433 MHz, 400 MHz, 366 MHz, 333 MHz,

and 300A MHz core frequencies with

128 KB level-two cache; 300 MHz and

266 MHz core frequencies without

level-two cache.

Binary compatible with applications

running on previous members of the Intel

microprocessor line.

Dynamic execution microarchitecture.

Operates on a 66 MHz, transaction-oriented

system bus.

Specifically designed for valued PC

systems: based on the same P6

microarchitecture used in the Pentium

processor with the capabilities of MMX™

technology.

Power Management capabilities.

Optimized for 32-bit applications running

on advanced 32-bit operating systems.

Uses cost-effective packaging technology.

— Single Edge Processor (S.E.P.) Package

to maintain compatibility with SC242

(processor core frequencies (MHz):

266, 300, 300A, 333, 366, 400, 433).

— Plastic Pin Grid Array (PPGA) Package

(processor core frequencies (MHz):

300A, 333, 366, 400, 433, 466, 500).

Integrated high performance 32 KB

instruction and data, nonblocking, level-

one cache: separate 16 KB instruction and

16 KB data caches.

Integrated thermal diode.

The Intel

Celeron™ processor is designed for Value PC desktops and is binary compatible with

previous generation Intel architecture processors. The Intel

Celeron processor provides good

performance for applications running on advanced operating systems such as

Windows* 95/98, Windows* NT, and UNIX*. This is achieved by integrating the best attributes

of Intel processors—the dynamic execution performance of the P6 microarchitecture plus the

capabilities of MMX™ technology—bringing a balanced level of performance to the Value PC

market segment. The Intel

Celeron processor offers the dependability you would expect from

Intel at an exceptional value. Systems based on Intel

Celeron processors also include the latest

features to simplify system management and lower the cost of ownership for small business and

home environments.

PPGA Package

S.E.P. Package

Order Number:

243658-009

July 1999
