(888) IPD-CONVerters
q
(888) 473-2668
q
www.ipdconverters.com
FRD SERIES - DUAL OUTPUT, 5 WATT
DESCRIPTION
FEATURES
• 500V Isolation
• Short Circuit Protection
• 6-Sided Shielding
FRD dual output DC/DC converters offer excellent
• Wide Input Range
regulation and isolation in an industry standard
• Trim and Enable Pins
package. Available in several input versions, the FRD • Remote Sense Pins
is perfect for industrial, datacom, or telecom
applications. The FRD features short circuit
protection, six-sided shielding, and 500 VDC isolation.
Please see the FRS series for single output applications.
80
75
70
65
60
55
50
45
40
35
10
20
30
40
50
60
70
80
90
10
Efficiency vs. Load (28V Input)
EFFICIENCY %
EFF. FRD2812
EFF. FRD2815)
TECHNICAL SPECIFICATIONS
Input
Voltage Range
Reflected Ripple
Reverse Input Current
5V, 12V, 24V, 28V, and 48V Nominal
See selection chart for specific input range.
20% I
in
Max.
100% I
in
Max.
LOAD %
Efficiency vs. Load (48V Input)
70
65
60
55
50
45
40
35
30
25
10
20
30
40
50
60
70
80
90
10
LOAD %
EFF. FRD4812
EFF. FRD4815
Output
Setpoint Accuracy
Line Regulation V
in
Min. - V
in
Max., I
out
Rated
±1% V
out
±0.15% V
out
Load Regulation I
out
Min. - I
out
Max., V
in
Nom.
Minimum Output Current
Short Circuit Protection
1
±0.15% V
out
I
out
Rated
10 % l
out
Rated
Continuous
General
Switching Frequency
Isolation
Input - Output
Isolation Resistance - Input to Output
Case Temperature
Operating Range
Storage Range
Humidity Max, Non-Condensing
Temperature Coefficient
Vibration, 3 Axes, 5 Min Each
Safety
Weight (Approx.)
20 kHz
500 VDC
10
9
Ohms
-25 To +85°C
-40 To +125°C
95%
±0.02%/°C
5 g, 10 - 55 Hz
Consult Factory
2.2 oz
Notes
†
Specifications typically at 25°C, normal line, and full load, unless otherwise stated.
Soldering Conditions: I/O pins, 260°C, ten seconds; fully compatible with
commercial wave-soldering equipment.
Safety: Agency approvals may vary from model to model. Please consult factory
for specific model information.
C-64
EFFICIENCY %
MTBF predictions may vary slightly from model to model.
FRD SERIES - DUAL OUTPUT, 5 WATT
MODELS - (See the last page of this file for options.)
Vin
(Volts)
5
5
12
12
24
24
28
28
48
48
Vin Range
(Volts)
4.65 - 5.50
4.65 - 5.50
10.90 - 13.20
10.90 - 13.20
21.60 - 26.40
21.60 - 26.40
25.20 - 30.80
25.20 - 30.80
43.20 - 52.80
43.20 - 52.80
Iin Max.*
(Amps)
2.01
2.04
0.85
0.86
0.43
0.45
0.37
0.38
0.21
0.22
Vout
(Volts)
±12
±15
±12
±15
±12
±15
±12
±15
±12
±15
Iout Rated
(Amps)
±0.23
±0.19
±0.23
±0.19
±0.23
±0.19
±0.23
±0.19
±0.23
±0.19
Ripple & Noise
Pk-Pk (mV)
40
40
40
40
40
40
40
40
40
40
Efficiency
Typ. **
65%
66%
66%
67%
66%
65%
69%
71%
65%
66%
Model
FRD512
FRD515
FRD1212
FRD1215
FRD2412
FRD2415
FRD2812
FRD2815
FRD4812
FRD4815
* Maximum input current at minimum input voltage, maximum rated output power.
** At nominal Vin, rated output.
MECHANICAL DRAWING
2.00"
(50.8mm)
0.18"(4.6mm) MIN.
0.100"
-0.300"
(-7.6mm) (2.5mm)
1.40"
(35.6mm)
0.500"
(12.7mm)
0.800"
(20.3mm)
3
4
5
2.00"
(50.8mm)
BOTTOM VIEW
1
0
2
DIA 0.040"
(1.0mm)
0
0.200"
(5.1mm)
0.40"
1.10"
(27.9mm)
(10.2mm)
Thermal Impedance
Natural convection
100 LFM
200 LFM
300 LFM
400 LFM
10.3
7.7
6.3
5.1
4.1
°C/W
°C/W
°C/W
°C/W
°C/W
Pin
1
2
3
4
5
Function
+V
in
-V
in
+ V
out
Common
- V
out
Inches:
.XX ± 0.040
.XXX ± 0.010
Pin:
± 0.002
Case:
+ 0.04, - 0.00
Tolerances
(Millimeters)
.X ± 1.0
.XX ± 0.25
± 0.05
+ 1.0, - 0.0
Note:
Thermal impedance data is dependent on
many environmental factors. The exact
thermal performance should be validated
for specific application.
(Tolerances as listed unless otherwise specified.)
C-65
OPTIONS
When ordering equipment options, use the following suffix information. Select the option(s) that
you prefer and add them to the model number. Example ordering options are located below the
options table.
OPTION
Negative Logic
Lucent Compatible Trim
Terminal Strip
Trim
Enable
Trim and Enable
Current Share
Headerless
SUFFIX
N
T
TS
1
2
3
4
Y
APPLICABLE SERIES
HAS, HBD, HBS, HES, LES, QBS,
QES, TES, TQD
HAS, HBD, HBS, HES, QBS, QES
XWS, XWD, XWT
IAS, LES
IAD, IAS, LES, SMS
IAS, LES
SMS
Encapsulated EWS, IWS, OWS
REMARKS
TTL “Low” Turns Module ON
TTL “High” Turns Module OFF
PIN LENGTH AND HEATSINK
OPTIONS
0.110” (2.8mm) Pin Length
0.150” (3.8mm) Pin Length
0.24” (6.1mm) Horizontal Heatsink
0.24” (6.1mm) Vertical Heatsink
0.45” (11.4mm) Horizontal
Heatsink
0.45” (11.4mm) Vertical Heatsink
0.95” (24.1mm) Horizontal
Heatsink
0.95” (24.1mm) Vertical Heatsink
8
9
1H
1V
2H
2V
3H
3V
All Units (Except SMS)
All Units (Except SMS)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
All Units (Except DIP, SIP, and SM
Packages)
Standard Pin Length is 0.180”
(4.6mm)
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Includes Thermal Pad
Example Options:HBS050ZG-ANT3V = HBS050ZG-A with negative logic, Lucent compatible trim, and
0.95” vertical heatsink.
LES015YJ-3N = LES015YJ with optional trim and enable, negative logic.
QBS066ZG-AT8 = QBS066ZG-A with Lucent compatible trim and 0.110” pin length.
NUCLEAR AND MEDICAL APPLICATIONS
Power-One products are not authorized for use as critical components in life support systems,
equipment used in hazardous environments, or nuclear control systems without the express written consent of the President of Power-One, Inc.
TECHNICAL REVISIONS
The appearance of products, including safety agency certifications pictured on labels, may change depending on the
date manufactured. Specifications are subject to change without notice.
C105
