www.amccaps.com
H
igH
T
emperaTure
S
Tacked
c
apaciTorS
K
ey
F
eatures
• For Use at Temperatures Up to 200°C
• Rated Working Voltages from 50V to 200V
• Rugged Stack with Hi-Temp Lead-Attachment
• MLC Designs Utilizing Military Grade Ceramics
• Custom Sizes, Voltages, and Values Available
a
pplications
• For High Temperature Applications Such As:
- Oil Well Logging (Downhole)
- Geophysical Probes
E
D
- Jet Engine Controls
B A
M
echanical
c
haracteristics
D
E
.250" MIN
.055"
±
.010
.020"
±
.002
.100" MAX
.025" MIN
F
.010"
±
.002
C
Straight Lead
.100" TYP
L-Lead
J-Lead
B A
.070"
±
.010
.250" MIN
.055"
±
.010
.020"
±
.002
.100" MAX
.025" MIN
.100" TYP
F
.010"
±
.002
.050" min
.050" min
C
.070"
±
.010
.050" min
.050" min
h
ow to
o
rder
101
VOLTAGE
Standard Voltages:
500 = 50 V
101 = 100 V
201 = 200 V
T23
CASE SIZE
See Chart
W
DIELECTRIC
N = NPO
W = X7R
106
CAPACITANCE
1st two digits are
significant; third digit
denotes number of
zeros.
103 = .01 µF
104 = 0.1 µF
105 = 1.0 µF
106 = 10 µF
K
TOLERANCE
J = ± 5% *
K = ± 10%
M = ± 20%
* (NPO only)
J
LEAD STYLE
J = “J” Leads
(formed in)
L = “L” Leads
(formed out)
N = Straight Lead
4
MARKING
3 = Special Mark
4 = Standard Mark
6 = EIA 2-digit
S
SPECIAL CODE
S = Other Special
Example Part number written: 101T23W106KJ4 =Rated 100 VDC@200°C, 10uF± 10% X7R in T23 size.
22
Advanced Monolythic Ceramics, Inc., A Johanson Company 3101 Constitution Avenue, Olean, New York 14760 • (716) 372-5225 • Fax (716) 372-5467
www.amccaps.com
d
ielectric
c
haracteristics
TEMPERATURE COEFFICIENT:
CAP DROP AT 200°C:
DISSIPATION FACTOR:
INSULATION RESISTANCE:
@25
°C
INSULATION RESISTANCE:
@200
°C
DIELECTRIC STRENGTh:
TEST PARAMETERS:
NPO DIELECTRIC
0 ± 30 ppm, -55 to 125°C
minus 0.5% max
.001 (0.1%) max, 1Khz, 25°C
1000 Ohm-Farads or 100 Gigohms
whichever is less @ 25°C, WVDC
1 Ohm-Farads or 100 Megohms
whichever is less @ 200°C, WVDC
2.5 X WVDC, 25°C, 50 mA max
1Khz ± 50Hz, 1.0±0.2 VRMS, 25°C
X7R DIELECTRIC
0 ± 15% ,-55 to 125°C
minus 45% max
.025 (2.5%) max, 1KHz, 25°C
1000 Ohm-Farads or 100 Gigohms
whichever is less @ 25°C, WVDC
1 Ohm-Farads or 100 Megohms
whichever is less @ 200°C, WVDC
2.5 X WVDC, 25°C, 50 mA max
1Khz ± 50Hz, 1.0±0.2 VRMS, 25°C
c
apacitance
/ V
oltage
s
election
Case
Size
T05
T25
T35
T45
T55
T04
T24
T34
T44
T54
T03
T23
T33
T43
T53
50 V
.056
0.10
0.15
0.22
0.27
0.12
0.22
0.33
0.47
0.56
0.47
0.82
1.20
1.80
2.20
NPO Max Capacitance (µF)
100 V
.047
.082
0.12
0.18
0.22
0.10
0.18
0.27
0.39
0.56
0.39
0.68
1.00
1.50
1.80
200 V
.022
.039
.068
.082
0.10
.047
.082
0.12
0.18
0.27
0.22
0.39
0.68
0.82
1.00
50 V
1.20
2.20
3.30
4.70
5.60
2.70
4.70
8.20
12.0
15.0
10.0
18.0
27.0
39.0
47.0
X7R Max Capacitance (µF)
100 V
0.68
1.20
1.80
2.70
3.30
1.50
2.70
3.90
5.60
8.20
5.60
10.0
15.0
22.0
27.0
200 V
0.33
0.68
1.00
1.20
1.50
0.82
1.50
2.20
3.30
3.90
2.70
4.70
8.20
10.0
12.0
M
echanical
c
haracteristics
Case
Size
T05
T25
T35
T45
T55
T04
T24
T34
T44
T54
T03
T23
T33
T43
T53
A
(max.”)
.120
.240
.360
.480
.650
.120
.240
.360
.480
.650
.120
.240
.360
.480
.650
B
(max”)
.185
.305
.425
.545
.715
.185
.305
.425
.545
.715
.185
.305
.425
.545
.715
C
±.025
D
(min.”)
D
(max.”)
E
(max.”)
F
(min.”)
Leads
per side
.250
.224
.275
.300
.080
3
.400
.350
.425
.440
.180
4
.450
.950
1.075
.500
.180
10
Advanced Monolythic Ceramics, Inc., A Johanson Company 3101 Constitution Avenue, Olean, New York 14760 • (716) 372-5225 • Fax (716) 372-5467
23
