BFR93AW-GS08 Overview

Transistor

BFR93AW-GS08 Parametric

Parameter NameAttribute value
MakerVishay
package instruction,
Reach Compliance Codeunknown
Maximum collector current (IC)0.05 A
ConfigurationSingle
Minimum DC current gain (hFE)40
Maximum operating temperature150 °C
Polarity/channel typeNPN
Maximum power dissipation(Abs)0.2 W
surface mountYES
Base Number Matches1
Not for new design, this product will be obsoleted soon
BFR93A/BFR93AR/BFR93AW
Vishay Semiconductors
Silicon NPN Planar RF Transistor
1
Features
High power gain
High transition frequency
e3
Low noise figure
Lead (Pb)-free component
Component in accordance to RoHS 2002/95/EC
and WEEE 2002/96/EC
SOT23
2
1
3
SOT23
3
2
1
SOT323
Applications
• Wide band amplifier up to GHz range
2
3
19150
Mechanical Data
Typ:
BFR93A
Case:
SOT23 Plastic case
Weight:
approx. 8.0 mg
Marking:
+ R2
Pinning:
1 = Collector, 2 = Base, 3 = Emitter
Typ:
BFR93AR
Case:
SOT23 Plastic case
Weight:
approx. 8.0 mg
Marking:
+ R5
Pinning:
1 = Collector, 2 = Base, 3 = Emitter
Electrostatic sensitive device.
Observe precautions for handling.
Typ:
BFR93AW
Case:
SOT323 Plastic case
Weight:
approx. 8.0 mg
Marking:
WR2
Pinning:
1 = Collector, 2 = Base, 3 = Emitter
Parts Table
Part
BFR93A
BFR93AR
BFR93AW
Ordering Code
BFR93AGELB-GS08
BFR93ARGELB-GS08
BFR93AW-GS08
Type Marking
+ R2
+ R5
WR2
Remarks
Tape and Reel
Tape and Reel
Tape and Reel
Package
SOT23
SOT23
SOT323
Absolute Maximum Ratings
T
amb
= 25 °C, unless otherwise specified
Parameter
Collector-base voltage
Collector-emitter voltage
Emitter-base voltage
Collector current
Total power dissipation
Junction temperature
Storage temperature range
T
amb
60 °C
Test condition
Symbol
V
CBO
V
CEO
V
EBO
I
C
P
tot
T
j
T
stg
Value
20
12
2
50
200
150
- 65 to + 150
Unit
V
V
V
mA
mW
°C
°C
Document Number 85035
Rev. 1.6, 08-Sep-08
www.vishay.com
1
