5.0 x 3.2x0.9mm Crystal
Standard Crystal Datasheet
Helping Customers Innovate, Improve & Grow
VXM5
Table 1. Electrical Performance
Parameter
Nominal Frequency
Mode
Operating Temperature Range
Stability Over T
OP1
Frequency Tolerance
2
Load Capacitance
Shunt Capacitance
Drive Level
T
OP
F
STAB
F
TOL
C
L
C
o
10
F
AGE
500
Description
T
STO
ESR
80
60
Applications
50
40
30
-40
90
Equivalent Series Resistance
Crystal Frequency
8.000MHz-12.000MHz
12.001MHz-16.000MHz
16.001MHz-20.000MHz
20.001MHz-24.000MHz
24.001MHz-54.000MHz
Ohm
6
±10
±10
32
5
100
±5
Symbol
F
NOM
Min.
8.000
Typ
Max
54.000
Units
MHz
°C
ppm
ppm
pF
pF
uW
ppm
MOhm
°C
Fundamental or 3rd Overtone
0/70, -10/70, -20/70, -40/85
±100
VT-804
Aging / 1st year (at 25 °C)
Insulation Resistance
Storage Temperature
Features
Notes:
1. Referenced to the Frequency at 25 °C.
2. Frequency measured at 25 °C ± 3 °C.
Product is compliant to RoHS directive and fully compatible with lead free assembly.
Package Drawing
Block Diagram
All Dimensions in mm
Page1
Tape & Reel
Table 7. Tape and Reel Dimensions (mm)
Tape
A
5.25
B
3.45
C
12.0
D
5.5
E
1.75
F
8.0
G
4.0
H
2.0
J
1.5
K
1.5
L
0.3
M
1.1
Reel
A
178
B
180
C
21.0
D
13.0
E
2.0
W
12.4
T
2.0
Reliability & IR Compliance
Table 2: Reflow Profile
Parameter
PreHeat Time
Ts-min
Ts-max
Ramp Up
Time Above 217 °C
Time To Peak Temperature
Time at 260 °C
Ramp Down
Symbol
t
S
Value
60 sec Min, 260 sec Max
150°C
200°C
3 °C/sec Max
60 sec Min, 150 sec Max
480 sec Max
30 sec Max
6 °C/sec Max
R
UP
t
L
T
AMB-P
t
P
R
DN
Pads are Au over Ni and compatible with either SnPb or Pb free attachment.
MSL: 1
Page2
Ordering Information
VXM5 - XXX - XX- xxMxxxxxxx
Product
5.0 x 3.2mm, Crystal
Mode
1:
Fundamental
Temp Stability
C:
10ppm
D:
15ppm
E:
20ppm
F:
25ppm
G:
30ppm
H:
35ppm
I:
40ppm
J:
45ppm
K:
50ppm
S:
100ppm
Frequency in MHz
Load Capacitance
0: Series Resonance
06-32pF
Operating Temperature
E:
-40 to 85 °C
J:
-20 to 70 °C
W: -10
to 70 °C
T:
0 to 70 °C
*Note: not all combination of options are available.
Other specifications may be available upon request.
10ppm stability not available for -40 to 85°C
*
Add
_SNPBDIP
for tin lead solder dip
Example: VXM5-1KE-18-26M0000000_SNPBDIP
