SCREW TERMINAL TYPE ALUMINUM ELECTROLYTIC CAPACITORS
FXR Series
• Conform RoHS
Useful of 8,000 hours at 85°C (Warranty of 5,000 hours at 85°C)
Product Specifications
Items
Specifications
–40°C ~ +85˚C
350 ~ 500V.DC
Temperature range
Rated voltage
Capacitance tolerance
Features
• Ripple Current increased by 37% (without wind) or 50%
(with 0.5m/s wind) by new heat radiation constructions in
case of ø90
• 500V added in the series.
±20% (20°C, 120Hz)
0.01CV (µA) or 5 mA, whichever is smaller or less(20℃, after 5 minutes)
Leakage current
[C = nominal capacitance (µF), V = rated voltage (V)]
Dissipation factor Less than the value specified in the standard products table. (20˚C,120Hz)
Permissible ripple current As specified in the standard products table. (85˚C,120Hz)
After the rated voltage with specified ripple current is applied at 85˚C for 5000 hours:
Capacitance tolerance: ±15% or less of the initial value
High-temperature load
Dissipation factor: 175% or less of the specified initial value
Leakage current: Specified initial value or less
Insulation plate
Insulation sleeve
Hexagon-head bolt
Screw terminal
Vent
Anode marking
Others
JIS C 5101-4.
Ripple current correction coefficient
P
±1
Marking
L
±2
T
±1
D
±2
(unit：mm)
Temperature (°C)
Correction coefficient
Frequency (Hz)
Correction coefficient
Forced wind (m/s)
Correction coefficient
40
1.89
50/60
0.7
＜
0.5
1.0
60
1.67
120
1.0
0.5
≦
1.1
85
1.00
300
1.1
1K
1.3
≧10K
1.4
φD
64
77
90
P
28.6
32.0
32.0
S
M5×10
M6×12
M6×12
T
4.5
3.0
3.0
Cap material
PPS
PPS
PPS
Terminal shapes: M5 for ø64; M6 for ø77, 90.
Terminal permissible currents: 60Arms for M5; 100Arms for M6.
Please use this type of capacitor at a terminal current below the permissible.
Product code : (Example) FXR type 400 V 5,600µF±20%
FXR
2G 562
Y
(
E
)
E case (øD: 77 mm) product
Type of series
Case code (∗)
Type of bracket code
Capacitance code
Rated voltage code
∗(
) Case code in parentheses : If two types of shape exist for the same rating,
enter the case code.
Bracket
• See page 55 for shapes and dimensions.
• Product names in the Standard Products Table correspond to the
bracket for Type Y, but Type
Ι
bracket may be used (Type of bracket
code =
Ι
).
• If bracket are not necessary, enter "N" for the type of bracket code.
• Bracket will be delivered separately.
Standard Products Table
Rated Voltage
Code
(Surge Voltage)
(V. DC)
Capacitance
(µF)
3900
4700
5600
Case size
øDXL(mm)
64×115
64×131
64×155
77×121
90×106
77×137
90×121
77×161
90×137
90×161
90×161
64×100
64×131
64×155
64×155
77×137
90×106
77×137
90×121
77×161
90×137
90×161
90×161
Ripple current
tanδ
20°C,120Hz
85°C,120Hz
(Arms)
ESR(typ.)
20°C,100Hz
(m
Ω
)
Z max
20°C,10kHz
(m
Ω
)
ESL(typ.)
(nH)
22
22
22
23
23
23
23
23
23
23
23
22
22
22
22
23
23
23
23
23
23
23
23
Product name
FXR2V392Y
FXR2V472Y
FXR2V562YD
FXR2V562YE
FXR2V562YF
FXR2V682YE
FXR2V682YF
FXR2V822YE
FXR2V822YF
FXR2V103Y
FXR2V123Y
FXR2G272Y
FXR2G332Y
FXR2G392Y
FXR2G472YD
FXR2G472YE
FXR2G472YF
FXR2G562YE
FXR2G562YF
FXR2G682YE
FXR2G682YF
FXR2G822Y
FXR2G103Y
350
2V
(400)
6800
8200
10000
12000
2700
3300
3900
4700
400
2G
(450)
5600
6800
8200
10000
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
0.15
14.6
16.9
19.8
21.6
22.3
25.0
26.2
29.3
30.1
35.7
39.1
11.5
14.2
16.5
18.1
20.8
20.5
22.7
23.8
26.6
27.4
32.2
35.7
25
20
17
17
17
14
14
12
12
9
8
38
30
26
21
21
21
18
18
15
15
12
10
26
21
18
18
18
15
15
12
12
9
8
40
32
28
22
22
2
19
19
16
16
12
10
65
