5680F Series T-1 2 High Right Angle Assembly
D E S C R I P T I O N AN D F EAT U R E S
All dimensions in inches.
.200
MAX
LE D P OS IT ION 1
.360
F eatures :
• 2 T -1 LE Ds mounted in s ingle block.
• L es s P C board s pace needed, height and
s pacing alignment s aves as s embly cos t.
• High B rite and S uper B rite LE Ds , diffus ed lens .
• S tandoffs prevent flux entrapment.
• Bl ack Nylon plas tic block, UL94V -O
Alternate LE Ds are als o available in this package
as a s tandard variation.
Mounting hole pattern on page 1-X6.
.390
.200
LE D P OS IT ION 2
.100
.175±.015
Ø.120
.100
MAX
.200
.100
.020
S Q TYP.
.100
C AT HODE
E L E C T R O - O P T I C A L C H A R A CT E R I S T I C S AN D R A T I N G S
T ypical
Intensity
(mcd)
10.0
7
16
6.3
R ated
C urrent
(mA)
10
10
10
10
C ontinuous
F orward
C urrent Max.
(mA)
P art Number
5680F 1;1
5680F 3;3
5680F 5;5
5680F 7;7
E mitted
C olor
R ed/R ed
Amber/Amber
G reen/G reen
Y ellow/Y ellow
F orward V oltage
T yp.
(V )
2.0
2.0
2.2
2.1
Max.
(V )
3.0
3.0
3.0
3.0
R everse
B reakdown
V oltage Min.(V )
5.0
5.0
5.0
5.0
P eak
Wavelength
(nm)
650
603
562
585
30
30
30
30
T he model numbers listed above are standard off the shelf parts, for the user who may have a requirement calling for
various color/electrical specifications, a part number can be determined by referring to the chart shown below.
Model No. is as follows: 5680F
LE D
C ode
1LC
5LC
7LC
1-5V
3-5V
5-5V
1
3
5
7
LE D 1
;
LE D 2
LE D C olor
R ed
G reen
Y ellow
R ed
Amber
G reen
R ed
Amber
G reen
Y ellow
T ypical
Intensity
(mcd)
2.5
2.1
1.8
8.0
8.0
8.0
10
7
16
6.3
R ated
C urrent
(mA)
2.0
2.0
2.0
10.0
10.0
10.0
10.0
10.0
10.0
10.0
F orward
C urrent Max.
(mA)
F orward V oltage
T yp.
(V )
2.2
1.8
1.9
5.0
5.0
5.0
2.0
2.0
2.2
2.1
Max.
(V )
2.2
2.2
2.7
7.5
7.5
7.5
3.0
3.0
3.0
3.0
R everse
B reakdown
V oltage Min.
(V )
P eak
Wavelength
(nm)
650
565
583
655
583
565
635
603
562
583
7
7
7
20
15
15
30
30
30
30
5
5
5
5
5
5
5
5
5
5
America:
CML Innovative Technologies,Inc.
147 Central Avenue
Hackensack -NJ 07601 -USA
Tel:1-201-489 -8989
Fax:1-201-489 -6911
e-mail:americas@cml-it.com
Europe:
CML Technologies GmbH &Co.KG
Robert-Bunsen-Str.1
67098 Bad Dürkheim -GERMANY
Tel:+49 (0)6322 9567-0
Fax:+49 (0)6322 9567-88
e-mail:europe@cml-it.com
Asia:
CML Innovative Technologies,Inc.
61 Aida Street
Singapore 459975
Tel:(65)9630 -5003
e-mail:asia@cml-it.com
