382876-8 datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > The connector> socket> 382876-8

382876-8: DescriptionSOCKET, PGA540, IC SOCKET; CategoryThe connector socket; File Size106KB，1 Pages; ManufacturerTE Connectivity; Websitehttp://www.te.com

Download Datasheet Parametric View All

382876-8 Overview

SOCKET, PGA540, IC SOCKET

382876-8 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
ECCN code	EAR99
Contact to complete cooperation	GOLD (30)
Contact completed and terminated	GOLD (30) OVER NICKEL
Device slot type	IC SOCKET
Type of equipment used	PGA540
Shell material	LIQUID CRYSTAL POLYMER
JESD-609 code	e4
Manufacturer's serial number	382876
Number of contacts	540
Base Number Matches	1

Preview

Download Datasheet

View All

C orporate Hom e

Electronic Components

Se gm e nts

W ho W e Are

My Account

Searc h

Products

Documentation

Resources

My Account

Customer Support

Home

Products

By Type

Socket/C ard Products

Product Feature Selector

> Product Details

382876-8 Product Details

Live Product Chat

PGA Sockets

Not re vie we d for R oHS C om plia nce

No Im a ge Ava ila ble

Quick Links

C heck Pricing & Availability

Search for Tooling

Product Feature Selector

C ontact Us About This Product

382876-8

T E I nternal N umber: 3 8 2 8 7 6 - 8

Product Highlights:

Zero Insertion Force

Number of Positions = 540

PC B Mount Style = Through Hole

Grid Size = 20x20

Grid Spacing = Interstitial: 1.27 x 2.54 mm

View all Features

Obsolete

C ontact Product Information

C enter

A dd to M y P art L is t

Reques t Sample

Find Similar P roduc ts

Buy P roduc t

Documentation & Additional Information

Product Drawings:

None Available

Catalog Pages/Data Sheets:

I C SOC KETS

(PDF, English)

Product Specifications:

None Available

Application Specifications:

None Available

Instruction Sheets:

None Available

CAD Files:

None Available

List all Documents

Product Features

(Please use the Product Drawing for all design activity)

Product Type Features:

Insertion Force

= Zero

Number of Positions

= 540

PC B Mount Style = Through Hole

Grid Size

= 20x20

Grid Spacing (mm [in])

= Interstitial: 1.27 x 2.54 [.050 x .100]

C hip C ompatibility

= Other

Frame Style

= C losed

Heat Sink Attachment

= Without

ZIF Actuator

= Handle

Profile

= Standard

C over Material = Liquid C rystal Polymer (LC P)

Electrical Characteristics:

Insulation Resistance (M?) = 5,000

Termination Related Features:

Termination Post Length (mm [in])

= 3.56 [0.140]

Socket Identifier = None

Solder Tail C ontact Plating = Gold (30) over Nickel

Body Related Features:

Assembly Process Feature = None

Actuator Handle Material = Zinc Alloy (C hromate Treated)

Contact Related Features:

C ontact Style

= Stamped + Formed

C ontact Base Material = C opper Alloy

C ontact Mating Area Plating Material = Gold (30)

Housing Related Features:

Housing C olor = Natural

Housing Material = Liquid C rystal Polymer (LC P)

Housing Flammability Rating = UL 94V-0

Housing Material Temperature = High

Industry Standards:

RoHS/ELV C ompliance

= Not reviewed for ELV/RoHS compliance

Lead Free Solder Processes

= Not reviewed for lead free solder

process

Operation/Application:

Application

= Test/Burn-In

Packaging Related Features:

Packaging Method = Tray

Other:

Brand = AMP

Additional Information:

Product Line Information
