REVISIONS
REV.
D
E
F
ECO. NO
1869
2055
2164
2516
DESCRIPTION
DATE
BY
JH
LH
LH
LH
F
ADD CONTACT DEPTH 6.4mm, UPDATE TOP VIEW & 12/23/2008
TOLERANCE, WIDTH 2.54 WAS 2.4
ADD CONTACT POINT DISTANCE 2.48mm
CORRECT TOP VIEW AND ISO VIEW (PIN HOLE
LOCATION) & RIGHT VIEW (.063" DISTANCE)
11/12/2009
7/28/2010
F
G
UPDATE NOTE 10 AND ADD NOTE 11 MATING PARTS 02/14/2012
E
E
.100±.008 2.54±0.20
A±.008 [ 0.20]
D
B±.014[ 0.35]
.124±.008 3.15±0.20
.102 2.58
.257±.008 6.53±0.20
.335±.006 8.50±0.15
D
C
C
.063±.008 1.60±0.20
.024(w)X.016(t)
[0.60x0.40]
02-20, 0.20mm MAX.
NOTES:
21-30, 0.30mm MAX.
1. INSULATOR MATERIAL: SEE PART NUMBER CODING.
31-40, 0.40mm MAX.
2. CONTACT MATERIAL: PHOSPHOR BRONZE.
3. CONTACT PLATING: SEE PART NUMBER CODING.
4. CURRENT RATING: 3 AMPS PER CONTACT.
5. VOLTAGE RATING: 250V AC/DC
6. INSULATOR RESISTANCE: 5000 MEGOHMS MIN.
7. CONTACT RESISTANCE: 20 MILLIOHMS MAX.
8. DIELECTRIC WITHSTANDING: 500V AC.
9. OPERATING TEMPERATURE: -40° C TO +105° C.
10.*PROCESSING TEMPERATURE: SEE PART NUMBER CODING.
11.MATES WITH SULLINS .100 [2.54] CONTACT CENTER MALE HEADER SERIES.
(.025 [0.64] SQUARE POSTS)
*INDICATED TEMPERATURE AND TIME IS FOR COMPONENT
INSULATOR. HIGHER PROCESSING TEMPERATURES MAY BE USED,
PROVIDED HEAT IS APPLIED FROM BACK SIDE OF PCB, AND INSULATOR
DOES NOT EXCEED INDICATED TEMPERATURE AND TIME.
8
7
6
5
.100±.002 2.54±0.05
A±.004[ 0.10]
.100±.002 2.54±0.05
.040±.002 1.02±0.05
B
B
RECOMMENDED PCB LAYOUT
A
Pb
RoHS
COMPLIANT
4
UNLESS OTHERWISE SPECIFIED:
DIMENSIONS ARE IN INCHES [MM]
TOLERANCES:
ANGULAR:
5
DRAWN
DATE
NAME
12/15/2008 JH
THE INFORMATION HEREIN CONTAINS
PROPIETARY INFORMATION OF
SULLINS ELECTRONICS AND IS NOT
TO BE REPRODUCED, USED OR
DISCLOSED TO OTHERS FOR ANY
PURPOSE EXCEPT AS SPECIFICALLY
AUTHORIZED IN WRITING BY AN
OFFICER OF SULLINS ELECTRONICS.
TITLE
PART NUMBER
SIZE
HEADER FEMALE, 2.54mm CC, 1 ROW, RA
CAGE CODE
A
DECIMALS
.X= .012 [.3]
.XX= .008 [.20]
.XXX= .006 [.15]
3
SCALE: 12:1
2
C
54453
DWG. NO.
xPxCxx1LGBN-RC
10493
SHEET 1 OF 1
1
REV
G
FILE NAME: 10493, P(N)PxCxx1LGBN-RC
